Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum efficiency. The specific models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2009
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
SWZ
Walk-Behind
Model:
SWZ36A-16KAI
SWZ36A-17KAI
SWZ48V-17KAI
SWZ52V-17KAI
SWZ52V-19KAI
SWZ-19KAI
SWZ-21KAE
PART NO. 03226 Rev. 2
PRINTED 1/2009
PRINTED IN USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WALK-BEHIND SWZ-19KAI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Scag Power Equipment WALK-BEHIND SWZ-19KAI

  • Page 1 The specific models that this book covers are listed on the inside cover. Before operating your machine, please read all the information enclosed. © 2009 Scag Power Equipment Division of Metalcraft of Mayville, Inc. OPERATOR’S MANUAL...
  • Page 2 FAILURE TO FOLLOW SAFE OPERATING PRACTICES MAY RESULT • Read this manual completely as well as other manuals that came with your mower. • ALWAYS FOLLOW OSHA APPROVED OPERATION. • DO NOT operate on steep slopes. • Always travel across slopes. •...
  • Page 3: Table Of Contents

    Table of Contents SECTION 1 - GENERAL INFORMATION 1.1 INTRODUCTION ...1 1.2 DIRECTION REFERENCE ...1 1.3 SERvICING THE ENGINE AND DRIvE TRAIN COMPONENTS ...1 1.4 SYMBOLS ...2 SECTION 2 - SAFETY INFORMATION 2.1 INTRODUCTION ...3 2.2 SIGNAL WORDS ...3 2.3 BEFORE OPERATION CONSIDERATIONS ...3 2.4 OPERATION CONSIDERATIONS ...4 2.5 MAINTENANCE CONSIDERATIONS &...
  • Page 4 SECTION 6 - ADJUSTMENTS 6.1 PARKING BRAKE ADJUSTMENT ...18 6.2 NEUTRAL ADJUSTMENT ...18 6.3 STEERING CONTROL ROD ADJUSTMENTS ...18 6.4 TRACKING ADJUSTMENT ...19 6.5 THROTTLE CONTROL AND CHOKE ADJUSTMENTS ...19 6.6 CUTTER DECK BELT ADJUSTMENTS ...19 6.7 BELT ALIGNMENT ...20 6.8 ADJUSTING CUTTING HEIGHT ...20 6.9 ELECTRIC CLUTCH ADJUSTMENT ...23 SECTION 7 -...
  • Page 5: Section 1 - General Information

    All information is based upon product information available at the time of approval for printing. Scag Power Equipment reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 6: Symbols

    SYMBOLS SYMBOL DESCRIPTION Choke Parking Brake On/Start Off/Stop Falling Hazard Fast Continuously Variable - Linear Pinch Point 481039S Hour meter/Elapsed Operating Hours STT MODELS Seat must be installed under the seat hold down bracket during installation. Failure to secure the seat under the hold down bracket could result in serious injury or death in a roll over.
  • Page 7: Section 2 - Safety Information

    Section 2 INTRODUCTION Your mower is only as safe as the operator. Carelessness or operator error may result in serious bodily injury or death. Hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper training of the personnel involved in the operation, transport, maintenance and storage of the equipment.
  • Page 8: Operation Considerations

    If the operator(s) or mechanic(s) cannot read English or Spanish, it is the owner's responsibility to explain this material to them. DO NOT wear loose fitting clothing. Loose clothing, jewelry or long hair could get tangled in moving parts. Do not operate the machine wearing shorts; always wear adequate protective clothing including long pants.
  • Page 9: Maintenance Considerations & Storage

    Section 2 WARNING DO NOT use your hand to dislodge the clogged discharge chute. Use a stick or other device to remove clogged material after the engine has stopped running and the blades have stopped turning. Be alert for holes, rocks, roots and other hidden hazards in the terrain.
  • Page 10: Using A Spark Arrestor

    Remove spark plug wire before making any repairs. Keep all nuts, bolts and screws tight, to ensure the machine is in safe working condition. Check blade mounting bolts frequently to be sure they are tight. Do not change the engine governor settings or overspeed the engine.
  • Page 11: Safety And Instructional Decals

    Section 2 SAFETY AND INSTRUCTIONAL DECALS WARNING DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING KIT, OR ENTIRE GRASS CATCHER INSTALLED WARNING ROTATING BLADES AND BELTS * Keep hands, feet & clothing clear * Keep all guards in place * Shut off engine & disengage blade clutch before servicing * Use caution in directing discharge * Read instruction manual before operating...
  • Page 12: Section 3 - Specifications

