- Page 1 2017 Compile Installation Manual Global Contract Inc. 565 Petrolia Road OHSAS 18001:2007 ISO 9001:2015 ISO 14001:2015 North York, Ontario, M3J 2X8 REVISED: FALL 2017 Visit us on the Internet at globalcontract.com • (416) 739-5000...
-
Page 2: Table Of Contents
• For 4-ways, install the clips on the 4th side facing up, so the panel can be the panels. dropped on. Please contact your Global Contract Service Representative at 416-739-5000 for any questions or concerns. NOTE: Any alterations to listed components will void the manufacturer’s warranty. -
Page 3: Quick Connect Clips
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Quick Connect Clips Add or remove “Quick Connect” clips with a Phillips screwdriver, by loosening the screw enough to allow the clip to slide freely. To remove clip, lift tab on top of panel and slide clips out of groove. To change clip orientation, use the following hole confi... -
Page 4: Capas Privacy Glass
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES CAPAS Privacy Glass STEP 1: Open the clamps. STEP 2: Remove the pin. STEP 3: Measure 5” from the edge. STEP 4: Drill directly into the top of the panel. (use the provided #10 1 1/2” pan head square drive type A screw.) STEP 5: Use the thicker rubber pad if two different size pads are provided in the box. -
Page 5: Post Base Covers
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Post Base Covers STEP 1: Slide Post Base Cover into bottom of Universal Corner Post. STEP 2: Secure into place on 2 sides, with two small black screws. Electrical - Adding Power Distribution Housing Align Power Distribution Housing so the bottoms tabs drop into the pre-cut slots in the panel base. -
Page 6: Power Distribution Harness
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Electrical - Power Distribution Harness and Duplexes STEP 1: Plug Jumper into Power Distribution Harness, until it clicks fi rmly into place. The arrow above the embossed “N”, should be pointing up. STEP 2: Slide Duplex into place, until it clicks fi rmly into place. Power Distribution Harness has two ports on each side to plug in additional Jumpers or Ceiling Feeds. -
Page 7: Ceiling Feed
GLOBAL Contract • Summer 2017 rev:Winter 2018 • Summer 2017 INSTALLATION GUIDELINES Electrical - 90 degree post cable capacity Typical application, recommended maximum With Power Without Power Panel Frame Panel Frame Pass Through Cable Pass Through Cable Power Feed (0.73” dia) 20x CAT6 Cables 25x CAT6 Cables 0.25”... -
Page 8: Raceway Covers Without Knockouts
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Raceway Covers without Knockouts STEP 1: Orient Raceway Cover until it is almost VERTICAL and insert top of cover STEP 3: Snap bottom corners of Raceway Covers, to secure into place. into groove on panel. STEP 2: Raceway Cover can be lifted up at 90 degrees, and pushed slightly into panel, to lock in place. -
Page 9: Cantilevers Corner Brackets
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Cantilevers / Corner Brackets Installation Tip: Build from the BOTTOM..UP! • • Slide all Worksurface Supports and Brackets into place...FIRST. Tackboards/Write- boards /Load Bars, SECOND. Overhead Storage / Shelves, THIRD. STEP 1: Slide worksurface supports, with connection plate and screws attached, into groove on side of panel. -
Page 10: Chmeg Metal End Gable
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES CHMEG Metal End Gable STEP 1: Engage the leg into the panel’s rail by rotating it into place. STEP 2: Install the worksurface while making sure the leg is perpendicular to the panel. Page •... -
Page 11: Centre Mounted Overhead
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Centre Mounted Overhead 1. Install the corner brackets so they align with the very top of the panel. 2. Measure and centre the overhead on top of the panel. 3. While someone holds it in place, fasten the overhead to the brackets with the provided screws. -
Page 12: Pedestal Brackets
Compile Pedestals come shipped with cardboard protection on top, bottom and all four corners, and then shrink wrapped. Compile Pedestals may be stacked up to 3 high, in the shipping trailer, during delivery. All Worksurface Supporting Pedestals ship with holes punched in the tops, on all four corners, to allow simple attachment to worksurfaces., using wood screws... -
Page 13: Overhead Storage Bins
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Overhead Storage Bins STEP 1: Slide overhead side supports, with connection plate and screws attached, into groove on side of panel. STEP 2: Align top of overhead side support with top of panel. STEP 3: Securely attach all screws using a #4 ALLEN BIT, or TORX T25 HEAD BIT. -
Page 14: Low Profi Le Shelves
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Low Profi le Shelves STEP 1: Slide Low Profi le side supports, with connection plate and screws at- tached, into groove on side of panel. STEP 2: Align bottom of Low Profi le side support with bottom of Overhead Stor- age Cabinet, if applicable, use the supplied shelf gauge STEP 3: Securely attach all screws using a #4 ALLEN BIT, or BALL TORX T25 BIT, on one side only. -
Page 15: Tackboards
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Tackboards STEP 1: Slide universal brackets, with connection plate and screws attached, into grooves on each side of panel. STEP 2: Securely attach all screws using a #4 ALLEN BIT, or TORX T25 HEAD BIT. STEP 3: Hang tackboard hooks, into notches on universal bracket. -
Page 16: Ada Overhead
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES ADA Overhead STEP 1: Slide down the supplied 2 - two hole sliders into the side groves of the panel to their position using a gauge. Typical installation is 15” from the top of the panel. -
Page 17: Core Replacement
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Core Replacement STEP 1: Insert the crowbar under the bottom of the vertical and lift until the con- nectors at the top disengage. Repeat for the other side and release the panel from the row. -
Page 18: Module Replacement
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Module Replacement Applies to: fabric or laminate replacement. Conversion from glass to fabric, or fabric to glass. STEP 1: Remove the square #1 screws along the vertical part of the panel frame. *DO NOT remove the Philllips screws found at the bottom! STEP 2: Carefully remove the piece without causing ant damage. -
Page 19: End Panel
STEP 3: Attach the end panel to the Compile panel’s vertical rail (5). Put it on an angle then rotate it into its place. STEP 4: Adjust the levelers as needed, making sure the end panel will keep the worksurface level. -
Page 20: Accessory Retainer
GLOBAL Contract • Summer 2017 INSTALLATION GUIDELINES Accessory Retainer STEP 1: Mount the accessory on the load bar. 3” black rubber retainer for use with STEP 2: Push the accessory retainer (1) into the gap above the accessory (2) to paper management accessories. - Page 21 GLOBAL Contract • Summer 2017 globalcontract.com •Page...
- Page 22 GLOBAL Contract • July 2012 GLOBAL GLOBAL Contract Contract • Summer 2017 • June 2016 THE GLOBAL GROUP SHOWROOM 1350 Flint Road, Toronto, Ontario, M3J 2J7 Sales & Marketing • TEL: 1-877-446-2251 • FAX: 416-667-0338 Customer Service • TEL: 416-739-5000 • FAX: 800-361-3182 VANCOUVER SHOWROOM 3823 Still Creek Avenue Burnaby, BC, V5C 4E2 •...
