- Page 1 Cactus Technologies, Limited Commercial Grade -240S series Product Manual May 2, 2018 www.cactus-tech.com...
- Page 2 Users of Cactus Technologies ® products for such unintended and unauthorized applications shall assume all risk of such use and shall indemnify and hold Cactus Technologies ® and its officers, employees, subsidiaries, affiliates and distributors harmless against all claims, costs, damages,...
-
Page 3: Table Of Contents
Cactus Technologies, Limited Table of Contents 1.Introduction to Cactus Technologies ® Commercial Grade -240S Series SSD Products..........5 1.1.Supported Standards...........................6 1.2.Product Features............................6 1.2.1.Host and Technology Independence....................6 1.2.2.Defect and Error Management......................6 1.2.3.Power Supply Requirements......................7 2.Product Specifications..............................7 2.1.System Environmental Specifications......................7 2.2.System Power Requirements........................7 2.3.System Performance...........................8... - Page 4 Cactus Technologies, Limited Appendix D.Limited Warranty............................1 Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5...
-
Page 5: Introduction To Cactus Technologies Commercial Grade -240S Series Ssd Products
® Commercial SSD is a high capacity solid-state flash memory product that complies with the Serial ATA 3.1 standard and is functionally compatible with a SATA hard disk drive. Cactus Technologies ® Commercial SSD provide up to 1TB of formatted storage capacity. -
Page 6: Supported Standards
The defect management is completely transparent to the host and does not consume any user data space. The soft error rate for Cactus Technologies ® Commercial SSD is much lower than that of magnetic disk drives. -
Page 7: Power Supply Requirements
Cactus Technologies, Limited 1.2.3. Power Supply Requirements Cactus Technologies ® Commercial SSD operates at a voltage range of 5.0 volts ± 10%. 2.Product Specifications For all the following specifications, values are defined at ambient temperature and nominal supply voltage unless otherwise stated. -
Page 8: System Performance
768TB 512GB 1536TB 3072TB Note: estimated TBW assumes workload consisting of mostly large block wrties. 2.5. Physical Specifications The following sections provide the physical specifications for Cactus Technologies ® Commercial SSD products. 2.5.1. 2.5” SSD Physical Specifications Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5... - Page 9 Cactus Technologies, Limited Figure 2-1. 2.5” SSD Dimensions (512GB or below) Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5...
- Page 10 Cactus Technologies, Limited Figure 2-2. 2.5” SSD Dimensions (1TB) Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5...
-
Page 11: Interface Description
Cactus Technologies, Limited 3.Interface Description The following sections provide detailed information on the Cactus Technologies ® Commercial SSD interface. 3.1. SSD Pin Assignments and Pin Type Cactus Technologies ® SSD uses industry standard 7+12 SATA connector. The signal/pin assignments and descriptions are listed in Table 3-5. -
Page 12: Dc Characteristics
Cactus Technologies, Limited 3.2.2. DC Characteristics Parameter Symbol Units Input Voltage -0.5 Vcc + 0.5 Output Voltage Vout -0.3 Vcc + 0.3 Input Leakage Current Output Leakage Current Input/Output Capacitance Operating Current Idle Active 3.2.3. AC Characteristics Cactus Technologies ®... -
Page 13: Error Register
Cactus Technologies, Limited 4.1.2. Error Register This register contains additional information about the source of an error when an error is indicated in bit 0 of the Status register. The bits are defined as follows: IDNF ABRT AMNF Bit 7 (BBK) This bit is set when a Bad Block is detected. -
Page 14: Drive/Head (Lba 27-24) Register
Cactus Technologies, Limited 4.1.8. Drive/Head (LBA 27-24) Register The Drive/Head register is used to select the drive and head. It is also used to select LBA addressing instead of cylinder/head/sector addressing. The bits are defined as follows: Bit 7 This bit is set to 1. -
Page 15: Device Control Register
Cactus Technologies, Limited 4.1.10. Device Control Register This register is used to control the drive interrupt request and to issue an ATA soft reset to the drive. The bits are defined as follows: SW Rst -IEn Bit 7 This bit is used in 48-bit addressing mode. When cleared, the host can read the most recently written values of the Sector Count,Drive/Head and LBA registers. -
Page 16: Ata Command Description
Cactus Technologies, Limited 5.ATA Command Description This section defines the ATA command set supported by Cactus Technologies ® Commercial SSDs. 5.1. ATA Command Set Table 5-6 summarizes the supported ATA command set . Table 5-6. ATA Command Set COMMAND Code... -
Page 17: Feature Set
Cactus Technologies, Limited COMMAND Code SMART Stand By E2h, 96h Stand By Immediate E0h, 94h Write Buffer Write DMA Write DMA Ext Write FPDMA Queued Write Multiple Write Multiple Ext Write Sector(s) Write Sector(s) Ext 6. S.M.A.R.T. Feature Set Cactus Technologies ®... -
Page 18: Attributes
Cactus Technologies, Limited Byte Description Vendor specific Short self-test routine recommended polling time (in minutes) Extended self-test routine recommended polling time (in minutes) Conveyance self-test routine recommended polling time (in minutes) 375-385 Reserved 386-395 Firmware Version/Date Code 396-397 Reserved 398-399... - Page 19 Cactus Technologies, Limited Attribute ID Attribute values Attribute Name Erase fail count in worst die Total wear level count Runtime invalid block count Total program fail count Total erase fail count Uncorrectable error count Power-off retract count Drive temperature (°C)
-
Page 20: Appendix A. Ordering Information
Cactus Technologies, Limited Appendix A. Ordering Information Model KDXFI-240S-XX Where: is drive capacities: 16G -------------- 16GB 32G -------------- 32GB 64G -------------- 64GB 128G ------------ 128GB 256G ------------ 256GB 512G ------------ 512GB 1T ---------------- 1TB Where: is temperature grade blank ------------ standard... -
Page 21: Appendix B.technical Support Services
Cactus Technologies, Limited Appendix B.Technical Support Services B.1.Direct Cactus Technologies ® Technical Support Email: tech@cactus-tech.com Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5... -
Page 22: Appendix C.cactus Technologies ® Worldwide Sales Offices
Cactus Technologies, Limited ® Appendix C.Cactus Technologies Worldwide Sales Offices Email: sales@cactus-tech.com Email: americas@cactus-tech.com Cactus Technologies Limited Commercial Grade -240S Series SSD Product Manual v1.5... - Page 23 TBW is exceeded, whichever occurs first. This express warranty is extended by Cactus Technologies ® Limited to customers of our products. II. GENERAL PROVISIONS This warranty sets forth the full extent of Cactus Technologies ® responsibilities regarding the Cactus Technologies ®...
- Page 24 ® Customer Service department (tech@cactus-tech.com) with the following information: product model number and description, nature of defect, conditions of use, proof of purchase and purchase date. If approved, Cactus Technologies ® will issue a Return Material Authorization or Product Repair Authorization number with shipping instructions.