    ENGINE General Type ...Heavy Duty Industrial/Commercial Gasoline Brand ...Kawasaki Horsepower: (Scag Model SWZ36A-16KAI) ... 16 HP (Spec. # FH480V-BS24-R) (Scag Model SWZ36A-17KAI, SWZ48V-17KAI, SWZ52V-17KAI) ...17 HP (Spec.# FH541V-BS38-R) (Scag Model SWZ52V-19KAI, SWZ-19KAI) ...19 HP (Spec.# FH580V-BS34-R) (Scag Model SWZ-21KAE) ...21 HP (Spec. # FH641V-GS06-R) Cylinders ...2 with Cast-Iron Sleeves - Kawasaki Governor ...Mechanical Type with Variable Speed Control Set At 3600 RPM (+/- 100 RPM) Idle Speed:...
  • Page 13: Cutter Deck

    Section 3 CUTTER DECK Type ...Out-Front design with anti-scalp rollers Construction ... 36 / 48 = 7-Gauge Deck Top w/10-Gauge Reinforced Spindle Area, 7-gauge (3/16") Deck Skirt 52 / 61 = 10-Gauge Deck Top w/10-Gauge Reinforced Spindle Area, 7-Gauge (3/16") Deck Skirt True Cutting Width: 36 ...35.5"...
  • Page 14: Section 4 - Operating Instructions

    OPERATING INSTRUCTIONS CAUTION Do not attempt to operate this mower unless you have read this manual. Learn the location and purpose of all controls and instruments before you operate this mower. CONTROLS AND INSTRUMENT IDENTIFICATION Before operating the mower, familiarize yourself with all mower and engine controls.
  • Page 15: Safety Interlock System

    Section 4 Speed Control Lever (Figure 4-1). the forward speed. Neutral Latch (Figure 4-1). Used to secure the belt drive system in neutral. Apply neutral latches when parking the machine. Operator Pressence Control (Figure 4-1) The operator pressence control levers must be depressed before the transmission is shifted out of neutral or engaging the mower deck.
  • Page 16: Forward Travel

    FORWARD TRAvEL To travel forward with the mower, release the parking brake, select the desired speed using the speed control lever, pull steering control levers upward, release the neutral latch for both sides and slowly release both the left and right steering control levers.
  • Page 17: Hillside Operation

    Section 4 HILLSIDE OPERATION WARNING DO NOT operate on steep slopes. ALWAYS FOLLOW OSHA APPROvED OPERATION. This mower has been designed for good traction and stability under normal mowing conditions. However, caution must be used when traveling on slopes, especially when the grass is wet. Wet grass reduces traction and steering control.
  • Page 18: Moving Mower With Engine Stopped

    4.11 MOvING MOWER WITH ENGINE STOPPED To “free-wheel” or move the mower around without the engine running, turn the dump valve levers located on the back of the pumps counter clockwise o the "freewheel" position and move the mower by hand. To operate the mower, the dump valves must be turned clockwise to the closed position.
  • Page 19: Troubleshooting Cutting Conditions

    Section 5 TROUBLESHOOTING CUTTING CONDITIONS CONDITION STRINGERS - OCCASIONAL BLADES OF UNCUT GRASS Width of Deck SGB020 STREAKING - STRIPS OF UNCUT GRASS IN CUTTING PATH Width of Deck SGB018 STREAKING - STRIPS OF UNCUT GRASS BETWEEN CUTTING PATHS Width Width Deck Deck...
  • Page 20 TROUBLESHOOTING CUTTING CONDITIONS (CONT'D) CONDITION U N E v E N C U T O N F L AT GROUND - WAvY HIGH-LOW APPEARANCE, SCALLOPED CUT, OR ROUGH CONTOUR Width of Deck SGB020 UNEvEN CUT ON UNEvEN GROUND - WAvY APPEARANCE, HIGH-LOW SCALLOPED CUT, OR ROUGH CONTOUR Width of Deck...
  • Page 21 Section 5 TROUBLESHOOTING CUTTING CONDITIONS (CONT'D) CONDITION SCALPING - BLADES HITTING DIRT OR CUTTING vERY CLOSE TO THE GROUND Width of Deck SGB022 STEP CUT - RIDGE IN CENTER OF CUTTING PATH Width of Deck SGB024 SLOPE CUT - SLOPING RIDGES ACROSS WIDTH OF CUTTING PATH Width of Deck...
  • Page 22: Section 6 - Adjustments

