- Page 1 Cactus Technologies, Limited Industrial Grade -910S/910S-P1 series Product Manual September 4, 2018...
- Page 2 Users of Cactus Technologies ® products for such unintended and unauthorized applications shall assume all risk of such use and shall indemnify and hold Cactus Technologies ® and its officers, employees, subsidiaries, affiliates and distributors harmless against all claims, costs, damages,...
-
Page 3: Table Of Contents
Cactus Technologies, Limited Table of Contents 1.Introduction to Cactus Technologies ® Industrial Grade -910S/910S-P1 Series SSD Products........5 1.1.Supported Standards...........................6 1.2.Product Features............................6 1.2.1.Host and Technology Independence....................6 1.2.2.Defect and Error Management......................6 1.2.3.Power Supply Requirements......................7 2.Product Specifications..............................7 2.1.System Environmental Specifications......................7 2.2.System Power Requirements........................7 2.3.System Performance...........................8... - Page 4 Cactus Technologies, Limited 6.6.3.Self-test Log Structure........................27 7.Additional Features for -910S-P1..........................27 7.1.Jumper Triggered Full Disk Erase......................27 7.2.AES256 Hardware Encyrption.........................28 7.2.1.Vendor Specific Command......................28 7.2.2.Enabling and Using Encryption......................30 Appendix A. Ordering Information..........................32 Appendix B.Technical Support Services........................33 Appendix C.Cactus Technologies ® Worldwide Sales Offices..................34 Appendix D.Limited Warranty............................35...
-
Page 5: Introduction To Cactus Technologies Industrial Grade -910S/910S-P1 Series Ssd Products
-910S/910S-P1 series SSD is a high capacity solid-state flash memory product that complies with the Serial ATA 3.0 standard and is functionally compatible with a SATA hard disk drive. Cactus Technologies ® -910S/910S-P1 series SSD provide up to 640GB of formatted storage capacity. -
Page 6: Supported Standards
The defect management is completely transparent to the host and does not consume any user data space. The soft error rate for Cactus Technologies ® Industrial SSD is much lower than that of magnetic disk drives. -
Page 7: Power Supply Requirements
Cactus Technologies, Limited These defect and error management systems, coupled with the solid-state construction, give Cactus Technologies ® Industrial SSDs unparalleled reliability. 1.2.3. Power Supply Requirements Cactus Technologies ® Industrial SSD operates at a voltage range of 5.0 volts ± 10%. -
Page 8: System Performance
Data Reliability < 1 non-recoverable error in 10 14 bits READ Endurance: > 2,000,000 erase/program cycles per logical sector 2.5. Physical Specifications The following sections provide the physical specifications for Cactus Technologies ® Industrial SSD products. Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual... -
Page 9: 2.5" Ssd Physical Specifications
Cactus Technologies, Limited 2.5.1. 2.5” SSD Physical Specifications Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual v2.2... - Page 10 Cactus Technologies, Limited Figure 2-1. 910S 2.5” SSD Dimensions Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual v2.2...
- Page 11 Cactus Technologies, Limited Figure 2-2. 910S-P1 2.5” SSD Dimensions Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual v2.2...
-
Page 12: Interface Description
Cactus Technologies, Limited 3.Interface Description The following sections provide detailed information on the Cactus Technologies ® Industrial SSD interface. 3.1. SSD Pin Assignments and Pin Type Cactus Technologies ® SSD uses industry standard 7+12 SATA connector. The signal/pin assignments and descriptions are listed in Table 3-5. -
Page 13: Dc Characteristics
Cactus Technologies, Limited 3.2.2. DC Characteristics Parameter Symbol Units Input Voltage -0.5 Vcc + 0.5 Output Voltage Vout -0.3 Vcc + 0.3 Input Leakage Current Output Leakage Current Input/Output Capacitance Operating Current Sleep Mode Active 3.2.3. AC Characteristics Cactus Technologies ®... -
Page 14: Error Register
Cactus Technologies, Limited 4.1.2. Error Register This register contains additional information about the source of an error when an error is indicated in bit 0 of the Status register. The bits are defined as follows: IDNF ABRT AMNF Bit 7 (BBK) This bit is set when a Bad Block is detected. -
Page 15: Drive/Head (Lba 27-24) Register
Cactus Technologies, Limited 4.1.8. Drive/Head (LBA 27-24) Register The Drive/Head register is used to select the drive and head. It is also used to select LBA addressing instead of cylinder/head/sector addressing. The bits are defined as follows: Bit 7 This bit is set to 1. -
Page 16: Device Control Register
Cactus Technologies, Limited 4.1.10. Device Control Register This register is used to control the drive interrupt request and to issue an ATA soft reset to the drive. The bits are defined as follows: SW Rst -IEn Bit 7 This bit is used in 48-bit addressing mode. When cleared, the host can read the most recently written values of the Sector Count,Drive/Head and LBA registers. -
Page 17: Ata Command Description
Cactus Technologies, Limited 5.ATA Command Description This section defines the ATA command set supported by Cactus Technologies ® -910S/910S-P1 series SSDs. 5.1. ATA Command Set Table 5-6 summarizes the supported ATA command set . Table 5-6. ATA Command Set COMMAND... -
Page 18: Identify Drive-Ech
Cactus Technologies, Limited COMMAND Code Set Transfer Mode EFh/03h Enable Power-up In Standby EFh/06h Disable Power-up In Standby EFh/08h Set Max Set Max Address Set Max Freeze Lock F9h/04h Set Max Lock F9h/02h Set Max Set Password F9h/01h Set Max Unlock... - Page 19 Cactus Technologies, Limited Table 5-7. Identify Drive Information Word Default Value Total Bytes Data Field Type Information Address 0040H Non-removable device. XXXXH Default number of cylinders; capacity dependent. XXXXH Reserved 00XXH Default number of heads; capacity dependent. 0000H Retired XXXXH Default number of sectors per track;...
