Slope Extensions & Spring Plate
Item Quantity Part Number
1 2 9701-0217
2 1 9701-0218
3 1 9701-0219
4 1 9701-0105
5 2 9701-0220
9701-0104
6 1
9701-0246
7 1 9701-0103
4111-0072 — Dec. 2018
© 2018 Systems, LLC
WASHER, FLAT 1" X 18 GAUGE
PIN , COTTER
PIN, SLOPE EXTENSION PIVOT
SPRING MOUNTING PLATE ASSEMBLY
NUT,LOCK 7/16"-14 SERRATED FLANGE
SLOPE EXTENSION
SLOPE EXTENSION WITH ROLLER (OPTIONAL)
CARRIAGE ASSEMBLY KIT (INCLUDES 1,2,3,5,6)
Description
PARTS
37
