Displays2go MNTW803S Installation Manual

Download this manual

Enlarged version

Thank you for choosing our product

This product contains small items that could be a choking hazard if swallowed. Keep

these items away from young children

1.Make sure these instructions are read and completely understood before attempting

installation. If you are unsure of any part of this installation, contact a professional

installer for assistance.

2.The wall or mounting surface must be capable of supporting the combined weight of

the mount and the display; otherwise the structure must be reinforced

3.Safety gear and proper tools must be used. A minimum of two people are required

for this installation. Failure to use safety gear can result in property damage, serious

injury or death.

-8-

Warning

INSTALLATION GUIDE

Item No.:MNTW803S

TV Size Range: 14

Maximum Weight Capacity: 15kg/33lbs

Adjustable angle: 5

Integrated Cable management

CAUTION

This product was designed to be installed on wood stud walls and solid concrete walls.

Before installing make sure the supporting surface will support the combined load of the

equipment and hardware. Never exceed the Maximum Load Capacity. This product is

intended for indoor use only. Use of this product outdoors could lead to product failure or

personal injury.

"～

- ～

Need help?

Do you have a question about the MNTW803S and is the answer not in the manual?

Page 1 INSTALLATION GUIDE Item No.:MNTW803S Item No.:MNTW803S Thank you for choosing our product Thank you for choosing our product "～ " TV Size Range: 14 Maximum Weight Capacity: 15kg/33lbs - ～ ° ° Adjustable angle: 5 Integrated Cable management Warning This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children 1.Make sure these instructions are read and completely understood before attempting...
Page 2 Hardware Kit: Hardware Kit: Part 3-Adjusting display and using cord management Part 3-Adjusting display and using cord management Route cords along articulating arms using cord management clip Articulating arms can be adjusted to position display into desired location. Plastic cover Use allen wrench (F) to tighten and loosen the tension screw.
Page 3 Part 3-Attaching plastic covers to wall plate Part 3-Attaching plastic covers to wall plate Part 1-Attaching TV Plate To Screen Part 1-Attaching TV Plate To Screen Secure plastic covers over wall plate by pushing them toward each other Center TV plate vertically on back of screen. Select the small(A), medium until they lock in place.
Page 4 Part 2a-Wood Stud Mounting Part 2a-Wood Stud Mounting Part 2b-Concrete Wall Mounting Part 2b-Concrete Wall Mounting Use wall plate as a template, make sure it is level, and mark mounting Level wall plate and use wall as a template to mark two holes. Drill two ”...