    PARKING BRAKE ADJUSTMENT Adjust the parking brake so that when the brake hand lever is against the stop on the handle bar, the brake levers on the brake shaft weldment are against the stops on the engine deck. CAUTION Adjust the brake only enough to hold the machine. Excessive force may cause damage to the machine or brake components.
  • Page 23: Tracking Adjustment

    Section 6 TRACKING ADJUSTMENT -NOTE- Before proceeding with this adjustment, be sure that the tire pressures are correct and the neutral adjustment and the steering control rod adjustment have been completed. With the machine on a flat level surface, start the engine, release the parking brake and place the speed control lever into the speed that will most often be used.
  • Page 24: Belt Alignment

    -NOTE- Due to initial belt stretch and to prevent the belt from slipping, check this adjustment after the first 2 hours, 4 hours and 8 hours of operation. Adjust the RH blade drive belt using a belt tension gauge. Adjust the belt so that the belt moves 1/2" with 10 pounds of pressure.
  • Page 25: Blade Height Adjustment

    Section 6 BLADE HEIGHT ADJUSTMENT Adjusting the blade height can be done by moving any number of the five smaller 1/4" spacers on the blade mounting bolts to the top of the spindle shaft or below the spindle shaft. -NOTE- All blades should be positioned equally.
  • Page 26 Custom-Cut Baffle Adjustment Mounting Slot Selected Slot “A” Height (inches) Slot “B” Height (inches) Figure 6-10. Custom-Cut Baffle Adjustment Mounting Hardware Location Hole 1 Hole 2 Hole 3 3-3/4” 4-1/4” 4-3/4” Hole 2 Hole 3 3-1/2” 4” Section 6 Hole 4 5-1/4”...
  • Page 27: Electric Clutch Adjustment

    Section 6 ELECTRIC CLUTCH ADJUSTMENT The electric clutch serves two functions in the operation of the mower. In addition to starting and stopping the power flow to the cutter blades, the clutch also acts as a brake to assist in stopping blade rotation when the PTO is switched off or the operator presence circuit is interrupted.
  • Page 28: Section 7 - Maintenance

    MAINTENANCE CHART - RECOMMENDED SERvICE INTERvALS HOURS BREAK-IN 100 200 500 (FIRST 10) * Perform these maintenance procedures more frequently under extreme dusty or dirty conditions MAINTENANCE PROCEDURE Check all hardware for tightness C h e c k a l l b e l t s f o r p r o p e r alignment Check engine oil level *Clean mower...
  • Page 29: Lubrication

    Section 7 MAINTENANCE CHART - RECOMMENDED SERvICE INTERvALS (CONT'D) HOURS BREAK-IN (FIRST 10) LUBRICATION GREASE FITTING LUBRICATION CHART LOCATION 1 - Caster Wheel Pivot 2 - Caster Wheel Bearings 3 - Brake Actuator Levers 4 - Cutter Deck Spindles 5 - Pump Control Pivot 6 - Brake Lever 7 - Neutral Cam Pivot PROCEDURE...
  • Page 30 Figure 7-1. Lubrication Fitting Points Section 7 GREASE FITTING LUBRICATION LUBRICANT / INTERVAL LITHIUM MP WHITE GREASE 2125 ( 40 HOURS / WEEKLY ) CHASSIS GREASE ( 100 HOURS / BI-MONTHLY ) CHASSIS GREASE ( 200 HOURS / MONTHLY ) 390S0177...
  • Page 31: Checking/Changing Hydraulic Oil Level

    Section 7 HYDRAULIC SYSTEM A. CHECKING HYDRAULIC OIL LEvEL The hydraulic oil level should be checked after the first 8 hours of operation. Thereafter, check the oil after every 200 hours of machine operation or monthly, whichever occurs first. - IMPORTANT - If the oil level is consistently low, check for leaks and correct immediately.
  • Page 32: Engine Oil

    ENGINE OIL A. CHECKING ENGINE CRANKCASE OIL LEvEL The engine oil level should be checked after every 8 hours of operation or daily as instructed in the Engine Operator’s Manual furnished with this mower. B. CHANGING ENGINE CRANKCASE OIL After the first 20 hours of operation, change the engine crankcase oil and replace the oil filter.
  • Page 33: Engine Air Cleaner

