AP8030DN
Product Description
Issue
05
Date
2017-04-20
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei AP8030DN

Summary of Contents for Huawei AP8030DN

  • Page 1 AP8030DN Product Description Issue Date 2017-04-20 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    NOTICE is used to address practices not related to personal injury. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 4 Changes in Issue 02 (2014-12-05) This version has the following updates: The following information is modified:  5.2 Radio Specifications Changes in Issue 01 (2014-09-10) This is the initial commercial release. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 5: Table Of Contents

    4 Product Features (in Cloud-based Management Mode) ..........20 5 Technical Specifications ....................24 5.1 Basic Specifications ................................24 5.2 Radio Specifications ................................25 5.3 Standards Compliance ............................... 32 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 6: Product Positioning And Characteristics

    2.4 GHz harbors, data and 5 GHz backhaul, video frequency surveillance, bands to and train-to- support more ground access users. It backhaul). also provides comprehensive Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 7 The AP8030DN can work as a Fat AP, Fit AP, or cloud AP. It can switch flexibly among three working modes based on the network plan. Typical networking modes are as follows: Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright ©...

  • Page 8: Issue 05 (2017-04-20) Huawei Proprietary And Confidential

    In this networking, the AP functions as a Fit AP. The AC is responsible for user access, AP go-online, AP management, authentication, routing, security, and QoS. Huawei products that provide the AC function include the AC6605, AC6005, ACU2 (with S7700, S9700, or S12700), S5720HI, S6720HI, S7700 (with X series board), S9700 (with X series board), and S12700 (with X series board).
  • Page 9 AP8030DN 1 Product Positioning and Characteristics Product Description Figure 1-2 Fat AP networking Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 10 Campus on the same cloud for user access, AP online, authentication, routing, AP management, security, and QoS. An enterprise can choose to use the Portal authentication server integrated in the Agile Controller-Campus or the authentication server deployed by itself. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 11: Product Characteristics

     The RADIUS server delivers packet forwarding, security, and QoS policies according to the device type carried in the RADIUS authentication and accounting packets in Fit AP mode. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 12 (NMS) to facilitate remote configuration and fast fault location. Supports the Link Layer Discovery Protocol (LLDP) to implement automatic link discovery and obtain the network topology. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 13 Complies with IP67 protection standards. Provides 6 kA or 6 kV surge protection capability on an Ethernet interface. Complies with international standards and China safety standards III. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 14: Hardware Structure

    AP. NOTE The actual device appearance may be different from the following device appearance, but these differences will not affect device functions. Figure 2-1 AP appearance Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 15 CONSOLE: Connects to a maintenance terminal for AP configuration and management. Default:Restores factory settings and restarts the device when you hold down the button more than 3 seconds. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 16 After the system is status blinking once reset and starts uploading the software, the indicator blinks green once. Until the software is uploaded and started, the indicator remains steady green. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 17 AP successfully goes online. The AP works in Fit AP or cloud- based management mode and fails to go online. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 18 Green Blinking The AP has STAs connected to the 2.4 GHz radio and is transmitting data. The indicator blinks more quickly when more data is being transmitted. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 19 Wireless indicator to reflect the service traffic volume on the radio. When an AP functions as a Fat AP, the Wireless indicator of the AP cannot reflect the signal strength. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 20: Product Features (In Fat Ap And Fit Ap Modes)

    Control and Provisioning of Wireless Access Points (CAPWAP) in Fit AP mode  Automatic login in Fit AP mode  Extended Service Set (ESS) in Fit AP mode  Wireless distribution system (WDS) in Fit AP mode Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 21: Network Features

     Airtime scheduling  Smart Application Control (SAC) in Fit AP mode 3.4 Security Features Security features supported by the AP are as follows: Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Maintenance Features

    Identifies the device type according to the organizationally unique identifier (OUI) in the MAC address.  Identifies the device type according to the user agent (UA) information in an HTTP packet. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 23: Locating Service

    (at 2.4 GHz frequency band only), wireless audio transmitters (at both the 2.4 GHz and 5 GHz frequency bands), wireless game controllers, and microwaves.  Works with eSight to perform spectrum analysis on interference sources. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 24: Product Features (In Cloud-Based Management Mode)

    4 Product Features (in Cloud-based Management Mode) Product Description Product Features (in Cloud-based Management Mode) The following table lists features supported by APs in cloud-based management mode. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 25 DHCP  STA isolation in the same VLAN  Access control lists (ACLs)   Unified authentication on the Agile Controller-Campus   Network Address Translation (NAT) Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 26 (WPA2 enterprise edition)  WPA-WPA2 hybrid authentication  802.1x authentication, MAC address authentication, and Portal authentication  DHCP snooping  Dynamic ARP Inspection (DAI)  IP Source Guard (IPSG) Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 27 Web local AP management through HTTP or HTTPS Real-time configuration monitoring and fast fault location using the NMS System status alarm Network Time Protocol (NTP) Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 28: Technical Specifications

    -40° C to +70° C Operating humidity 0% to 100% (non-condensing) IP rating IP67 Wind resistance Up to 149 MPH 53 kPa to 106 kPa Atmospheric pressure Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 29: Radio Specifications

    – 20 MHz: Compliance. 802.11n 20 MHz: 3 802.11n 40 MHz: 1 – 20 MHz: – 40 MHz: 802.11ac – 20MHz: – 40MHz: 4 – 80MHz: 2 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 30 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 40cm between the radiator and any part of your body. Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 31 -86 dBm @ MCS17 MCS17 -90 dBm @ -86 dBm @ MCS18 MCS18 -85 dBm @ -81 dBm @ MCS19 MCS19 -81 dBm @ -79 dBm @ MCS20 MCS20 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 32 Product Description Item Description -78 dBm @ -75 dBm @ MCS21 MCS21 -76 dBm @ -74 dBm @ MCS22 MCS22 -74 dBm @ -71 dBm @ MCS23 MCS23 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 33 -87 dBm @ MCS17 MCS17 -89 dBm @ -86 dBm @ MCS18 MCS18 -84 dBm @ -81 dBm @ MCS19 MCS19 -81 dBm @ -78 dBm @ MCS20 MCS20 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 34 Product Description Item Description -76 dBm @ -74 dBm @ MCS21 MCS21 -75 dBm @ -72 dBm @ MCS22 MCS22 -74 dBm @ -71 dBm @ MCS23 MCS23 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 35 MCS8NSS2 MCS7NSS2 MCS7NSS2 -91 dBm @ -67 dBm @ -64 dBm @ MCS0NSS3 MCS8NSS2 MCS8NSS2 -90 dBm @ -66 dBm @ -62 dBm @ MCS1NSS3 MCS9NSS2 MCS9NSS2 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 36: Standards Compliance

     GB 4943 Radio standards  ETSI EN 300 328  ETSI EN 301 893  FCC Part 15C: 15.247  FCC Part 15C: 15.407  RSS-210 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 37 EAP Type(s) Environment standards  ETSI 300 019-2-1  ETSI 300 019-2-2  ETSI 300 019-2-4  IEC 60068-2-52  ETSI 300 019-1-1  ETSI 300 019-1-2 Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 38 CENELEC EN 50385  OET65  RSS-102  FCC Part1&2  FCC KDB RoSH  Directive 2002/95/EC & 2011/65/EU Reach  Regulation 1907/2006/EC WEEE  Directive 2002/96/EC & 2012/19/EU Issue 05 (2017-04-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
