Ridgeview 48in Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # WSF48RV26DO
# WSF48RV26WA
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2019-06-25
LOT NUMBER:
DATE PURCHASED: /
OR
Rev. 0001-A
/
Advertisement
Related Manuals for Whalen WSF48RV26DO
Summary of Contents for Whalen WSF48RV26DO
- Page 1 LOT NUMBER: DATE PURCHASED: / Ridgeview 48in Fireplace Console Model # WSF48RV26DO # WSF48RV26WA ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Fixed Shelf (Qty. 1) C- Base (Qty. 1) D- Side Panel (Qty. 2) E- Left Partition Panel (Qty.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (4) M3.5 x 12mm Screw (Qty. 22+1 extra) (Qty.
- Page 5 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Base (C), Partition Panels (E and F) and Middle Crossbar (H) with a Phillips screwdriver.
- Page 6 Assembly Instructions 4. Align and attach the Middle Crossbar (H) to the Fixed Shelf (B) by engaging three Cam Locks (1) (Refer to page 2 on Cam Lock system operation supplement). 5. Align and attach the Middle Left Stile (I) to the Left Partition Panel (E) and fasten them into place with four 30 mm Screws (6).
- Page 7 Assembly Instructions 7. Align and attach the Stoppers (10) to the Partition Panels (E and F) with four 12 mm Screws (4). 8. Attach the Fixed Shelf (B) beween the Partition Panels (E and F) by engaging four Cam Locks (1).
- Page 8 Assembly Instructions 9. Using the wood dowels as a guide, firmly press the assembled Partition Panels (E and F) to the Base (C) and fasten them in place with four 50 mm Screws (8). Fully tighten the screws with a Phillips screwdriver.
- Page 9 Assembly Instructions 11. Align the large holes on one Side Panel (D) with the inserted Wood Dowels (3) on the Base (C). Firmly press them together and fasten it in place by engaging two Cam Locks (1). 12. Repeat the same procedure to attach the other Side Panel (D) at the other end. 13.
- Page 10 Assembly Instructions D/E/F 14. Place the Top Panel (A) onto the inserted Wood Dowel (3) properly and fasten it in place by engaging eight Cam Locks (1). I /J 15. Ask for assistance to flip the unit around at its front edge as shown. 16.
- Page 11 Assembly Instructions O/P/Q 17. Now, go back and securely tighten all the cam locks and screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 18. Pick up the Middle Back Panel (P) and align the pre-drilled holes against the upper long edge with the pilot holes on the back rail of Top Panel (A).
- Page 12 Assembly Instructions 22. Pick up one Door (N) and attach the extended hinge arms to the hinge bases installed on the one Side Panel (D). Please follow the steps below to combine the door hinges together. a). Extend both hinge arms of the Door (N) to open position. b).
- Page 13 Assembly Instructions 26. Plug Cam Lock Covers (16) onto the visible Cams Locks to conceal the cams. 27. Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the Base (C) as it may scratch the unit. 28.
- Page 14 Assembly Instructions NOTE: To prevent your TV from tipping, you must install the acrylic TV stopper if you place a flat panel television on the top panel. Otherwise, skip to step 31. 30. Remove the paper backing from the Acrylic Stopper (15), then properly align the acrylic stopper into the cut- out on the acrylic stopper template on the Top Panel (A).
- Page 15 Assembly Instructions NOTE: The doors are shipped with Wood Door Insert. You can keep the doors as they are or interchange with the Door Glass Insert (R) depending on your configuration. 32. To change the configuration, loosen the screws on the inside of Doors (N) and rotate the clips to remove the door insert panel.
- Page 16 Assembly Instructions Tools required (not provided): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8’’ drill bit. 33. Ask for assistance to position the assemble fireplace at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Base (C) to correct the tilting and level the doors.
-
Page 17: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Never use water to clean your furniture as it may cause damage to the finish. -
Page 18: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