    Section 7 ENGINE AIR CLEANER A. CLEANING AND/OR REPLACING AIR CLEANER ELEMENT For any air cleaner, the operating environment dictates the air cleaner service periods. Inspect and clean the air cleaner element after every 100 hours of operation or bi- weekly, whichever occurs first and replace the element if required.
  • Page 34: Cutter Blades

    Charging rates between 3 and 50 amperes are satisfactory if excessive gassing or spewing of electrolyte does not occur or the battery does not feel excessively hot (over 125°F). If spewing or gassing occurs or the temperature exceeds 125°F, the charging rate must be reduced or temporarily stopped to permit cooling.
  • Page 35: Blade Replacement

    Section 7 C. BLADE REPLACEMENT WARNING Always wear proper hand and eye protection when working with cutter blades. Remove the ignition key before replacing the blades. Remove the belt cover. Secure the cutter blades to prevent them from rotating, (use the optional Blade Buddy tool P/N 9212, to assist in securing the cutter blades), remove the blade attaching bolt.
  • Page 36: Illustrated Parts List

    ILLUSTRATED PARTS LIST SCAG APPROvED ATTACHMENTS AND ACCESSORIES. Attachments and accessories manufactured by companies other than Scag Power Equipment are not approved for use on this machine. Scag approved attachments and accessories: • Mulch Plate (p/n 9258, 9286, 9287) •...
  • Page 37: Caster Assembly

    Section 8 Ref. Part No. Description 04066-01 Quick Pin 43037-01 Spacer, Spacer Yoke, 1/2" Long 48100-01 Bronze Bearing 48114-04 Greasing Fitting 46082 Support Assembly (Incl. #3 & #4) 45006 Caster Yoke 04021-07 Nut, Elastic Stop 1/2-13 43022 Sleeve, Caster Wheel Bearing 04001-37 Bolt, Hex Head 1/2-13 x 5-1/2"...
  • Page 38: 36A Cutter Deck

    36A CUTTER DECK Section 8 SW06CD36A...
  • Page 39 Section 8 Ref. Part No. Description 461848 Cutter Deck w/Decals 461663 Cutter Spindle Assembly 43312 Spacer, Outside 481022 Bearing, Tapered 43644 Spindle Housing 04001-154 Bolt, 5/16-18 x 4-3/4" 43589 Spindle Shaft 04001-51 Bolt, 3/8-16 x 3-3/4" Hex Head 04063-08 Key, 1/4 x 1/4 x 2" 43592 Spacer, Cutter Blade - Small 04001-175...
  • Page 40: 48V & 52V Cutter Decks

    48v & 52v CUTTER DECKS Section 8 40 39 SW-06CD48V-52V...
  • Page 41 Section 8 Ref. Part No. Description 461852 Cutter Deck w/Decals 461855 Cutter Deck w/Decals 461663 Spindle Assembly 43296 Spacer, Inside 482744 Pulley 481022 Tapered Bearing 43644 Spindle Housing 48114-04 Grease Fitting Str. 5/16" 43589 Spindle Shaft 43682 Idler Pivot 04063-08 Key, 1/4 x 1/4 x 2"...
  • Page 42: 61V Cutter Deck

    61v CUTTER DECK Section 8 40 39 SW-06CD48V-52V...
  • Page 43 Section 8 Ref. Part No. Description 461860 Cutter Deck w/Decals 461663 Spindle Assembly 43296 Spacer, Inside 482745 Pulley 481022 Tapered Bearing 43644 Spindle Housing 48114-04 Grease Fitting Str. 5/16" 43589 Spindle Shaft 43682 Idler Pivot 04063-08 Key, 1/4 x 1/4 x 2" 43592 Spacer, Cutter Blade - Small 04001-175...
  • Page 44: Engine Deck - Manual Start

    ENGINE DECK - MANUAL START ENGINE DECK - MANUAL START 16 KAI 17 KAI 19 KAI ONLY Section 8 SWZ 08 EDMAN...
  • Page 45 Section 8 Ref. Part No. Description 483263 Engine, 16HP Kawasaki (Spec FH480V-BS24-R) 482927 Engine, 17HP Kawasaki (Spec FH541V-BS38-R) 482928 Engine, 19HP Kawasaki (Spec FH580V-BS34-R) 04040-15 Flatwasher, 5/16 - .375 x .875 x .083 04001-09 Capscrew, 5/16-18 x 1" Hex Head 482547 Cap, Fuel Tank 461729...
  • Page 46: Engine Deck - Electric Start

