OPERATION
Multi-Colored & Outside Light Sequence Charts
Normal Operation
Condition
Ready For Use
Leveler Operating or Restraint
Engaging/Releasing In Progress
Restraint Engaged
Restraint Engage Failure
Emergency Stop Active
*If equipped, Audible Alarm will also be active.
Bypass Mode
Condition
Restraint Engage Failure
(Bypass Mode prompt)
Bypass Mode
Reset Attempted (Leveler in Use)
Reset Attempted (Door Open)
Reset Lights to Normal Mode
Menu & Diagnostics
Condition
Main Menu Active
System Fault Present
Restraint Use Disabled
22
Inside
Red
Amber
Green
Red/Amber, Display Backlight*
Red (solid)*
Inside
Red/Amber, Display Backlight
Green/Amber
(Green/Red on Dock Alert)
Red/Amber, Display Backlight
Green/Amber, Display Backlight
Red, Display Backlight (5 seconds)
Inside
Red (solid)
Red/Amber
Amber
Lights
Outside
Green
Red
Red
Red
Red (solid)
Lights
Outside
Red
Red
Red
Red
Green
Lights
Outside
Red (solid)
Red
None
