- Page 1 IB Size: 105.5 x 210mm (A5) 32 INCH 32 INCH STEREO SOUND BAR STEREO SOUND BAR with Bluetooth Wireless Technology with Bluetooth Wireless Technology ® ® Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model:CHT939...
- Page 2 FCC Warnings WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 4 1. Insert the small plug from the supplied AC/DC To the wall outlet Adaptor to the DC In Jack on the top of unit. To the AC In Jack 2. Insert the AC/DC Adaptor to the wall outlet having AC 100-240V~; 50/60Hz. To the DC IN jack on NOTES: NOTES:...
- Page 5 2.1 Mounting on the wooden wall You may use 2 pieces screws (Included) 1. Mark the position of the mounting screws on the wall using a pencil. 2. Drill the supplied screws directly into the marks that you have made on the wall and leave approx.
- Page 6 Front View 1. Indicator 3. Speaker 3. Speaker 2.Remote Sensor Top View AUX IN 2 FM ANT DC IN 16V, 1.8A AUX IN 1 TUNE- TUNE+ POWER/ VOL- VOL+ SOURCE AUX IN 2 FM ANT DC IN 16V, 1.8A AUX IN 1 TUNE- TUNE+ POWER/...
- Page 7 TUNE+ TUNE- MO/ST SOURCE VOL- BASS - TREBLE- BASS+ TREBLE+ VOL+ 6. BASS +/- buttons Power ON/OFF (Standby) button (Mute) button 2. TUNE -/ (Skip Backward) button 8. EQ (Equalizer) button 3. TUNE +/ (Skip Forward) button (Play/Pause) button 4. MO/ST (Mono/Stereo) button 10.
-
Page 8: Battery Precautions
- First Time Use Remove and discard the insulation film as figure on the right. - If the battery is consume, replace it as below: 1. Push and slide out the battery holder as figure 1 below. 2. Replace the battery with a new CR2025 button cell as the polarity markings on the rear of the Remote Control. - Page 9 GENERAL OPERATIONS 1. Connect the AC/DC adapter to the unit and wall outlet as the previous procedure. The Red Indicator will light. 2. Press the POWER/SOURCE button on the unit or press the Power button on the remote control to power on the unit from standby mode. The color of the Indicator will turn to correspondence color.
- Page 10 ( For details pairing procedures, please refer to the user's manual of your BT Device.) NOTES: 1. When the external BT Device searched the unit, our model number " CHT939 " will appear on the display of external BT Device. 2. Pairing code "0000" or "1234" may need to enter. Normal operation after paired: 1.
- Page 11 AUX IN 1 : LISTEN TO EXTERNAL AUDIO DEVICES 1. Connect the Headphone/Earphone; Aux out jack or Line out jack from the external audio player (such like MP3 player; Discman … etc) to the AUX IN 1 jack on the top of unit by the supplied Audio Connection Cable as the figure below: Audio Player...
- Page 12 TROUBLESHOOTING GUIDE Check the followings before requesting service SYMPTOM POSSIBLE CAUSE POSSIBLE SOULTION Power AC/DC Adapter Connect the power AC/DC adapter not connected to the unit or wall outlet. No power Press the POWER/SOURCE button on the The unit is in Standby mode unit or button on the Remote Control to turn on the unit from Standby mode.
- Page 13 Power Source................... DC 16V; 1.8A, Radio Coverage..................FM 87.5-108 MHz Impedance of Speakers: ....................8 Ohm, 12W x 2 Loud Speakers Audio Power .................... 10W x 2 (Total 20W) Bluetooth Effective Range in Open Area............Up to 32 feet Remote Effective Range..................Up to 16 feet 1 x AC/DC Adaptor (Input: AC 100-240V~;...
- Page 14 CHT939_WC_E0CL1_B0US...