    ENGINE DECK - ELECTRIC START ENGINE DECK - ELECTRIC START SWz-21KAE Section 8 SWZ 08 EDELCT...
  • Page 47 Section 8 ENGINE DECK - ELECTRIC START Ref. Part No. Description 481964 Engine, 21KAE Kawasaki (Spec FH641V-GS06-R) 04040-15 Flatwasher, 5/16-.375 x 875 x .083 04001-09 Capscrew, 5/16-18 x 1" Hex Head 482547 Cap, Fuel Tank 461729 Fuel Tank Assy. (incl. 6, 7) 48309 Bushing 483747...
  • Page 48: Drive And Brake Components

    DRIvE AND BRAKE COMPONENTS DRIvE AND BRAKE COMPONENTS 37 41 3, 3A 10, 10A Section 8 SWZ05D&BC...
  • Page 49 Section 8 DRIvE AND BRAKE COMPONENTS Ref. Part No. Description 481876 Ring, Split 04001-19 Bolt, 3/8-16 x 1" Hex Head 45842 Brake Shaft Assembly Weldment, 16" Small Frame 45854 Brake Shaft Assembly Weldment, 20" Large Frame 04062-01 Hair Pin Cotter, .094 x 1.62 04003-12 Carrage Bolt, 5/16-18 x .75"...
  • Page 50: Handle Assembly - 16" Small Frame

    HANDLE ASSEMBLY - 16" SMALL FRAME 45 11 Section 8 SWZ08SFHAN...
  • Page 51 Section 8 HANDLE ASSEMBLY - 16" SMALL FRAME Ref. Part No. Description 461976 Upper Handle Wlmt. W/Decals 42675 Quadrant, Speed Control 04062-02 Hairpin, .094 x 1.19 45282 Lever, Speed Adjustment 43086 Bushing, Speed Adjustment Lever 04001-20 Hex Head Bolt, 3/8-16 x 1.5" 48493-01 Ball Plunger 48092...
  • Page 52: Handle Assembly - 20" Large Frame

    HANDLE ASSEMBLY - 20" LARGE FRAME 45 11 Section 8 SWZ 08 LFHAN...
  • Page 53 Section 8 HANDLE ASSEMBLY - 20" LARGE FRAME Ref. Part No. Description 461977 Upper Handle Wlmt. W/Decals 42675 Quadrant, Speed Control 04062-02 Hairpin, .094 x 1.19 45282 Lever, Speed Adjustment 43086 Bushing, Speed Adjustment Lever 04001-20 Hex Head Bolt, 3/8-16 x 1.5" 48493-01 Ball Plunger 48092...
  • Page 54: Hydraulic Assembly

    HYDRAULIC ASSEMBLY HYDRAULIC ASSEMBLY Section 8 2005SWZ-HA...
  • Page 55 Section 8 Ref. Part No. Description 481164 Cap, Oil Reservoir 461428 Oil Reservoir (With Fittings) 482266-01 Elbow, 9/16 O-Ring x 3/8" Hose 48811 Hose, 3/8" ID - 10-1/4" Long (Order By The Inch) 48811 Hose, 3/8" ID - 7" Long (Order By The Inch) 48603-06 O-Ring 483097...
  • Page 56: Hydraulic Pump Assembly

    HYDRAULIC PUMP ASSEMBLY PORT "A" SIDE PORT "B" SIDE Section 8...
  • Page 57: Hydraulic Pump Assembly

    Section 8 Ref. Part No. Description HG 70516 Housing Kit HG 70573 End Cap Kit HG 50641 Straight Headless Pin HG 50969 Hex Flange Bolt, M8-1.25 x 60mm HG 51232 Housing O-Ring HG 2513027 Charge Pump Kit HG 50273 Gerotor Assembly HG 9004101-1340 O-Ring HG 50095...
  • Page 58: Wire Harnesses

    NEUTRAL INTERLOCK BLACK W/RED STRIPE BLACK BLUE WHITE WHITE YELLOW INSTRUMENT PANEL HARNESS WIRE HARNESSES BLADE CLUTCH WHITE BLACK HANDLE WIRE HARNESS - Section 8 ENGINE DECK WIRE HARNESS PART NO. 483075 KOHLER GROUND (15 HP) KAWASAKI (15 HP, 16 HP & 17 HP) WIRE HARNESS ADAPTER - ENGINE SW08WH483075...
  • Page 59: Wire Harnesses

