- Page 1 32 INCH STEREO 32 INCH STEREO SOUND BAR SYSTEM SOUND BAR SYSTEM with Digital Optical Input and Bluetooth Wireless Technology with Digital Optical Input and Bluetooth Wireless Technology ® ® Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
- Page 2 FCC Warnings WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 4 1. Insert the plug from the supplied AC/DC Adapter to the DC IN Jack on top of the unit. 2. Insert the AC Plug from the supplied AC/DC Adapter to the wall outlet with AC 100-240V~; 50/60Hz. To the wall outlet To the DC IN jack on the top of the unit.
-
Page 5: Mounting To A Wall
Mounting to a wall 2.1 Mounting to a wooden wall 2 pieces screws (Included) A. Mark the position of the mounting screws on the wall using a pencil. B. Drill the supplied screws directly into the marks that you have made on the wall and leave approx. - Page 6 Front View Top View 1. Indicator 8. POWER/SOURCE Button 2. Remote Sensor 9. VOL - (Volume Down) Button 3. Speaker 10. VOL + (Volume Up) Button 4. OPTICAL IN Jack (Play/Pause) Button 5. AUX-IN 1 Jack (Previous) Button 6. AUX-IN 2 Jacks (Next) Button 7.
- Page 7 (Play/Pause) button STANDBY button 2. VOL(Volume) - button (Mute) button 7. VOL(Volume)+button 3. SOURCE button (Next) button (Previous) button T TI E Remove and discard the insulation tab as figure on the right. Replacing Batteries For Remote Control 1. Push and slide out the battery holder as figure 1 below. 2.
- Page 8 TION Follow these precautions when using a battery in this device: 1. se only the si e and type of battery specified. 2. Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment, a reserved battery may cause damage to the device. o not mix different types of batteries together e.g: Al aline and Carbon inc or old batteries with fresh ones.
-
Page 9: General Operations
GENERAL OPERATIONS 1. Connect the AC/DC adapter to the unit and wall outlet. The red indicator will light but unit is OFF and in standby mode. Press and hold the POWER/SOURCE button to turn on the unit. 2. Press the POWER/SOURCE button on the unit or the SOURCE button on the Remote Control repeatedly to switch to Bluetooth, OPTICAL IN, AUX IN 1 or AUX IN 2 mode. -
Page 10: Bluetooth Pairing And Playback
BLUETOOTH PAIRING AND PLAYBACK Bluetooth In first time use or re-pairing to new BT Device, pairing the unit to the external BT Device as follows: 1. Power on the unit as previous procedures. 2. Press the POWER/SOURCE Button on unit or press the SOURCE Button on remote control repeatedly until the indicator turns Blue and blinks. - Page 11 CONNECTION THROUGH OPTICAL 1. Connect the Optical out jack from the external audio Player (such like TV, DVD Player,BD Player …etc.) to the OPTICAL IN jack on the unit by the Optical Connection cable (not supplied) as the figure below: ( For PCM format only ) Top view of the unit TV;...
- Page 12 AUX IN 1 : LISTEN TO EXTERNAL AUDIO DEVICES An external (Auxiliary) audio source (ie.,mobile phone, personal CD player or MP3 player) can be connected to this unit and heard through the speakers. 1. Plug one end of the Aux In cable into Aux In 1 jack of unit. 2.
- Page 13 AUX IN 2 : LISTEN TO TV/DVD/VCR/DVR An external Video/Audio player (such as TV, DVD player, VCR, etc.) can be connected to this unit and heard through the speakers. 1. Plug one side of RCA White and Red cable (included) into the AU IN 2 jacks on the top of unit.
-
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE Check the following before requesting service POSSIBLE CAUSE SYMPTOM POSSIBLE SOLUTION Connect the power AC/DC Adapter No Power Power AC/DC Adapter to the unit or wall outlet not connected Press the POWER/SOURCE button The unit is in standby mode on the unit or button on the remote control to turn on the unit from standby... - Page 15 Power Input................AC 100-240V~; 50/60Hz Power Output................DC9V 1.5A Audio Power..................5W x 2 (Total 10W) Bluetooth Effective Range in Open Area...........Up to 32 feet Remote Effective Range................Up to 16 feet ACCESSORIES 1 x AC/DC Adapter (Input: AC 100-240V~; 50/60Hz; 0.5A) (Output: DC 9V 1500mA, 1 x Remote Control, using CR 2025 button cell ( Included, already installed in remote control )
-
Page 16: Limited Warranty
Under no circumstance shall Craig be liable for any loss or consequential damage arising out of the use of this product. This warranty gives specific legal rights. However, you may have other rights which may vary from state to state.
