Page 1: Quick Start Guide
AP Series Indoor Wireless LAN Access Points Quick Start Guide... - Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
-
Page 3: Intended Audience
Preface This document describes the hardware configuration, installation preparation, installation method, installation procedure, cable connection, and procedure for logging in to the indoor APs. The preface is organized as follows: • Intended Audience • Symbol Conventions • Documentation Obtaining • Technical Support Intended Audience This document is intended for: •... -
Page 4: Technical Support
Huawei customer service center (CSC) for help. • Tel: 4008229999 You can also visit http://enterprise.huawei.com, click Contact Us in the lower area of the page, and select the country to obtain contact information about Huawei local office. -
Page 5: Change History
Change History Changes between document issues are cumulative. Therefore, the latest document issue contains all the changes in previous issues. Change in Issue 01 (2012-10-31) Initial commercial release. -
Page 6: Device Introduction
Device Introduction The Huawei AP series indoor wireless LAN access point provides eight models: AP3010DN-AGN, AP5010DN-AGN, AP5010SN-GN, AP6010DN-AGN, AP6010SN-GN, AP6310SN-GN, AP7110DN-AGN, and AP7110SN-GN. The indoor AP features high reliability, high security, simple network deployment, automatic AC discovery and configuration, and real-time management and maintenance. - Page 7 Device Introduction Table 2 Interfaces on indoor APs AP7110DN-AGN Console ETH/PoE Default DC 12V AP7110SN-GN Console ETH/PoE Default DC 12V Table 3 Interfaces on indoor APs Name Description DC 12V Connected to the power adapter. Default Press and hold down the Reset button for 3 seconds to restore the factory settings and restart the AP.
-
Page 8: Installation Preparations
Installation Preparations 1. Safety Precautions WARNING Only the qualified personnel are permitted to install and remove the device and its accessories. Before installation and operation, read the safety precautions carefully. Take proper measures to prevent injuries and device damage. ... - Page 9 Installation Preparations 3. Device Accessories The following accessories are delivered together with indoor APs: AP6010DN&SN, AP6310SN, AP3010DN, AP5010DN&SN: AP7110DN&SN: sheet metal wall- plastic wall-mounting bracket mounting bracket Expansion screws 4. Installation Tools To install indoor APs, prepare the following tools: Phillips screwdriver Flat-head screwdriver Maker...
-
Page 10: Installing The Ap
Installing the AP 1. Installation Flowchart Figure 1 Flowchart for installing an AP Start Check before installation To a T-rail Against the ceiling Determine the installation location Against the wall Fix the wall-mounting Fix the wall-mounting Fix the wall-mounting bracket to a T-rail bracket against the wall bracket against the ceiling Install the AP... - Page 11 Installing the AP 3. Determining the Installation Position When determining the AP installation position, comply with the following rules: Try to reduce the number of obstacles, such as walls, between the AP and user terminals. Install the AP away from electronic devices that can interfere the radio signal or make noises, such as the microwave oven.
- Page 12 Installing the AP 4. Installing the AP NOTE The AP3010DN-AGN, AP5010DN-AGN, and AP5010SN-GN have plastic wall-mounting bracket delivered with them, so they can only be wall mounted. The AP6010DN-AGN, AP6010SN-GN, AP6310SN-GN, AP7110DN-AGN, and AP7110SN-GN have sheet metal wall-mounting bracket delivered with them, so they can be wall mounted, ceiling mounted, or T-rail mounted indoors.
- Page 13 Installing the AP Against the Ceiling 1. Fix a clip holder at the rear side of the AP with two M3*6 screws. The wall-mounting bracket is fixed at the ceiling, and the AP is hung on the bracket. The clip holder prevents the AP from dropping.
- Page 14 Installing the AP 3. Align the cucurbit holes at the rear side of the AP with four screws on the wall-mounting bracket and secure the AP. To a T-rail 1. Fix a clip holder at the rear side of the AP with two M3*6 screws. For details, see step 1 in Against the Ceiling.
- Page 15 1) Fix the cable of the security lock to a fixed object around. 2) Plug the locking piece into the security keyhole on the device and lock it. 1. Lock hole 2. Security lock 6. Connecting Cables Table 6 Appearance of indoor APs (front view) AP3010DN-AGN AP5010DN-AGN AP5010SN-GN AP6010DN-AGN AP6010SN-GN ETH/PoE...
- Page 16 Installing the AP Table 6 Appearance of indoor APs (front view) AP7110DN-AGN Console ETH/PoE Default DC 12V AP7110SN-GN Console ETH/PoE Default DC 12V Table 7 Cables of indoor APs Cable Description 5 GHz antenna cable Connects to the 5 GHz antenna for transmitting and receiving signals. 2.4 GHz antenna cable Connects to the 2.4 GHz antenna for transmitting and receiving signals.
- Page 17 Installing the AP Table 8 Pin assignment X1 Pin Wire Color X2 Pin White and orange Orange White and green Blue White and blue Green White and brown Brown NOTE The antennas of the AP6310SN-GN used must comply with local laws. ...
- Page 18 Indoor APs can be either powered on by the PoE or DC power supply. Do not frequently power on and off an AP. 2. Indicator Status Table 9 Indicator status of the AP3010DN-AGN, AP5010SN-GN, AP5010DN-AGN, AP6010DN- AGN and AP6010SN-GN Indicator...
- Page 19 Power-on Table 10 Indicator status of the AP6310SN-GN Indicator Information Link Wireless Description Type Steady The device is being started. green Startup status Blinking The system is working properly. green Steady The system fails to load the DRAM or system software. The system is working properly.
- Page 20 Power-on Table 11 Indicator status of the AP7110SN-GN and AP7110DN-AGN Information Link Wireless Description Type Steady The device is being started. green Startup Blinking The system is working properly. status green Steady The system fails to load the DRAM or system software.
-
Page 21: Logging In To The Ap
Logging In to the AP After an AP is powered on, you can log in to the AP using the following methods. 1. Logging In to the AP Through the Console Port 2. Logging In to the AP Using Telnet Logging In to the AP Through the Console Port This section describes how to log in to the AP through the console port. - Page 22 Logging In to the AP Step 4 Click Restore Defaults, select 9600 bit/s from the Bits per second drop-down list box, and click OK, as shown in Figure 1-3. Figure 1-3 Setting communication parameters Step 5 Press Enter on the subsequent dialog boxes until the command line prompt of the user view, such as <Enterprise AP>, is displayed.
- Page 23 Logging In to the AP NOTE Run the exit command to exit from the Telnet window. When the system fails to exit from the Telnet window: If you logged in to the AP from an AC or a switch, press Ctrl+T to return to the AC or switch view. This operation does not affect the AP operation.
- Page 24 Appendix Declaration on Hazardous Substances in Electronic Information Products Hazardous Substances Parts Cr6+ PBDE Mechanical part Board/circuit module Signal cable Cable connector Power adapter Auxiliary equipment O: Indicates that the concentration of the hazardous substance contained in all the homogeneous materials of this part is below the limit requirement of the SJ/T 11363-2006 standard.
-
Page 25: Warranty Card
In any case that is not covered by this limited warranty or should the warranty expire, Huawei shall charge for the service(s) claimed for the products if the product is still remediable.