    Section 8 TRANSMISSION BLK W/RED STRIPE GREEN BLACK BLUE WHITE WHITE YELLOW RED W/YEL STRIPE INSTRUMENT CONNECTOR WIRE HARNESSES ENGINE DECK WIRING HARNESS KAWASAKI ELECTRIC START PART NUMBER: 483076 ENGINE GROUND WHITE BLACK W/RED STRIPE STARTER SOLENOID HANDLE WIRING HARNESS KAWASAKI ELECTRIC START PART NO.
  • Page 60: Wire Harnesses

    Section 8 WIRE HARNESSES WIRE HARNESS ADAPTER PART NO. 481717 KAWASAKI (15 HP, 16 HP & 17 HP) SW2006WH481717...
  • Page 61: Replacement Decals And Information Plates

    Section 8 REPLACEMENT DECALS AND INFORMATION PLATES WARNING DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING KIT, OR ENTIRE GRASS CATCHER INSTALLED SPINNING BLADES KEEP CLEAR BLADE CONTACT & THROWN OBJECTS CAN INJURE MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING PATENTS: 4,487,006 4,885,903 4,920,733...
  • Page 62 Section 8 REPLACEMENT DECALS AND INFORMATION PLATES 481423 FAST SPEED CONTROL SLOW NEUTRAL 482297 481124 Hea vy- Duty Comm e rcial 481971...
  • Page 63 Section 8 REPLACEMENT DECALS AND INFORMATION PLATES Ref. Part No. Description 483405 Decal, Discharge Chute 48314 Decal, Scag Logo 483407 Decal, Danger-Spinning Blades 483406 Decal, Warning-Rotating Blades 483044 Decal, Patents 48404 Decal, Metalcraft - Made in USA 483441 Decal, Instrument Panel - Rear 483404 Decal, Sulky Attachment 483402...
  • Page 64: Limited Warranty - Commercial Equipment

    Cutter decks are warranted against cracking for a period of three (3) years. (Parts and labor 1st and 2nd year; Parts only 3rd year.) The repair or replacement of the cutter deck will be at the option of Scag Power Equipment. We reserve the right to request components for evaluation.
  • Page 65 (Piezas y mano de obra) (La garantía de dos años no incluye las conexiones, mangueras, las correas de transmisión). La reparación o el reemplazo de la bomba hidráulica o el motor hidráulico estarán sujetos a discreción de Scag Power Equipment.
  • Page 66 lbs. césped recogedor Peso lbs. Peso 41.0" alineación Ancho Cero Cero lbs. lbs. lbs. lbs. 40.5" 40.5" 40.5" 40.5" 80.0" 62.0" 73.5" 64.5" 41.0" 37.0" 78.0" 78.0" SWZ-61V SWZ-52V bebida. práctica segura forma lateral. descarga cierre cuchillas flujo, directores empernados, combinado hurricane) (eye...
  • Page 67: Especificaciones

    para transmisión bloqueo embrague/cuchilla (diseño manual actuación operador motor funcionamiento rueda cada banda, campo alineación simple palanca controlado bloqueo palanca reversa, neutral para apriete rueda, cada para independiente micrones cuartos, capacidad nylon, cúbicas pulgadas fundido, hierro motor operación descarga válvulas torque alto fundido...
  • Page 68 autorizado Scag distribuidor Consulte autorizado Scag distribuidor Consulte autorizado Scag distribuidor Consulte autorizado Scag distribuidor Consulte autorizado Scag distribuidor Consulte cuchilla Reemplace nivel inclinación Ajuste seque césped Corte terreno condiciones ajustarse para velocidad Disminuya corte dirección cambiar corte plataforma altura aumentar terreno, velocidad...
  • Page 69 autorizado Scag distribuidor Consulte llantas presión ajuste Revise llantas presión ajuste Revise corte dirección cambiar corte plataforma altura aumentar terreno, velocidad reducir tener puede cuchilla autorizado Scag distribuidor Consulte autorizado Scag distribuidor Consulte nivel inclinación Ajuste plataforma abajo parte Limpie terreno hacia filo...
  • Page 70: Fallas De Identificación

    pase cada traslape Aumente cuchillas Reemplace seque césped Corte terreno condiciones ajustarse para velocidad Disminuya plataforma abajo parte Limpie correa tensión Ajuste 3600 motor Opere cuchillas Afile cuchillas Afile correa tensión Ajuste plataforma abajo parte Limpie cuchillas Afile seque césped Corte terreno condiciones...
  • Page 71 protección máxima para automotriz cortacésped Encere Scag. autorizado disponible 48521) (N/P Scag pintura dañadas metal superficies eléctricos. componentes presión. limpiadores limpiadores fría agua corte. cortacésped lave uso, comprimido. aire motor; está mientras equipo parte PRECAUCIÓN: MÁQUINA batería. negativo cable luego batería positivo cable...
  • Page 72: Hidráulico Sistema

