Configure the Drive

Configuring the PowerFlex 527 Drive with
Integrated Motion
This chapter procedures on how to set up Integrated Motion on the EtherNet/IP
network control by using a PowerFlex® 527 Drive.
For information on...
Configure the Drive
Configure the Logix Designer Application Project
Add a PowerFlex 527 Drive
Configure the PowerFlex 527 Drive
Apply Power to the PowerFlex 527 Drive
Test and Tune the Axes – Velocity and Position Control Modes
Before you begin, make sure you know the catalog number for each drive
TIP
component, the Logix module and /or controller used in your motion control
application.
You can include the drive in your Studio 5000 Logix Designer® application by
adding it to a configured EtherNet/IP module or controller and adding it under
the I/O configuration tree. After setting the network configuration, you can view
the drive status information in Studio 5000® software and use it in your
Studio 5000 Logix Designer application.

Set the Network Configuration

You can set the network configuration by using the LCD display and drive
keypad.
1. When the LCD display is showing the Device/Axis state, use the keypad
to navigate to SETTINGS -> NETWORK. Then choose either STATIC
IP or DHCP.
The default setting is STATIC IP.
2. If you chose STATIC IP, then you must configure the following settings:
• IP address
• Gateway
• Subnet mask
Rockwell Automation Publication 520-UM002B-EN-E - December 2017
Chapter
See page...
51
52
57
59
82
83
3
51
