Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum efficiency. The specific models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2023
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
SWZT
Walk-Behind
Model:
SWZT-36H-14FS
SWZT-48H-15FSE
SWZT-48H-20CX
SWZT-52H-18FSE
SWZT-52H-20CX
SWZT-61H-22FSE
SWZT-61H-25CX
PART NO. 03543
PRINTED 9/2023
PRINTED IN USA
