Aventura CAM-IPR Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network Camera
User Manual v1.0
CAM-IPR Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAM-IPR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aventura CAM-IPR Series

Summary of Contents for Aventura CAM-IPR Series

  • Page 1 Network Camera User Manual v1.0 CAM-IPR Series...

  • Page 2: Table Of Contents

    IPR Network Camera Series User Guide Aventura Technologies 48 Mall Drive Commack, NY USA 11725 Tel: 1-631-300-4000 Fax: 1-631-434-7000 Table of Contents Introduction ................................5 Overview ................................... 6 Range of Applications ............................6 Product Description ............................7 Operation Environment for Remote Access ..................... 7 Device Connection ..............................
  • Page 3 Line Crossing Detection (LCD) ......................... 39 12.5 Stationary Object Detection..........................39 12.6 Pedestrian Detection (PD) ..........................40 12.7 Face Detection (FD) ............................41 12.8 Cross Counting (CC) ............................42 12.9 Smart Analysis ..............................44 Page | 3 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 4 IPR Network Camera Series User Guide Page | 4 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 5: Introduction

    IPR Network Camera Series User Guide Introduction Thank you for using our Aventura® network camera products. These network cameras are easy to install and operate and can be employed in large and medium-sized enterprises, governmental projects, large malls, chain stores, intelligent buildings, hotels, hospitals, schools, and other large deployments, as well as to applications requiring remote network video transmission and monitoring.

  • Page 6: Overview

    IPR Network Camera Series User Guide Overview Range of Applications These network cameras with robust image processing capabilities may be applied in various large and medium- sized applications. Monitoring Center Page | 6 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 7: Product Description

    Memory: 1G or more Video memory: 256M or more Display: 1280 × 1024 or higher resolution to support HD camera resolutions IE: IE 9.0 or higher version; the camera can also connect to an NVR for full configuration. Page | 7 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 8: Device Connection

    The more commonly used configuration connects the IP cameras to local area networks and the Internet, where the camera and PC are connected to the LAN ports of a router/switch, with the gateway in the camera set to the IP address of the router. Page | 8 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 9: Device Operation Instructions

    If the PING command fails, check IP address and gateway setting of the PC and connectivity of the LAN. If DHCP is used, to find out the camera’s IP address see the process below. Page | 9 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 10: Searching Devices

    1. Run IPC Device Search by double-clicking the icon . It will search and display any online IPC and their IP address, port number, device type, and version, subnet mask, gateway, MAC address, and connection P2P details. Page | 10 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 11 IPC, then press the “Upgrade” button in the right corner to update. 3. Config: Double-click on the line to select a camera in the search page, which switches to the Config page with the IP information filled in. Page | 11 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 12 Export will save a .txt file to select user location. Import will allow selection of saving the .txt backup to be sent to the device. After an Import the device will reset. Page | 12 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 13: Installation Of Controls And Login To System

    Follow the screen prompt and install the AVPlugin application. If prompted, allow the plugin to run on this or on all websites. Preview Operate IE and enter the IP address of the camera (e.g., HTTP: //192.168.1.88) to open a login box as shown below: Page | 13 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 14 Some buttons in the preview frame are described below. : Color setting button, for the setting of color, brightness, contrast, saturation, and sharpness of the frame. : PTZ CONTROL press the icon, then it shows below picture: Page | 14 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 15 Click “Local Settings” button to pop up the following dialog box: In this dialog box, you can set video storage location, paths for download of remote file and storage of image snapshot, file type (RF by default, in H.264 or H.265 encoding) and video recording duration. Page | 15 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 16: Playback (Optional Function)

    The user can search video by file type as needed and control the video playback through the simple tools on the toolbar, e.g., open/stop the video, bitstream video, recording, snapshot, download recording, quick motion video playback, Sound On/Off. Page | 16 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 17: Parameter Setting

    OSD Position: shown by the text in red color on the frame; you can relocate the name of the channel and time by dragging it in the preview frame. Click Save when done. Image Control Click on Image Control in Display Configuration to open the following page: Page | 17 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 18: Privacy Zones

    Click on Save to enable the video masking area. Remove: After clicking Refresh, choose a blocked area by clicking it and then click Remove and click Save to remove it. Page | 18 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 19: Roi (If Applicable)

    ROI areas, the minimum rate among them is used as the frame rate to be applied for the non-ROI region in the preview frame.) Page | 19 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 20: Record Parameters

    In the image: one grid in the table is 30 minutes, green is normal recording, yellow is motion detection alarm, red is I/0 (for cameras that support alarm inputs). The user can set up different record type and time according to the specific requirement. Page | 20 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 21: Network Parameters

    PC client; cell phone port is used for connection of the mobile client. Video Streaming settings Click on Video Streaming setting in Network Parameter Menu to open the following page: Page | 21 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 22 I frame interval: Set I frame interval. Note: Range for the main bitstream is 256-8192. The range for the sub-bitstream is 128-4096. The range for cell phone bitstream is 8-1536. Page | 22 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 23: E-Mail Configuration

    E-mail test: Click it to test whether the mailbox is configured correctly by sending a test mail. DDNS Configuration Click on DDNS Configuration in Network menu to open the following page: DDNS configuration: Dynamic DNS configuration - used to overcome issues with changes in dynamic WAN Page | 23 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 24: Ip Filtering

