Aventura CAM-IPM-5D-41P-VP Quick Operation Manual

Hide thumbs Also See for CAM-IPM-5D-41P-VP:

Advertisement

Table of Contents

See also: User Manual , Installation Manual

Network Camera

Quick Operation Guide
V4.0.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAM-IPM-5D-41P-VP and is the answer not in the manual?

Questions and answers

Related Manuals for Aventura CAM-IPM-5D-41P-VP

Summary of Contents for Aventura CAM-IPM-5D-41P-VP

  • Page 1: Network Camera

    Network Camera Quick Operation Guide V4.0.1...
  • Page 2 Network Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to CAM-IPM-5D-41P-VP, CAM-IPM-3D-29P-VP, CAM-IPM-2D-29P-WDR, CAM-IPM-2D-29P-WDRI, CAM-IPM-03D-21IR-VP Cameras This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.

  • Page 3: Appearance Description

    Network Camera·Quick Operation Guide 1 Appearance Description 1.1 Camera Description Figure 1-1 Overview Table 1-1 Description...
  • Page 4 Network Camera·Quick Operation Guide Description 10M/100M self-adaptive Ethernet interface INITIAL SET: Reset button AUDIO OUT: Audio output interface MIC IN: Audio input interface D+, D-: RS-485 interface 1A, 1B, 2A, 2B: Alarm output interface IN1, GND, IN2, GND: Alarm input interface Power supply interface Note: After powering the camera on, pressing and holding the...

  • Page 5: Camera Wiring Diagram

    Network Camera·Quick Operation Guide 1.2 Camera Wiring Diagram Figure 1-2 Wiring Diagram...

  • Page 6: Installation

    Network Camera·Quick Operation Guide 2 Installation Notes: Verify the package contents are correct by checking the items against the packing list. Read the following contents carefully before the installation. Make sure that all the related equipment is powered-off during the installation. Check whether the power supply is matched with your AC outlet to avoid damage.
  • Page 7 Network Camera·Quick Operation Guide Figure 2-1 Side Clips Steps: 1. Use the screws to fix the mounting base to the ceiling; rotate the back box counterclockwise to secure it to the mounting base; use the lock screw to secure the dome camera. Figure 2-2 Mounting 2.
  • Page 8 Network Camera·Quick Operation Guide Figure 2-3 Disassembling 3. Connect the RCA analog video output with a monitor to view the image of the camera. Loosen the lens set screw and pan, tilt or rotate the lens to get a desired surveillance angle. Adjust the lens focus to obtain a perfect image.
  • Page 9 Network Camera·Quick Operation Guide Figure 2-5 Image Adjusting 4. Reinstall the lower dome and tighten the screws. Figure 2-6 Reinstall...
  • Page 10 Network Camera·Quick Operation Guide In-ceiling mounting: Steps: 1. Secure the mounting base to the in-ceiling mounting base with screws. In-ceiling mounting base Mounting base Figure 2-7 Mounting Base...
  • Page 11 Network Camera·Quick Operation Guide 2. Push the dome camera to the in-ceiling mounting base, rotate the dome camera for 10 degrees counterclockwise and then fasten the lock screws to fix the camera. ① ③ Lock screw ② Figure 2-8 Camera and Mounting Base 3.
  • Page 12 Network Camera·Quick Operation Guide Figure 2-9 Installing 4. It is strongly recommended that you use a safety rope to secure the in-ceiling mounting base to the roof. Safety rope Figure 2-10 Safety Rope 5. Fasten the lock screws to secure the dome camera.
  • Page 13 Network Camera·Quick Operation Guide Lock Screw Figure 2-11 Fasten Screws 6. Remove the lower dome and connect the RCA analog video output with a monitor to view the image of the camera. Loosen the lens set screw and pan, tilt or rotate the lens to get a desired surveillance angle.
  • Page 14 Network Camera·Quick Operation Guide 7. Install the trim plate with screws to finish the installation. Figure 2-13 Trim Plate Installing...

  • Page 15: Setting The Network Camera Over The Lan

    Set the IP address of the camera for accessing via LAN. Steps: 1. To get the IP address, use the Aventura client software to list the online devices. Please refer to the user manual of client software for detailed information.
  • Page 16 Network Camera·Quick Operation Guide 3. Enter the IP address of network camera in the address field of the web browser to view the live video. Note:  The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. ...

  • Page 17: Accessing Via Web Browser

    Network Camera·Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above...
  • Page 18 Network Camera·Quick Operation Guide Figure 4-1 Adjust the Security Level Steps: 1. Open the web browser. 2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface.
  • Page 19 Network Camera·Quick Operation Guide Figure 4-2 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
  • Page 20 Network Camera·Quick Operation Guide Figure 4-3 Download Plug-in...
  • Page 21 Network Camera·Quick Operation Guide Figure 4-4 Download Plug-in Figure 4-5 Install Plug-in...
  • Page 22 Network Camera·Quick Operation Guide Figure 4-6 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of network camera.

This manual is also suitable for:

Cam-ipm-3d-29p-vpCam-ipm-2d-29p-wdriCam-ipm-2d-29p-wdrCam-ipm-3d-21ir-vp
