hager EG110 Instructions For Use

_________________________________________________________________________
http://waterheatertimer.org/Hagar-timers-and-manuals.html
™ §
1 channel time switch -
daily cycle.
User instruction
pr og
ON au to
nu
ma
OFF
t
re se
r
en te
on
of f
EG110
Working principle : Time setting :
The EG110 is a time switch for the automatic
control of electrical loads.
It is fully programmable with a maximum of 20
program steps.
The front cover is sealable preventing
unauthorised access after completion of
programming.
Warning : at the beginning of use, please
reset the device in order to clear the memory
before programming.
This is achieved by using a pen to push the
on
reset button.
1. Move mode selector to
Presentation :
2. Input time with buttons "+" and "-".
Important :
The clock starts when leaving the time setting mode.
2
Programming :
1
prog 3
auto
OFF
manu
on
reset
enter
off
4 5 6 7
on
Display :
Œ
time

circuit status (ON or OFF)
1. Move mode selector to "prog".
2. Input the switching time with buttons "+" and "-".
Buttons :
3. Input the type of switching with button "on/off"
Ž
Mode selector : to select one of the
(for the first action ON is automatically proposed).
following modes :
4. Enter this program step with button "enter".
time setting
Program additional time settings by repeating
prog programming
steps 2 to 4.
auto running mode
Important :
manu manual override

To activate the program, move mode selector to
"on/off" : chooses whether the circuit
"auto".
is on or off

"+" and "-" : changes settings
‘
Running mode Auto
"enter" : to confirm
’
"reset" This mode is the current displaying mode.
It does not allow any modification.
Move mode selector to "auto".
Display of the time and the state of the channel.
1
To check your program :
1. Move mode selector to "prog".
2. Press the "enter" key repeatedly to display
the different program steps (switching time
and state of the channel ON or OFF).
prog
auto
manu
To modify or delete a program step :
reset
enter
off
on
off
1. Move mode selector to "prog".
2. Press "enter" repeatedly and select the
program step to modify or to delete.
ON
3. Modify :
prog
auto
- switching time with keys "+" or "-"
manu
- state of the channel with key "on/off".
To delete a program step, modify switching
time with keys "+" and "-", until display --:--
(between 23:59 and 00:00).
4. Confirm with the "enter" key.
reset
enter
off
To override the output :
Permanent override :
on
off
1. Move mode selector to "manu".
2. Select the state of the output with key
"on/off".
To switch back to automatic mode, move
mode selector to "auto".
Timed override :
ON
on
enter
off
ON
prog
auto
1. Move mode selector to "manu".
manu
2. Select the state of the output with key
"on/off".
3. Input with key "+" and "-" the override
duration : from 1 to 23 hours by steps of
reset
1 hour.
enter
Then from 1 to 27 days by steps of 1 day.
4. Move mode selector to "auto".
The state indication is flashing. This means a
timed override. Return to the initial program
after the duration.
To cancel the timed override :
ON
on
enter
off
1. Move mode selector to "manu".
2. Press key "-" or "+" until display -h.
3. Move mode selector to "auto" to switch
ON
prog back to automatic mode.
auto
manu
To reset the time switch :
reset
Press "reset" to clear the program.
enter
Technical specifications :
Electrical characteristics :
- supply voltage : 230V +10/-15% 50Hz
- output : 1 changeover contact
μ 16A - 250V AC1.
μ 3A - 250V cos φ = 0,6
1000 W incandescent lighting
prog
auto - power consumption : 1 VA
manu
- protection degree : IP20
- insulation class : II
Functional characteristics :
- accuracy : ± 1sec. / day at 20 °C
reset
- operating reserve : lithium battery,
total of three years.
Environment :
Operating temperature : -10 to +50 °C
Storage temperature : -10 to +50 °C
Connection tunnel terminals :
2
flexible : 0,5 to 2.5 mm
2
rigid : 0,5 to 4 mm
Dimensions : 3 modules (3x17,5mm)
Electrical connections :
L
N
prog
auto
manu
EG110
1 2 3 4 5 6
reset
Warranty
GB
A warranty period of 24 months is offered on hager products,
from date of manufacture, relating to any material of manufac-
turing defect. If any product is found to be defective it must be
returned via the installer and supplier (wholesaler). The warranty
is withdrawn if :
- after inspection by hager quality control dept the device is
found to have been installed in a manner which is contrary to
IEE wiring regulations and accepted practice within the industry at
the time of installation.
- the procedure for the return of goods has not been followed.
Explanation of defect must be included when returning goods.
6E 6129.c
