Craig CHT985 Owner's Manual

Craig CHT985 Owner's Manual

29 inch stereo sound bar system with digital optical input and bluetooth wireless technology
Hide thumbs

Advertisement

Table of Contents

29 INCH STEREO
29 INCH STEREO
SOUND BAR SYSTEM
SOUND BAR SYSTEM
with Digital Optical Input and
with Digital Optical Input and
Bluetooth
Wireless Technology
®
Bluetooth
Wireless Technology
®
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Model: CHT985
Owner's Manual
Size: 148.5(W) x 210(H)mm (A5)

Advertisement

Table of Contents
loading

Related Manuals for Craig CHT985

Summary of Contents for Craig CHT985

  • Page 1 29 INCH STEREO SOUND BAR SYSTEM SOUND BAR SYSTEM with Digital Optical Input and with Digital Optical Input and Bluetooth Wireless Technology ® Bluetooth Wireless Technology ® Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: CHT985 Size: 148.5(W) x 210(H)mm (A5)

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS FCC Warnings WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS...

  • Page 4: Power Source

    POWER SOURCE 1. Insert the small plug from the supplied AC/DC Adapter to the DC IN Jack on the rear of unit. 2. Connect the AC/DC Adapter to the wall outlet having AC 100-240V~; 50/60Hz. The Red Standby Indicator on the front of unit will illuminate. To the wall outlet DC IN 5.8V,1.5A...

  • Page 5: Mounting To A Wall

    Mounting to a wall 2.1 Mounting to a wooden wall A. Mark the position of the mounting screws on the wall using a pencil. B. Drill the supplied mounting screws directly into the marks that you have made on the wall and leave approx.

  • Page 6: Location Of Controls

    LOCATION OF CONTROLS Front View Rear View DC IN 5.8V,1.5A OPTICAL IN Top View 1. Speakers 7. DC IN Jack 2. Remote Sensor 8. STANDBY/SOURCE Button 3. Indicators (Play/Pause) Button 4. OPTICAL IN Jack (Volume Down/Skip Backward) Button 5. AUX IN 2 Jack (Volume Up/Skip Forward) Button 6.
  • Page 7 LOCATION OF CONTROLS - REMOTE CONTROL (Standby On/Off) Button (Play/Pause) Button (Skip Backward) Button 4. SOURCE Button 5. VOL- (Volume Down) Button (Mute) Button (Skip Forward) Button 8. VOL+ (Volume Up) Button BUTTON CELL INSTALLATION - REMOTE CONTROL First Time Use: Remove and discard the insulation film as illustrated on the right.
  • Page 8 BATTERY PRECAUTIONS: Follow these Battery Precaution when using a battery in this device: 1. Use only the size and type of battery specified. 2. Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment.
  • Page 9 OPERATIONS GENERAL OPERATION: 1. Connected the unit to AC power as previously instructed. The Red Standby Indicator on the front of unit will illuminate. 2. Press and hold the STANDBY/SOURCE Button on the top of unit approximately 2 seconds or press the Button on the Remote Control to power on the unit from Standby mode.
  • Page 10 Control repeatedly to skip tracks. Notes: When the external BT Device searched the unit, our model number "CHT985" will appear on the display of external BT Device. If while pairing you are asked for a code please try "0000" or "1234".
  • Page 11 OPTICAL IN: Listen music from the Optical Out Jack from an external Video Player or Television: 1. Connect one end of the Optical Connection Cable (not included) to the Optical Out Jack on the external Video Player or Television. 2. Connect the other end of the cable to the OPTCAL IN Jack on the rear of unit as illustrated below: DC IN 5.8V,1.5A...
  • Page 12 AUX IN 1: Listen music from RCA output jacks from an external Video/Audio Player such as a Television; DVD Player, VCR … etc. 1. Connect one end of the RCA Connection Cable (not included) to the AUX Out Jacks on the external Video/Audio Player.
  • Page 13 AUX IN 2: Listen music from an external Audio Player such as a MP3 Player, Discman … etc. 1. Connect one end of the Supplied Audio Connection Cable to the Line Out/AUX Out Jack on the external Audio Player. 2. Connect the other end of the cable to the AUX IN 2 Jack on the rear of unit as illustrated below: DC IN 5.8V,1.5A...

  • Page 14: Troubleshooting Guide

    CLEANING: 1. To prevent fire or shock hazard, disconnect your unit from the AC wall outlet when cleaning. 2. The finish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use caution when cleaning and wiping the plastic parts. 3.

  • Page 15: General Specification

    GENERAL SPECIFICATION Power Source..................DC 5.8V,1.5A, Audio Power................3W per Channel (Total 6W, RMS) BT Version............................2.1 Bluetooth effective working range in open area............up to 32 feet Remote effective working range..................up to 16 feet ACCESSORIES 1 x AC/DC Adapter (Input: AC 100-240V~, 50/60Hz, 0.5A Max) (Output: DC 5.8V, 1.5A, 1 x Remote Control, using CR2025 button cell ( Included, already installed )
  • Page 16 Under no circumstance shall Craig be liable for any loss or consequential damage arising out of the use of this product. This warranty gives specific legal rights. However, you may have other rights which may vary from state to state.
