- Page 1 Cactus Technologies, Limited Industrial 3D TLC -270PM7 series M.2 SSD Product Manual August 14, 2023 www.cactus-tech.com...
- Page 2 Users of Cactus Technologies ® products for such unintended and unauthorized applications shall assume all risk of such use and shall indemnify and hold Cactus Technologies ® and its officers, employees, subsidiaries, affiliates and distributors harmless against all claims, costs, damages,...
-
Page 3: Table Of Contents
Cactus Technologies, Limited 1.Introduction to Cactus Technologies® Industrial 3D TLC Grade -270PM7 Series M.2 SSD Products ....5 1.1.Supported Standards...........................6 1.2.Product Features............................6 1.2.1.Host and Technology Independence....................6 1.2.2.Defect and Error Management......................6 1.2.3.Power Supply Requirements......................7 2.Product Specifications..............................7 2.1.System Environmental Specifications......................7 2.2.System Power Requirements........................7 2.3.System Performance...........................8... - Page 4 Cactus Technologies, Limited 8.Device Features................................26 9. Ordering Information..............................30 Appendix A.Technical Support Services........................31 Appendix B.Cactus Technologies® Worldwide Sales Offices..................32 Appendix C.Limited Warranty............................1 Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
-
Page 5: Introduction To Cactus Technologies® Industrial 3D Tlc Grade -270Pm7 Series M.2 Ssd Products
Industrial 3D TLC M.2 PCIe SSD is a high capacity solid-state flash memory product that complies with the PCI Express base standard v3.1 and NVM Express v1.3 standard. It is a PCIe device that operates in native NVMe mode. Cactus Technologies ®... -
Page 6: Supported Standards
Also, with the intelligent on-board controller, the host system software will not require changing as new flash memory evolves. Thus, systems that support the Cactus Technologies ®... -
Page 7: Power Supply Requirements
100 mV max. ripple (p-p) 3.3V ±5% (Maximum Average Value) Idle: 210mA 210mA 210mA 210mA See Notes. Read: 1100mA 1210mA 1200mA 1250mA Write 880mA 1060mA 1210mA 1260mA Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 8: System Performance
15MB/s 24MB/s 16MB/s depth=32 Random 4K read IOPS 26000 47000 76000 75000 Queue depth=32 Random 4K write IOPS 1700 3600 5900 3800 Queue depth=32 2.4. System Reliability Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 9: Physical Specifications
Data retention requirements are not considered in this estimation. 2.5. Physical Specifications The following sections provide the physical specifications for Cactus Technologies ® Industrial 3D TLC M.2 SSD products. -
Page 10: 2280 Ssd Physical Specifications
M.2 2280 SSD Physical Specifications Note: the top side thickness is without the heat spreader. Heat spreader adds approximately 0.4mm to the thickness. 2-1. M.2 2280 SSD Dimensions Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 11: Interface Description
Cactus Technologies, Limited 2-2. M.2 2280 SSD Heat Sink Dimensions (for extended temp. version) 3.Interface Description The following sections provide detailed information on the Cactus Technologies ® Industrial 3D TLC M.2 SSD interface. 3.1. M.2 SSD Pin Assignments and Pin Type The signal/pin assignments and descriptions are listed in Table 3-5. - Page 12 PCIe Reference Clock PEWAKE# Not used REFCLKp MFG_1 Reserved for manufacturer MFG_2 Reserved for manufacture M Key M Key SUSCLK 32kHz clock input; not used 3.3V 3.3V Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
-
Page 13: Electrical Specifications
M.2 SSD products conforms to all AC timing requirements as specified in the PCI Express base specifications. Please refer to that document for details of AC timing for all operation modes of the device. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 14: Pci Configuration
Cardbus CIS Pointer: N/A Subsystem ID: Subsystem Vendor 2263h ID: 1E3Ah Expansion ROM Base Address Reserved Capabilitie s Pointer: Reserved Max Lat: Min Gnt: Interrupt Interrupt Line Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 15: Pci Express Capabilities
Complete, Equalization Phase 1 Successful, Equalization Phase 2 Successful, Equalization Phase 3 Successful, Link Equalization Request 64-bit address capable; Per vector masking supported MSI-X MSI-X table size: 16; Per Vector Mask Bit Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 16: Nvm Express Registers
Lane Set by host, one register per lane Equalization Control 5.2. NVM Express Registers The following sections describe the NVMe register contents of Cactus Technologies ® Industrial 3D TLC grade M.2 SSD. 5.2.1. Controller Capabilities (CAP) This 64-bit register indicates basic capabilities of the controller. -
Page 17: Version (Vs)