    Username: Name of the user account Password: Password of the user account Test DDNS: connect to DDNS server and confirm authentication IP Filtering Click on IP Filtering in Network menu to open the following page: Page | 24 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 25: Rtsp

    Anonymous login: Enable to allow RTSP streaming without authentication. Usage Instructions: user:password@ Example: rtsp:// IP_address:RTSP_Port/ch01/A where A is one of: 0 (main stream), 1 (sub- stream) or 2 (mobile stream) If anonymous login is enabled, rtsp://IP_address:RTSP_Port/ch01/A Page | 25 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 26: Ftp

    Transfer Image: Check to allow images to be transferred SNMP Click on SNMP in Network menu to open the following page: SNMP settings – (SIMPLE NETWORK MONITOR PROTOCOL). Used for network monitoring Page | 26 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 27: Https

    HTTPS allows connection to the device via browser to use https:// to secure network settings/configuration HTTPS: On/Off. The default is On. HTTPS Type: Choose HTTPS with a unique certificate or HTTPS with a public certificate. Connecting to the IE may display the following information: Page | 27 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 28: Alarm Parameters

    (Note: When an object moves within the target area, a letter "M" in green color will be displayed on the preview frame) On cameras equipped with an SD card and alarm output contacts: Page | 28 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 29: I/O Alarm (If Applicable)

    Alarm Out: Enable output contact closure on the alarm Post Recording: After checking Enable Record, you can set the amount of time recording continues after the alarm input has reset (5s,10s, 20s, 30s) Page | 29 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 30: Lens Occlusion Detection

    If the camera includes an SD Card (optional function), it can store Logs, Video and Audio. These interfaces and functions are described below. HDD/SD Card (optional feature) Click HDD Card under the Device menu, then go to below page Page | 30 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 31: Audio (Optional Feature)

    Choose Audio Codec Type as desired (G711A, G711U, ADPCM, G726 with 16K, 24K, 32K or 40Kbps bandwidth) Click on Save to save the parameters as set. Note: The audio option may also be enabled in the Network > Video Streaming menu; see section 7.2 Page | 31 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 32: Logs

    Click on "Search" to retrieve and display related logs in the table. Use the First/Last/Next page number options to navigate the list. Click on "Refresh" to refresh the logs selected. Page | 32 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 33: System Parameters

    Sync with PC Time: The device will use your PC as a time server to set the time. 10.2 User Configuration Click on Users in the System menu to open the following page: Page | 33 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 34: System Information

    Here system information for the device will be displayed, including device type, MAC address, and software version, along with the P2P QR which can be used to add the device to the smartphone app. Page | 34 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 35: Advanced

    An interrupted update may render the device non-functional. 11.2 Loading Default Parameters Click on Load Default in Advanced menu to open the following page: Page | 35 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 36: System Maintenance

    Click on Maintain in the Advanced menu to open the following page: Here you can set scheduled rebooting or manually reboot the device. Since the camera cannot stream or record video during the reboot, employ this option carefully. Page | 36 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 37: Intelligent Analysis

    Crossing Detection (LCD), Stationary Object Detection (SOD), Pedestrian Detection (PD), Face Detection (FD) and Cross Counting (CC). These are explained in more detail below. 12.3 Perimeter Intrusion Detection (PID) Click Perimeter Intrusion in the Detection screen: Page | 37 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 38 Rule Type: Setup to each rule, A->B means can detect movement in A to B direction; B->A means can detect movement in B to A direction; A ←→B means can detect movement in both directions. Enable record: Trigger recording during and post-alarm. Page | 38 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 39: Line Crossing Detection (Lcd)

    B to A direction; A ←→B means can detect movement in both directions. Enable record: Trigger recording during and post-alarm. 12.5 Stationary Object Detection Click Stationary Object Detection in the Detection screen: Page | 39 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 40: Pedestrian Detection (Pd)

    Rule Type: Legacy means detecting objects left in the area; Lost means detecting objects removed from the area; Legacy & Lost detects both left and missing objects. Enable record: Trigger recording during and post-alarm. 12.6 Pedestrian Detection (PD) Click Pedestrian Detection in the Detection screen: Page | 40 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 41: Face Detection (Fd)

    Rule Number: Configure only 1 rule Rule Enable: make the rule active/inactive Rule Type: Always Normal Enable record: Trigger recording during and post-alarm. 12.7 Face Detection (FD) Click Face Detection in the Detection screen: Page | 41 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 42: Cross Counting (Cc)

    Rule Number: Configure only 1 rule Rule Enable: make the rule active/inactive Rule Type: Always Normal Enable record: Trigger recording during and post-alarm. 12.8 Cross Counting (CC) Click Cross Counting in the Detection screen: Page | 42 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 43 2) When enabling PID, LCD and SOD functions at the same time, the setup will be determined by the last function configured. 3) The intelligent alarm from FD, PD, and CC are different from the PID, LCD, SOD and so cannot be used at the same time. Page | 43 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 44: Smart Analysis

    Name & Export: Enter a name for the file and click Export to save the report. Begin Time: Initial date for selected report time period Search: runs the report as per the parameters entered List/Histogram/Line Chart selects the report display format. Page | 44 ©2018 Aventura Technologies, Inc. All rights reserved.