-
Page 20: Feature Set
Cactus Technologies, Limited Word Default Value Total Bytes Data Field Type Information Address 407FH UDMA Modes 0-6 supported; upper byte reflects currently selected mode. 0001H Security Erase Unit time. 0001H Enhanced Security Erase Unit time. 0000H Current APM level. FFFEH... -
Page 21: Attribute Data Structure
Cactus Technologies, Limited Byte(s) Description Revision code 2-361 Data for atrributes 1 - 30 Off-line data collection status Self-test execution status byte 364-365 Total time in seconds to complete off-line data collection activitiies Vendor specific Off-line data collection capabilities 368-369 SMART capabilities Error logging capabilities: bit[7:1] –... -
Page 22: Save Attribute Values (Subcommand D3H)
Cactus Technologies, Limited Attribute ID Attribute Name Description Soft Read error rate Corrected ECC error events which exceeded warning ECC error threshold Program Failure Block Count Number of flash program failures Erase Failure Block Count Number of flash erase failures... -
Page 23: Execute Off-Line Immediate (Subcommand D4H)
Cactus Technologies, Limited 6.5. S.M.A.R.T Execute Off-line Immediate (subcommand D4h) This subcommand causes the device to start the off-line process for the requested mode and operation. The LBA Low register shall be set to specify the operation to be executed as... -
Page 24: Read Log (Subcommand D5H)
Cactus Technologies, Limited 6.6. S.M.A.R.T Read Log (subcommand D5h) This command returns the specified log sector content to the host. LBA Low and Sector Count registers shall be set to specify the log sector and sector number to be written. -
Page 25: Error Log Structure
Cactus Technologies, Limited 6.6.2. S.M.A.R.T Error Log Structure Byte(s) Description SMART error log version (set to 01h) Error log index 2-91 error log data structure 92-181 error log data structure 182-271 error log data structure 272-361 error log data structure... - Page 26 Cactus Technologies, Limited Content of Device/Head register when the Command register was written Content written to Command register Timestamp Timestamp Timestamp Timestamp Error data structure: Byte Description Reserved Content of Error register after command completion Content of Sector Count register after command completion...
-
Page 27: Self-Test Log Structure
Cactus Technologies, Limited 6.6.3. Self-test Log Structure Byte(s) Description Log version 2+n*24 Self-test number 3+n*24 Self-test status 4+n*24 - 5+n*24 timestamp 6+n*24 Self-test failure checkpoint 7+n*24 - 10+n*24 LBA of first failure 11+n*24 - 25+n*24 Vendor specific ---- ---- 506-507... -
Page 28: Aes256 Hardware Encyrption
Cactus Technologies, Limited Once the erase operation has started, it cannot be interrupted. If the device is powered off while a quick erase operation is in progress, upon the next power up, the drive will resume the erase operation from where it left off when power was lost. - Page 29 Cactus Technologies, Limited Sector Count LBA Low LBA Med LBA High Device/Head Command Host must then perform a single sector PIO Data Out operation to the drive. The format of the sector data is as follows: Word Description 0-15 AES key (32 bytes)
-
Page 30: Enabling And Using Encryption
Cactus Technologies, Limited 7.2.2. Enabling and Using Encryption Here are the recommended steps to enable and use the AES256 hardware encryption feature: 1. Start with a blank drive – any data that existed before encryption is enabled will be lost once encryption is enabled as the data will be scrambled when sent through the decryption engine. - Page 31 Cactus Technologies, Limited echo “- - -” > /sys/class/scsi_host/host<n>/scan Where host<n> is that host channel where the drive is attached to (e.g. host0, host 1, etc.). This will force the OS to rescan for any disk attached to that host channel. The drive will then be detected and automatically mounted.
-
Page 32: Appendix A. Ordering Information
Cactus Technologies, Limited Appendix A. Ordering Information Model KDXFY-910S-P1 Where: is drive capacities: 64G -------------- 64GB 128G ------------ 128GB 160G ------------ 160GB 256G ------------ 256GB 320G ------------ 320GB 512G ------------ 512GB 640G ------------ 640GB Where is temperature grade: blank ------------ standard (0C to 70C) ------------ extended (-45C to 90C) -
Page 33: Appendix B.technical Support Services
Cactus Technologies, Limited Appendix B.Technical Support Services B.1.Direct Cactus Technologies ® Technical Support Email: tech@cactus-tech.com Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual v2.2... -
Page 34: Appendix C.cactus Technologies ® Worldwide Sales Offices
Cactus Technologies, Limited ® Appendix C.Cactus Technologies Worldwide Sales Offices Email: sales@cactus-tech.com Email: americas@cactus-tech.com Cactus Technologies Limited Industrial Grade -910S/910S-P1 Series SSD Product Manual v2.2... -
Page 35: Appendix D.limited Warranty
® Industrial Grade Flash Storage Products. Cactus Technologies ® , at its sole option, will repair, replace or refund the purchase price of the defective product. Cactus Technologies ® guarantees our products meet all specifications detailed in our product manuals. Although Cactus Technologies ®... - Page 36 ® Customer Service department (tech@cactus-tech.com) with the following information: product model number and description, nature of defect, conditions of use, proof of purchase and purchase date. If approved, Cactus Technologies ® will issue a Return Material Authorization or Product Repair Authorization number with return shipping instructions.
