Woodward TQ-125 Linkage Installation And Adjustment

Hide thumbs Also See for TQ-125:

Application Note 01300

(Revision NEW, 9/2000)

Original Instructions

TQ-125

Linkage Installation and Adjustment

Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is

believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly

undertaken.

Table of Contents

Need help?

Do you have a question about the TQ-125 and is the answer not in the manual?

Page 1 TQ-125 Linkage Installation and Adjustment Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly undertaken.
Page 2 Linkage Installation and Adjustment General The linkage kit for the TQ-125 generally consists of the following parts: two rod ends, a terminal lever, a length of threaded rod, and the associated hardware to attach these items between the TQ-125 and the prime mover fuel control.