    batería. corrosión. evitar silicona dieléctrica grasa aplique cable conexiones firmemente batería. celdas introduzca permita batería. limpiar para bicarbonato solución acero. batería postes cable extremos batería. luego plásticas mariposa tuercas baterías. después manos Lávese órganos daño cáncer como químicas sustancias California Estado plomo;...
  • Page 73 20W50. agregue necesario, rellenador. superior parte desde (pulgadas) hidráulico. tanque aceite durante neutro velocidad control vacío velocidad solamente. instálelo. motor limpio aceite Llene adecuadamente. deséchelo (Figura aceite filtro primero. ocurra anualmente, cada después cambiar debe aceite filtro elemento depósito. aceite agregue necesario, aceite...
  • Page 74: Mantenimiento

    polvo extremas condiciones bajo mantenimiento. procedimiento este sobre información obtener para Scag distribuidor motor operador manual chasis página chasis chasis necesario frecuencia chasis motor operador manual motor operador manual página necesario considere como 2125 litio blanca motor operador manual página página página página...
  • Page 75 adecuado ajuste obtener para cualquier freno accionador freno. componentes dañar puede excesiva fuerza detener para suficiente sólo PRECAUCIÓN: motor. plataforma queden freno soldada freno palancas mango, contra esté mano freno modo estacionamiento ESTACIONAMIENTO alineación Ajuste Scag. autorizado contacte alineación, obtener derecha.
  • Page 76 control varilla Ajuste 390s0198-1 multiplicador. codo ranura esté misma hasta dirección varillas giratoria plataforma codo ranurado orificio ubicación Verifique dirección. varilla giratoria plataforma Retire velocidad. control leva central canal esté multiplicador codo velocidad control apenas esté velocidad control asegúrese ajuste, este realizar reversa.
  • Page 77 3" personalizado corte deflector Posición TOPE PLANA ELÁSTICA TUERCA ARANDELA Setting 3" 2004 CARRO PERNO SUPERIOR pies-lb. torque Apriete 11). hasta Figuras como montaje accesorios ubicación). para hasta Figuras posición personalizado corte personalizado corte Deflector 2004 MONTAJE TORNILLERÍA corte. plataforma acuerdo variar puede...
  • Page 78 Figura ancho más CORTE cuchilla Espaciadores SC407G 2002 instalar afilar retirar, protección cuchillas forre protectores ojos para apropiada afilado. corte borde tienen ADVERTENCIA: Figura cuchilla entre espaciadores tres menos deben descarga, mejor distribuidas estar deben -NOTA- eje. debajo parte cuchilla montaje pequeños más...
  • Page 79 derecha mano plataforma correa Correa "J" Perno Plataforma correa. cubierta Figura (Vea tipo perno tuerca apretando tensión Ajuste 1/2" mueva misma Ajuste tensión. calibrador mano cuchilla transmisión operación. horas primeras ajuste este verifique patine, para correa, inicial estiramiento -NOTA- platforma transmisión correa IZQUIERDO...
  • Page 80: Operación

