OWNER’S MANUAL Power Inverter PID-750 Converts DC Battery Power to AC Household Power Includes Battery Cables CAUTION: Read all Safety Rules and Operating Instructions, and follow them with each use of this product. Schumacher Electric Corporation Mount Prospect, IL 60056 U.S.A.
IMPORTANT SAFETY INSTRUCTIONS Save These Instructions Before using your PID-750, read and understand this Owner’s Manual. • Keep the inverter well ventilated in order to properly dis- perse heat generated while it is in use. Make sure there are several inches of clearance around the top and sides and do not block the slots of the inverter.
Page 4
BEFORE USING PID-750 POWER INvERTER It is important to know the continuous wattage of the device you plan to use with the inverter. The PID-750 must be used with devices drawing 750 watts or less. If the wattage is not marked on the device, an estimate can be made by multiplying the AC input current (Amps) by the AC voltage (110V).
Page 5
Make sure the device you are using is compatible with a modified sine wave inverter. OPERATING INSTRUCTIONS Connecting to a 12 volt Battery: The PID-750 battery clamps allow quick hook-up to a 12V battery. Make sure the PID-750 and the device(s) are turned OFF. 1. Unscrew the positive (red) and negative (black) plastic connector knobs from the back of the inverter.
6. Turn the device ON. 7. To disconnect the PID-750, reverse the above steps. NOTE: If there is a short circuit or power surge in the device, the alarm will sound. To turn off the alarm, press the button. Cycle inverter power OFF and ON. If problem persists, use a larger inverter or a smaller device.
Device Type Cell Phones, MP 3 players, Camcorders Portable Work Light CD/DVD Player Clock Radio Laptop Stereo System Game Console (Xbox) 12" 3 Speed Fan 13" Color TV/VCR Combo Blender 25" Color TV PC & Monitor 3/8" Drill USAGE ExAMPLES Estimated Wattage 40–60 watts 30–100 watts 10 watts...
The LED readouts identify the current status of the PID-750. vOLTAGE IN: Voltage of vehicle’s battery or Portable Power jump starter/DC power source. vOLTAGE OUT: Voltage supplied to device through AC receptacle. POWER OUT: Power or wattage supplied to device plugged into the inverter.
PROBLEM: Alarm is On Reason/Solution 1. Display shows mands too much surge power. Cycle inverter power OFF and ON. If problem persists, use a larger inverter or a smaller device. Remove defective device. See warranty and call Customer Service 800-621-5485 (Hours: 7 a.m. – 4:30 p.m. CST). 2. Display shows Recharge/replace low battery. 3.
Page 10
Inverter will automatically reset after cooling. PROBLEM: Inverter Does Not Turn On Reason/Solution 1. Poor contact at terminals. Unplug and reinsert PID-750. 2. Fuse is blown. A blown fuse is usually caused by reverse polar- ity or a short circuit within the inverter. To replace,...
SPECIFICATIONS Maximum Continuous Power ... 750 Watts Surge Capacity (Output Wattage) ... 1500 Watts No Load Current Draw ... <.50 Amps Wave Form ... Modified Sine Wave Input Voltage Range... 11 – 15.5V DC Low Battery Alarm ... 10.7V – 11.3V DC Output Voltage ... 110V – 125V AC Low Battery Shutdown ...10.2V –...
Page 14
MANUAL DEL DUEÑO Inversor de Potencia PID-750 Convierte Potencia de Batería CC en Potencia Doméstica CA Incluye y Cables de Batería PRECAUCIÓN: Lea todos los Reglamentos de Seguridad e Instrucciones de Operación y sígalos en cada uso de este producto.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD Guarde Estas Instrucciones Antes de usar su PID-750, lea y entienda este Manual del Dueño. • Mantenga el inversor bien ventilado para dispersar debida- mente el calor generado mientras esté en uso. Asegúrese de que haya varias pulgadas de espacio alrededor de la tapa y los lados del inversor.
Page 17
ANTES DE USAR EL INVERSOR PID-750 Es importante saber el vataje continuo del dispositivo que se piensa usar con el inversor. El PID-750 tiene que usarse con dispositivos que requieren 750 vatios o menos. Si el vataje no está marcado en el dispositivo, se puede hacer un cálculo multiplicando la corriente de entrada CA...
INSTRUCCIONES DE OPERACIÓN Para conectar a una batería de 12 voltios: Las pinzas con cables del PID-750 permiten conexión rápida con una batería de 12 voltios. Asegúrese que el PID-750 y los dispositivos estén apagados. 1. Desentornille la perilla conectora plástica positiva (roja) y la negativa (negra) del dorso del inversor.
Page 19
Ponga el inversor en ON. 6. Ponga el dispositivo en ON. 7. Para desconectar el PID-750, invierta los pasos anteriores. NOTA: Si hay cortocircuito o exceso de potencia en el dispositivo, la alarma suena. Para apagar la alarma, ponga el botón.
10 minutos cada 2 a 3 horas para recargar la batería. Si bien el PID-750 recibe amperaje muy bajo cuando no está en uso, debe quedar desenchu- fado para evitar desgaste a la batería.
Page 21
TV a Colores 25" PC y Pantalla Taladradora 3/8" Las lecturas por LED identifican el estado actual del PID-750. VOLTAGE IN: El voltaje de la batería del vehículo o del ar- ranque inmediato Portable Power/fuente de potencia CC. VOLTAGE OUT: El voltaje proporcionado al dispositivo mediante el receptáculo CA.
– El inversor está sobrecalentado y automáticamente se apaga por un período de 1-3 minutos para enfriarse. Asegúrese de que el inversor esté bien ventilado. Se reenciende automáticamente después de enfriarse. Lo b – El voltaje de la batería del vehículo es menos de 10.5 voltios.
Page 23
3. La pantalla muestra Voltaje entre 10.5 y 11.0 volt- ios. La batería de 12 Voltios está baja. Recargue/reemplace la batería baja. El Inversor reenciende automáticamente después de que el voltaje de la batería llegue a 10.5 voltios. 4. La pantalla muestra muy alto.
Page 24
PROBLEMA: El Inversor No se Enciende. Causa/Solución 1. Mal contacto en los terminales. Desenchufe y reinserte el Inversor de PID-750. 2. El fusible se quema. Un fusible quemado es normalmente causado por polaridad inversa o cortocircuito dentro del inver- sor. Para reemplazarlo, póngase en contacto con un écnico de servicio calificado quien hará diag-...
ESPECIFICACIONES Potencia Continua Máxima ...750 Vatios Capacidad de Sobretensión (Potencia Pico) ...1500 Vatios Requisito de Corriente sin Carga ... <.50 Amps Forma de Onda ... Onda Sinusoidal Modificada Rango de Voltaje de Entrada ... 11 – 15,5V CC Alarma de Batería Baja ... 10,7V – 11,3V CC Voltaje de Salida ...
Schumacher Electric garantiza que su inversor está libre de defec- tos en materiales o mano de obra, exceptuando el abuso o mal uso, por el período de dos años desde la fecha de venta al usuario original o comprador consumidor. Si su inversor no funciona bien o falla durante el período de la garantía de 24 meses, debido a...
Page 27
o la exclusión o limitación de daños incidentales o consecuentes, de modo que las limitaciones o exclusiones anteriores quizás no se apliquen a usted. Esta garantía le concede derechos legales específicos y usted puede también tener otros derechos que varían de estado en estado.
