- Page 1 X210LW X210 LED Examination Light Operating & Installation Manual QAM.X210.0818.10...
- Page 2 Page 1 of 20...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction ................... 3 1.1 Supported Lights ................. 4 1.2 Technical Drawings ..............5 2. Technical Specifications ..............7 2.1 Serial Numbers and Labelling ............8 3. Operation ..................8 4. Correct Usage ................10 5. Installation ................... 11 5.1 X210LW Standard Wall Mounted version .......... -
Page 4: Introduction
(without the need for secondary filtering) with virtually no heat. Wall and rail mounted versions are available. The X210 LED features a high output-intensity which is variable via an electronic dimmer control located on the rear of the head. This control also acts as an on/off switch. The... -
Page 5: Supported Lights
For further information on our product range and find out more about our company please visit www.daray.co.uk or call 0333 321 0971 or 0800 804 8384. This product was designed & manufactured in Great Britain by: Daray Ltd. Edison House,... -
Page 6: Technical Drawings
1.2 Technical Drawings Page 5 of 20... - Page 7 Page 6 of 20...
-
Page 8: Technical Specifications
2. Technical Specifications Light Source Light Intensity (Lux) @ 0.5m 32,000 Lux ±5% Light Intensity (Lux) @ 0.75m 14,000 Lux ±5% Light Intensity (Lux) @ 1.0m 8,000 Lux ±5% Light Intensity Adjustment Range 10 - 100% Colour Temperature (Kelvin) 4,300K ±500 Colour Rendering Index (CRI) Colour Rendering (R9) @ 0.5m: 120mm... -
Page 9: Serial Numbers And Labelling
2.1 Serial Numbers and Labelling Each X210 LED is allocated a unique serial number located inside the wall mounting box. The power-supply module carries its own identification and serial number. 3. Operation Switch the power ON via the mains socket. If you have the X210LE hard-wired version and you have wired the light to a switch on the wall, ensure you locate the correct switch. - Page 10 Note: If mains power is removed, the intensity will be reset to its brightest setting when mains power is restored. Note: Unplug the power supply if the light is not going to be used for extended periods. The light-head swivels on its mounting flexible arm, and the flexible arm itself also swivels where it fits into its mounting.
-
Page 11: Correct Usage
4. Correct Usage Caution MUST to be taken to ensure correct usage of the light, to preserve all features – in particular the flexible neck (‘gooseneck’) If you need to bend the neck to reposition the light head, keep one hand approximately one third up the neck, and then use your other hand to curve the gooseneck through its entire range, avoiding sharp kinks that will cause irreparable damage. -
Page 12: Installation
5.1 X210LW Standard Wall Mounted version CAUTION: This product must be earthed. Check you have the following items: X210 LED Light – supplied complete with mounting box/PSU IEC Cable Kit including user manual and hex key WARNING: please note that this information is provided for guidance only and that a qualified builder or structural engineer should be consulted if you have any doubt about the suitability of the proposed mounting position. -
Page 13: X210Le Wall Mounted Version (Flush-Fit)
CAUTION: This product must be earthed. Check you have the following items: X210 LED Light – supplied complete with mounting box/PSU Kit including user manual and hex key Note the mounting position advice and warnings offered on page 13 of this manual. -
Page 14: X210Lr Rail Mounted Version
5.3 X210LR Rail Mounted version Check you have the following items: X210 LED Light – supplied complete with mounting box/PSU X210 Rail Mount Kit accessory Kit including user manual and hex key NOTE: Rail not supplied – if required, order code XRAIL If you are installing the XRAIL: ... -
Page 15: Fuse Replacement
6. Fuse Replacement CAUTION: Fuses normally blow for a reason. Investigate likely faults before changing fuses. CAUTION: Isolate the unit from the mains before accessing the fuses. Both the live and neutral mains inputs are fused. The fuses are contained in a holder which is part of the IEC inlet mounted on the rear panel of the mobile base. -
Page 16: Maintenance
The proposed maintenance is only a suggestion. Depending on the use of the product and the operating environment, this may need to be revised more often. DO NOT ATTEMPT ANY FIXES BEFORE CONSULTING DARAY. If you cannot resolve a problem then please contact our helpline on 0800 878 9864 or email support@daray.co.uk... -
Page 17: Product Cleaning & Care Guidelines
Acetone-based cleaners (e.g. nail polish remover, Goo-off™) MEK (Methyl Ethyl Ketone) If you are unsure whether you are using the correct cleaning fluids on your DARAY equipment, please feel free to get in touch with us for advice. Page 16 of 20... -
Page 18: Safety Precautions
If there is damage to the power cable or if exposed wire is visible DO NOT USE 8. Spare Parts CAUTION: Use only genuine ‘DARAY’ replacement lamps as other types may seriously impair the optical performance of the product. ITEM NO PART NAME... -
Page 19: Warranty Information
DARAY Ltd, please read the following information carefully. The DARAY Ltd returns policy provides guidance on when you can return goods we have supplied, and what you can expect from us once you do. To see our detailed returns policy and procedure visit www.daray.co.uk/returns... -
Page 20: Warranty Details
Failure to use or install the product in accordance with the manufacturer’s instructions. 5. Nothing in this warranty shall have the effect of restricting or excluding the liability of Daray in respect of: a) Death and personal injury caused by the negligence of Daray, or for fraud;... - Page 21 Service Notes Page 20 of 20...
- Page 22 Page 21 of 20...
- Page 23 Page 22 of 20...
- Page 24 DARAY Ltd. Edison House Robian Way Swadlincote Derbyshire United Kingdom DE11 9DH +44 (0)800 878 9864 +44 (0)333 321 0973 sales@daray.co.uk www.daray.co.uk...