    palanca apriete izquierda, girar palanca apriete derecha, giro recta. línea desplazará máquina dirección freno palancas neutral. seguros ambos libere manos, ambas freno palancas apretando para máxima velocidad recomienda -NOTA- velocidad hasta velocidad Mueva estacionamiento. cuchillas accionar antes manuales maniobrando girando giro característica hidrostática...
  • Page 81 máquina. esta operar antes seguridad instrucciones CORTACÉSPED lubricadas. sido todas asegurarse para preventiva sólo Esto fábrica. aplicó conexiones. todas lubricante estacionamiento freno accionamiento interruptor está máquina arrancar cigüeñal debe motor eléctrico, arranque interruptores adecuado ajuste según Apriete floja. tornillería haya motrices macizas Llantas...
  • Page 82 reparación. limpieza realizar antes cese movimiento máquina. ajuste servicio dando motor accidental arranque evitar cables desconecte llave quite implementos, baje transmisión, móviles. piezas lejos ropa pies, mantenga funcionando, está motor específicamente indique menos motor máquina ajustes plano. terreno máquina servicio dé...
  • Page 83 OSHA OPERACIONES CUMPLA opere entrenamiento personal derrumba. borde encima pasa rueda volcarse podría máquina zanjas verticales, pendientes corra. camine—no asas Mantenga equilibrio. mantenga paradas arranques giros suavemente, máquina adicional distancia Permita húmedas superficies pendientes, girar cuidado tenga velocidad baje suba Nunca posible.
  • Page 84 INSTALADOS. CÉSPED RECOGEDOR TOLVA PAJA MEZCLADOR EQUIPO ADVERTENCIA neutro. neutral seguros estacionamiento freno aplique cuchilla accionamiento interruptor neutral, posición velocidad mueva motor, arrancar firmemente. gasolina tapa nuevamente inmediatamente. cámbiesela ropa, combustible derrama abierta. boquilla bloquee dispositivo utilice combustible. terminar hasta recipiente combustible tanque...
  • Page 85 cuchillas. arrojados recogidos objetos todos cortada debe juguete. jueguen suban niños máquina. esta servicio calificadas personas niños seguridad. señales operador equipo, segura operación PREVIAS CONSIDERACIONES máquina. esta correcta operación procedimientos todos comprenda parte gran dependen demás personales. lesiones ocasionar pueden máquina cerca seguras...
  • Page 86 operador manual Desconectar – cortante Elemento Conectar – cortante Elemento básico Símbolo cortante Elemento Lento DESCRIPCIÓN curiosos alejados lanzados objetos operación Horómetro/Horas contacto Lineal – variable DESCRIPCIÓN SÍMBOLO Mantenga Peligro transcurridas 481039S Punto Continuamente Rápido SÍMBOLO...
  • Page 87 caída Riesgo lanzados Objetos Apagado/Parada Aceite polea resorte Tensión Encendido/Arranque 48071S giratoria Cuchilla estacionamiento Freno Transmisión Ahogador DESCRIPCIÓN SÍMBOLO DESCRIPCIÓN SÍMBOLO Símbolos...
  • Page 88 puede garantía período durante realizado autorizado trabajo Cualquier fabricante autorizado servicio encontrar Scag distribuidor limitada, garantía período estos servicio Para general. mantenimiento instrucciones manual; este cubiertos están motor reparación servicio TRANSMISIÓN TREN MOTOR hacia desplazamiento dirección operación posición encuentra derecha izquierda refieren “posterior”...
  • Page 89 posterior cubierta 47-49 (SWZ-21KAE) eléctrico manual) 42-43 40-41 38-39 36-37 34-35 32-33 (SWZ-21KAE) 30-31 28-29 26-27 22-23 19-21 corte... batería PÁGINA CONTENIDO Dentro cables-Kawasaki eléctrico Arranque Arranque motor plataforma manual) (arranque mango (arranque motor plataforma hidráulica (20") grande Bastidor (16") pequeño Bastidor freno...
  • Page 90 CERTIFICATION TECHNICIAN SUPPORT neutral... transmisión PÁGINA CONTENIDO hidráulico hidráulico aceite Mantenimiento Lubricación estacionamiento dirección control personalizado corte corte corte plataforma cortacésped inicial arranque Almacenamiento operación operación previas señalización seguridad generales tren componentes instrucciones TABLA aceite Cambio nivel Verificar Tabla Freno alineación Ajuste varilla...
  • Page 91 serie. serie número D5599999 D5500001 D5499999 D5400001 D5299999 D5200001 D5199999 D5100001 D4899999 D4800001 D4799999 D4700001 D4699999 D4600001 D4599999 D4500001 operación equipo. relacionado personal conocimiento, dependen COMO tracción APROBADAS cuidado. ruedas baja). corte trabajar puede debe persona manual otro móviles. partes limpiar.
  • Page 92 EE.UU. IMPRESO 2007 ABRIL IMPRESO 03226 Nº PARTE INC. MAYVILLE, INCLUIDA. TODA MÁQUINA, INTERIOR. CUBIERTA ESTÁN MANUAL ESTE ESPECÍFICOS MODELOS MÁXIMA TRABAJANDO MANTENER PROCEDIMIENTOS AYUDAR PUEDE ESTE LECTURA SCAG. PARA SEGURIDAD OPERACIÓN CONTIENE MANUAL MODELO METALCRAFT EQUIPMENT POWER INFORMACIÓN OPERAR ANTES INDICADOS CUBIERTOS...
