Remote Control Operation Instructions - Multibrackets M Motorized Turn Mount Manual

7a
7b
M-F
M-C
M-G
M-C
M-G M-D
M-E
or
M-H
M-H
M-H
8
5
M-F
M-G
M-A
Top of the TV
M-B
M-C
M-F
M-F
M-G
M-G
M-D
M-D
M-E
M-E
or or
M-H
M-I
M-I
9
90°
10
Do not open the electrical
cover.
11
remote control
±30°

Remote control operation instructions

STEP 1: When powered, the buzzer sounds once beep, TV wall
mount will be in standby state.
STEP 2: Press OK to return the TV wall mount flat against the
wall and hear one beep from the buzzer, the system will
then enter a working condition.
STEP 3: Follow the Key function instructions below to operate.
Note: f TV wall mount encounters an obstacle or has some
damage of machinery part in the process, TV wall mount will
stop automatically and sound three times beep beep beep.
hen the wall mount meets with an obstacle in the process.
Please remove the obstacle and push the wall mount by
hand until returns it flat against the wall. The wall mount can
normal use after press button.
6
