- Page 1 Cactus Technologies, Limited OEM Grade -245S series mSATA SSD Product Manual May 2, 2018 www.cactus-tech.com...
- Page 2 Users of Cactus Technologies ® products for such unintended and unauthorized applications shall assume all risk of such use and shall indemnify and hold Cactus Technologies ® and its officers, employees, subsidiaries, affiliates and distributors harmless against all claims, costs, damages,...
-
Page 3: Table Of Contents
6.ATA Command Description............................20 6.1.ATA Command Set............................20 7. S.M.A.R.T. Feature Set.............................21 7.1.S.M.A.R.T Data Structure........................21 7.2.S.M.A.R.T Attributes..........................22 Appendix A. Ordering Information..........................24 Appendix B.Technical Support Services........................25 Appendix C.Cactus Technologies ® Worldwide Sales Offices..................26 Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... - Page 4 Cactus Technologies, Limited Appendix D.Limited Warranty............................27 Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
-
Page 5: Introduction To Cactus Technologies Oem Grade -245S Series Msata Ssd Products
ECC, defect handling and diagnostics, power management, and clock control. The controller’s firmware is upgradeable, thus allowing feature enhancements and firmware updates while keeping the BOM stable. Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 6: Supported Standards
In the extremely rare case where a read error does occur, the drive has sophisticated ECC to recover the data. These defect and error management systems, coupled with the solid-state construction, give Cactus Technologies ® OEM mSATA SSDs unparalleled reliability. Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 7: Power Supply Requirements
® mSATA SSD DC Input Voltage 3.3V ±5% (VCC) 100 mV max. ripple (p-p) (Maximum Average Idle: 100 mA Value) Reading: 480 mA See Notes. Writing: 645 mA Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 8: System Performance
Note: estimated TBW assumes workload consisting of mostly large block writes; estimated TBW will be significantly reduced for workloads consisting mostly of random, small block writes. 2.5. Physical Specifications The following sections provide the physical specifications for Cactus Technologies ® mSATA SSD products. -
Page 9: Msata Ssd Physical Specifications
Cactus Technologies, Limited 2.5.1. mSATA SSD Physical Specifications 2-1. 2.5” SSD Dimensions Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... - Page 10 Cactus Technologies, Limited Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
- Page 11 Cactus Technologies, Limited Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
- Page 12 Cactus Technologies, Limited Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
- Page 13 Cactus Technologies, Limited Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
-
Page 14: Interface Description
Cactus Technologies, Limited 3.Interface Description The following sections provide detailed information on the Cactus Technologies ® OEM mSATA SSD interface. 3.1. mSATA SSD Pin Assignments and Pin Type The signal/pin assignments and descriptions are listed in Table 3-5. Table 3-5. mSATA SSD Pin Assignments and Pin Type... -
Page 15: Electrical Specifications
4.Electrical Specifications The following table defines all D.C. Characteristics for the mSATA SSD products. Unless otherwise stated, conditions are: Vcc = 3.3V ± 5% Ta = -40°C to 85°C Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 16: Absolute Maximum Ratings
The Serial ATA interface does not support Primary/Secondary or Master/Slave configurations. Each SATA channel supports only one SATA device, with the register selection as defined by the ATA standard. Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 17: Ata Task File Definitions
Sector Number (LBA 7-0) Register This register contains the starting sector number or bits 7-0 of the Logical Block Address (LBA) for any SSD data access for the subsequent command. Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 18: Cylinder Low (Lba 15-8) Register
These registers return the status when read by the host. Reading the Status register does clear a pending interrupt while reading the Auxiliary Status register does not. The meaning of the status bits are described as follows: BUSY CORR Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 19: Device Control Register
I/O space because of potential conflicts on Bit 7. The bits are defined as follows: -WTG -HS3 -HS2 -HS1 -HS0 -nDS1 -nDS0 Bit 7 This bit is unknown. Implementation Note: Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 20: Ata Command Description
Bit 1 (-nDS1) This bit is 0 when drive 1 is active and selected. Bit 0 (-nDS0) This bit is 0 when the drive 0 is active and selected. 6.ATA Command Description This section defines the ATA command set supported by Cactus Technologies ® mSATA SSDs. -
Page 21: Feature Set
Save Attribute Values Disable SMART operations Execute OFF-LINE Immediate Return Status 7.1. S.M.A.R.T Data Structure The Read Data commands returns 512 bytes of data in the following structure: Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 22: Attributes
Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 Byte 10 Byte 11 Read error rate Reallocated sectors count Power on hours Power cycle count Uncorrectable sector count when read/write Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... - Page 23 SMART utilities may report this attribute as 'Percent Remaining Life' or 'SATA Phy Error Count'; this is not valid for -245S series pSLC products, please ignore it. Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2...
-
Page 24: Appendix A. Ordering Information
128G ------------ 128GB Where: is temperature grade: blank ------------ standard I ------------------- extended Example: (1) 8GB mSATA SSD ----------------------------------------------------------- KD8GF-245SM1 (2) 8GB mSATA SSD extended temp. ------------------------------------ KD8GFI-245SM1 Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 25: Appendix B.technical Support Services
Cactus Technologies, Limited Appendix B.Technical Support Services B.1.Direct Cactus Technologies ® Technical Support Email: tech@cactus-tech.com Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... -
Page 26: Appendix C.cactus Technologies ® Worldwide Sales Offices
Cactus Technologies, Limited ® Appendix C.Cactus Technologies Worldwide Sales Offices Email: sales@cactus-tech.com Email: americas@cactus-tech.com Cactus Technologies Limited OEM Grade -245S Series mSATA SSD Product Manual v1.2... - Page 27 ® OEM Grade Flash Storage Products. Cactus Technologies ® , at its sole option, will repair, replace or refund the purchase price of the defective product. Cactus Technologies ® guarantees our products meet all specifications detailed in our product manuals. Although Cactus Technologies ®...
- Page 28 ® Customer Service department (tech@cactus-tech.com) with the following information: product model number and description, nature of defect, conditions of use, proof of purchase and purchase date. If approved, Cactus Technologies ® will issue a Return Material Authorization or Product Repair Authorization number and instructions to ship the product back to us for service.
