Product Information
Product Information
INGLESE
Language
Nr.
216
Date
4/2013
Subject
GS 35 C - GS 350 C
GS 35 C (EURO 1) - GS 350 C (EURO 2)
The new GS 35 C (EURO 1) and GS 350 C(EURO 2) chain saws are powerful 38.9 cc chain saws capable of developing
2.0 HP / 1.5 kW. Targeted at the entry-level user, they incorporate special technical solutions which enhance their
quality, cutting performance and compliance with anti-pollution legislation.
The result of in-depth research aimed at understanding the real needs of the target user, these machines deliver
high-tech solutions, outstanding cutting performance and simple operation at an affordable price.
User-friendly control is assured by numerous details, including - icons on the engine cover showing the ope-
rations to perform for quick and safe starting - primer device positioned in full view near to the starting handle
- ON-OFF switch, choke and half-throttle control incorporated into a single multifunction lever, for practical and
simple operation - transparent oil and mix reservoir for immediate display of the level - chain brake lever with
2 fixing points.
The new engines underline the technological credentials of the machine and are designed to reduce emissions
of noise and unburned hydrocarbons (HC+NOx). They ensure low running costs and respect for the environment,
particularly in the GS 350 C (EURO 2) version with catalytic muffler.
NEW CHAINSAWS
Mod. GS 350 C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Oleo-Mac Om
Summary of Contents for Oleo-Mac Om
- Page 1 Product Information Product Information INGLESE Language Date 4/2013 Subject GS 35 C - GS 350 C NEW CHAINSAWS GS 35 C (EURO 1) - GS 350 C (EURO 2) Mod. GS 350 C The new GS 35 C (EURO 1) and GS 350 C(EURO 2) chain saws are powerful 38.9 cc chain saws capable of developing 2.0 HP / 1.5 kW.
- Page 2 PERFORMANCE AND ENGINEERING SOLUTIONS Fig. 1 • 38.9 HP 2-stroke engine available in the Euro 1 version (GS 35 C) and the Euro 2 version with catalytic muffler (GS 350 C). • Nickel-plated cylinder, aluminium breech, crankshaft 3 sec- tions, forged machined steel connecting rod and shaft, big...
-
Page 3: Ease Of Use
EASE OF USE Fig. 5 • The illustrated step-by-step start-up instructions ensure quick and safe starting, even for less expert users (Fig. 5). Fig. 6 • Primer device positioned in full view on the engine cover: facili- tates starting from cold, after refuelling or following lengthy idle periods (Fig. - Page 4 COMFORT Fig. 9 • Anti-vibration system using 3 spring dampers and 3 rub- ber stops: significantly isolates the operator from engine vibra- tion, for greater comfort during use (Fig. 9). Fig. 10 • New starter handle design: for more comfortable starting of the machine (Fig.
- Page 5 EASE OF MAINTENANCE Fig. 13 • Filter cover built into engine cover: allows inspection and maintenance by removing the 3 fixing screws. (Fig. 13). Fig. 14 • Clutch”ON BOARD”, assembly secured to shaft using circlip: re- duces the risk of blockage and simplifies routine maintenance operations (Fig.
-
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL GS 35 C GS 350 C ENGINE TYPE Emak 2-stroke (EURO I) Emak 2-stroke (EURO 2) with catalyst DISPLACEMENT 38.9 BORE x STROKE mm x mm 40 X 31 MAXIMUM POWER OUTPUT HP/kW (rpm) 2.0 / 1.48 (9000) MAXIMUM TORQUE Nm (rpm) 2.15 (6500) - Page 7 It's an Emak S.p.A. trademark Member of the Yama Group Via E. Fermi, 4 • 42011 Bagnolo in Piano (Reggio Emilia) Italy Tel. +39 0522 956611 • Fax +39 0522 951555 venditeitalia@oleomac.it • www.oleomac.it...