15:0 MQES 3FFFh Max. Queue Entries Supported for I/O queues: 16384 5.2.2. Version (VS) This 32-bit register indicates the NVMe Specification supported by the device. Cactus Technologies ® Industrial 3D TLC grade M.2 SSD supports NVMe Specification v1.3. Bit(s) Name... -
Page 18: Interrupt Mask Clear (Intmc)
This 32-bit register provides status information of the drive controller. Bit(s) Name Value Description 31:6 Reserved Process Paused. When set to ‘1’, it indicates the drive controller has stopped processing commands Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 19: Nvm Subsystem Reset (Nssr)
Admin Submission Queue Size: 32 5.2.9. Admin Submission Queue Base Address (ASQ) This 64-bit register is written by the host to set the Admin Submission Queue Base Address. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 20: Admin Completion Queue Base Address (Acq)
PRP SGL Support. All PRP and SGL lists must be placed in host memory. Completion Queue Support. All Completion Queues must be placed in host memory. Submission Queue Support. All Submission Queues must be placed in host memory. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 21: Boot Partition Info (Bpinfo)
The returned structure is 4096 bytes and the following section describes the contents of this structure in Cactus Technologies ® Industrial 3D TLC grade M.2 SSDs. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 22: Identify Controller Data Struture
APSTA Autonomous Power State Transition Attributes: Autonomous Power State Transition supported 267:266 WCTEMP Warning Composite Temperature Threshold: 348K (75C) 269:268 CCTEMP Critical Compostie Temperature Threshold: 353K (80C) Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... - Page 23 535:534 Reserved 539:536 SGLS SGL Support: not supported 767:540 Reserved 1023:768 SUBNQN NVM Subsystem NVMe Qualified Name: not applicable Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
- Page 24 Relative Read Throughput (RRT): 3 Relative Read Latency (RRL): 3 Relative Write Throughput (RWT): 3 Relative Write Latency (RWL): 3 Idle Power (IDLP): - Active Power (ACTP): - Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
-
Page 25: Smart Reporting
The amount of time the drive is busy processing I/O commands; the unit is in minutes Power Cycles Number of power cycles Power On Hours Number of Power On Hours Unsafe Shutdowns The number of power loss without prior Shutdown notification. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 26: Device Features
Bit [2:0]: Arbitration Burst (AB). This indicates the max. number of commands the controller can launch at one time from a Submission Queue. Value specified is 2^n. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... - Page 27 Volatile Write Cache Enable (WCE). This field reflects Cache the state of Volatile Write Cache as set by the host. Bit[31:1]: Reserved Bit[0]: If set, Volatile Write Cache is enabled. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
- Page 28 Bit[7:0]: SMART Critical Warning. If set, each corresponding critical warning bit in SMART Log will trigger notice to the host. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
- Page 29 Bit[0]: Autonomous Power State Transition Enable (ASPTE). If cleared, Autonomous Power State Transition is disbaled. If set, transition attributes for each power state is returned in the Autonomous Power State Transition Structure. Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4...
-
Page 30: Ordering Information
Blank --------------- standard temp. (comes with heat spreader) I ---------------------- extended temp. (comes with heat sink) Example: KD128GF-270PM7 --------------------------------------- 128G standard temp. SSD KD256GFI-270PM7 -------------------------------------- 256G extended temp. SSD Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 31: Appendix A.technical Support Services
Cactus Technologies, Limited Appendix A.Technical Support Services A.1.Direct Cactus Technologies ® Technical Support Email: tech@cactus-tech.com Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 32: Appendix B.cactus Technologies® Worldwide Sales Offices
Cactus Technologies, Limited ® Appendix B.Cactus Technologies Worldwide Sales Offices Email: sales@cactus-tech.com Email: americas@cactus-tech.com Cactus Technologies Limited Industrial 3D TLC -270PM7 Series M.2 SSD Product Manual v1.4... -
Page 33: Appendix C.limited Warranty
TBW is exceeded, whichever occurs first. This express warranty is extended by Cactus Technologies ® Limited to customers of our products. II. GENERAL PROVISIONS This warranty sets forth the full extent of Cactus Technologies ® responsibilities regarding the Cactus Technologies ®... - Page 34 ® Customer Service department (tech@cactus-tech.com) with the following information: product model number and description, nature of defect, conditions of use, proof of purchase and purchase date. If approved, Cactus Technologies ® will issue a Return Material Authorization or Product Repair Authorization number and instructions to ship the product back to us for service.
