- Page 1 AP4030DN Quick Start Guide FCC ID: QISAP4030DN Issue Date 2015-02-06 HUAWEI TECHNOLOGY CO., LTD...
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: About This Document
AP4030DN Quick Start Guide About This Document About This Document Intended Audience This document describes hardware features of the AP7030DE and AP9330DN and provides basic installation methods. This document is intended for:： Network planning engineers Hardware installation engineers ... - Page 4 AP4030DN Quick Start Guide About This Document Symbol Description NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration. Change History Changes between document issues are cumulative. The latest document issue contains all changes made in previous issues.
-
Page 5: Table Of Contents
AP4030DN Quick Start Guide Contents Contents About This Document ........................iii 1 Indoor AP Overview ........................6 1.1 Device Structure ................................6 1.2 Indicator Description ..............................7 1.3 Basic Specifications ..............................9 1.4 Global Environmental Compliance..........................9 ... -
Page 6: Indoor Ap Overview
Indoor AP Overview About This Chapter The cost-effective AP4030DN supports 2 x 2 MIMO and provides comprehensive service support capabilities. It is deployed indoors and features high reliability, high security, simple network deployment, automatic AC discovery and configuration, and real-time management and maintenance. -
Page 7: Indicator Description
After an AP is powered on, you can run the led off command on the AC to turn off all AP indicators. To restore the indicators to normal working status, run the led on command. The AP4030DN has indicators located inside the panel. The indicators turn on after the AP is powered on. 华为专有和保密信息... - Page 8 AP4030DN Quick Start Guide Contents Figure 1-2 Indicator on the AP4030DN Table 1-2 Description of the indicator on the AP4030DN Type Color Status Description Default Green Steady on The AP is just powered on and the software is not started yet.
-
Page 9: Basic Specifications
DRAM detection failure or system software loading failure. The fault cannot be automatically rectified and must be rectified manually. 1.3 Basic Specifications Table in Table 1-3 shows the specifications of AP4030DN. Table 1-3 Basic specifications of the AP4030DN Item Description... - Page 10 品中可能会也可能不会含有所有所列的部件。 This table shows where these substances may be found in the supply chain of Huawei products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
-
Page 11: Ap Installation
AP4030DN Quick Start Guide Contents AP Installation About This Chapter 2.1 Preparing for Installation 2.2 Unpacking the Equipment 2.3 Determining the Installation Position 2.4 Installing the AP 2.1 Preparing for Installation This section describes safety precautions and tool preparations for AP installation. -
Page 12: Unpacking The Equipment
AP4030DN Quick Start Guide Contents Table 2-1 Tools Phillips screwdriver Torque screwdriver Marker (M4) 3mm/5mm (M3-M6) ESD gloves Utility knife Cable cutter Diagonal pliers RJ45 crimping tool Wire stripper Network cable tester Multimeter Level 2.2 Unpacking the Equipment Before unpacking the carton, ensure that the packing carton is intact and not damaged or soaked. -
Page 13: Determining The Installation Position
There must be at least 200 mm clearance between the cabling end of the AP and the wall. Figure 2-1 shows dimension and Figure 2-2 shows space requirements. Figure 2-1 Dimension of AP4030DN（Unit: mm） 华为专有和保密信息 Issue 01 (2015-02-06) -
Page 14: Installing The Ap
AP4030DN Quick Start Guide Contents Figure 2-2 Mounting an AP（Unit: mm） 2.4 Installing the AP 2.4.1 Wall Mounting Fix the mounting bracket to the wall, adjust the installation position, and use the marker to mark the drilling positions where expansion screws are installed. -
Page 15: Ceiling Mounting
AP4030DN Quick Start Guide Contents Fix the mounting bracket to the wall and use the Phillips screwdriver to fasten three expansion screws into the expansion. Align the mounting screws at the rear of the AP with the mounting holes on the mounting bracket and hang the AP on the bracket. -
Page 16: T-Rail Mounting
AP4030DN Quick Start Guide Contents 1. Remove a ceiling tile, determine locations of mounting holes based on the distance between two installation holes on the mounting bracket, use a hammer drill to drill hole on the ceiling tile, and fix the mounting bracket to the ceiling tile. -
Page 17: Installing The Security Lock
AP4030DN Quick Start Guide Contents bracket, hook the adjustable buckle to the T-rail, and secure the screw on the adjustable buckle to fasten the mounting bracket and T-rail. 2. Hang the AP on the mounting holes by aligning the mounting screws at the rear of the AP with the mounting screws on the bracket and push the AP horizontally to secure the AP. -
Page 18: Connecting Cables
AP4030DN Quick Start Guide Contents You need to purchase the security lock separately. 2.6 Connecting Cables Figure 2-3 and Table 2-2 shows interface and cable connection of AP4030DN。 Figure 2-3 Interfaces of the AP4030DN Table 2-2 Cable Connection Cable Description ... -
Page 19: Powering On The Ap
AP4030DN Quick Start Guide Contents Pay attention to the following points when installing network cables Before connecting an Ethernet cable to the AP, use the cable test tool to check whether the cable is qualified. If the cable is unqualified, replace it. -
Page 20: Logging In To The Ap
Then, you enter the user configuration interface. (The following information is only for reference.) The default user name and password are respectively admin and admin@huawei.com. The password entered in interactive mode is not displayed on the screen. -
Page 21: Logging In To The Ap Using Stelnet
AP4030DN Quick Start Guide 3 Logging In to the AP You can run commands to configure the AP. Enter a question mark (?) whenever you need help. 3.2 Logging In to the AP Using STelnet This section describes how to log in to the AP using STelnet. After logging in to the AP, you can configure the AP using commands. - Page 22 AP4030DN Quick Start Guide 3 Logging In to the AP Figure 3-1 PuTTY Configuration page Step 3 Click Open. Enter the user name and password at the prompt, and press Enter. You have logged in to the device. (The following information is only for reference.) login as: admin Sent username "admin"...
-
Page 23: Logging In To The Ap Using A Web Client
169.254.1.1 and the mask is 255.255.0.0. The web management system provides a default user account, with the user name admin and password admin@huawei.com. You are advised to change the user name and password on your first login. Assign your PC an IP address on the same network segment as the default IP address of the web management system, and connect the PC to the GE interface. - Page 24 AP4030DN Quick Start Guide 4 Caution Caution 4.1 Caution 华为专有和保密信息 Issue 01 (2015-02-06) 版权所有 © 华为技术有限公司...
