Operating Instructions
eFutureSafe – Automatic Head & Backrest
pillar
www.amfbrunsamerica.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eFutureSafe and is the answer not in the manual?

Questions and answers

Related Manuals for AMF-BRUNS eFutureSafe

Summary of Contents for AMF-BRUNS eFutureSafe

  • Page 1 Operating Instructions eFutureSafe – Automatic Head & Backrest pillar www.amfbrunsamerica.com...

  • Page 3: Foreword

    Foreword Dear Reader, these Operating Instructions serve to provide all infor- mation required for the safe use of the eFutureSafe head- and back-support. The eFutureSafe is designed and constructed in accord- ance with state of the art technology and recognised safe- ty standards.
  • Page 4 ATTENTION! ...warns of a potentially dangerous situation, which can cause material damage, if not avoided..contains general notes and useful information..gives a reference to important information in other sec- tions and documents. Page 4 of 40 eFutureSafe...
  • Page 5  Instructional text, e.g. a sequence of activities. Meaning of directions: If directions are given in the text (in front of, front, behind, rear, right, left), these directions relate to the normal direc- tion of travel of the vehicle. eFutureSafe Page 5 of 40...

  • Page 6: Table Of Contents

    2.1.5 Control unit ..........14 2.1.6 Emergency unlatching facility ..... 14 2.1.7 Rating plate ..........15 2.2 Operating Controls and Indicators ....... 16 2.3 Technical Data ............17 3 Transportation ..........18 4 Installation, Commissioning ......18 Page 6 of 40 eFutureSafe...
  • Page 7 5.4.1 Adjusting the lateral position of the head- and back-supports ......24 5.4.2 Adjusting the height of the head- and back-supports ......25 5.5 Emergency Release for the eFutureSafe ....27 6 Maintenance and Repair ........29 6.1 Safety Regulations for Maintenance and Repair ..............29 6.2 Routine Maintenance Work ........

  • Page 8: Safety

    Prerequisite to the safe handling and trouble-free opera- tion of the eFutureSafe is a thorough knowledge of the ap- plicable safety information and the safety regulations. It is therefore imperative that this Chapter is read thor- oughly before operating the eFutureSafe and that the in- structions and warnings herein are strictly observed.

  • Page 9: Proper Use

    Safety Proper Use The eFutureSafe is designed solely for use in a vehicle as a head- and back-support for persons who are driving a car whilst seated in a wheelchair. The driver seated in the wheelchair must wear the seat belts provided in the vehicle.

  • Page 10: User Requirements

    NOTE Guarantee work on the eFutureSafe must only be carried with prior agreement AMF-Bruns GmbH & Co. KG. The costs of such work will not be accepted by AMF-Bruns without prior agreement. Page 10 of 40 eFutureSafe...

  • Page 11: Danger Zone

    Safety Danger Zone The danger zone is any area within the swivelling range of the eFutureSafe, in which a person at risk of being injured or harmed. CAUTION! Risk of injury through movements of the eFutureSafe. There are a number of risks of personal injury if standing within the danger zone.

  • Page 12: Safety And Accident Prevention Regulations

    Adhere to the following notes in order to prevent personal injuries and material damage.  The eFutureSafe must only be used for the purpose for which it is intended (proper use), otherwise dangerous situations, with result injuries, may occur (Proper use: see Section 1.1, page 9).

  • Page 13: Description

     the control unit,  the operating controls and indicators. The aim of this chapter is to illustrate the construction and function of the eFutureSafe. To this end, the individual as- semblies and components are described in the following sections.

  • Page 14: Floor Mount And Side Support Bracket

    Description 2.1.1 Floor mount and side support bracket The eFutureSafe is anchored to the floor of the vehicle by its floor mount and special mounting components. In addi- tion to this, the eFutureSafe is anchored to the B-pillar by means of a vehicle-specific side support bracket. In the event of an accident, the forces acting are absorbed by the floor mount and the side support.

  • Page 15: Rating Plate

    Description 2.1.7 Rating plate A rating plate, which contains the fundamental data, is at- tached to the eFutureSafe (see Figure 2). The rating plate is located on the underside of the swivel arm. Year of Designation manufacture Type Serial number Manufacturer’s...

  • Page 16: Operating Controls And Indicators

    2.2 Operating Controls and Indicators Figure 3: Toggle switch Figure 4: Indicator Lamp Designation Function Toggle switch Swivels the eFutureSafe with the ignition switched OFF. Indicator Lamp Lights up green, as soon as the eFutureSafe is in the driving position.

  • Page 17: Technical Data

    Description 2.3 Technical Data Designation eFutureSafe Dimensions: Width (maximum) 605 mm Depth 605 mm (by swivelling) Height (minimum) 1251 mm Height (maximum) 1351 mm Height of connec- 860 mm tion to the B-pillar (minimum) Height of connec- 940 mm tion to the B-pillar (maximal) Weight (approx.)

  • Page 18: Transportation

    Such risks can not only occur during installation but also as a result of installation not being carried out correctly. Therefore:  The eFutureSafe must only be installed in the vehicle by trained, experienced technicians.  The vehicle manufacturer's body fitting guidelines must be adhered to.

  • Page 19: Operation

    Make certain that there are no obstacles within the swivelling range of the eFutureSafe. WARNING! Risk of personal injury and material damage. If its path is blocked by obstacles, the eFutureSafe can not be swivelled to the parking position. You can not get out of the vehicle. Therefore: ...
  • Page 20 Operation WARNING! Risk of severe injuries If the eFutureSafe is not in the driving position, it can not provide protection in the event of an accident. Therefore:  Make certain that the eFutureSafe is in the driving posi- tion. ...

  • Page 21: Swivelling The Efuturesafe To The

    NOTE Always ensure that the eFutureSafe is in the parking posi- tion when the vehicle is parked. If the eFutureSafe is in the driving position, the green indicator lamp will be lit and there is a risk that this will discharge the starter battery.

  • Page 22: Swivelling The Efuturesafe To The

    Operation 5.3 Swivelling the eFutureSafe to the Driving Position The eFutureSafe is in the driving position when it is swiv- elled forwards (see Figure 6).  Remove any bags or other objects from the wheel- chair's backrest.  Assume the driving position behind the steering wheel.

  • Page 23: Adjusting The Efuturesafe

    Have the eFutureSafe adjusted by a second person. Repeat the adjustment of the eFutureSafe if you use a dif- ferent wheelchair. The eFutureSafe must also be re-adjusted if there is a change of driver.

  • Page 24: Adjusting The Lateral Position Of The Head- And Back-Supports

     Move the carrier on the swivel arm such that the head- and back-supports are behind the centre of the driver.  Tighten the star grip. Carrier Star grip Figure 7: Lateral Adjustment of Head- and Back-Supports Page 24 of 40 eFutureSafe...

  • Page 25: Adjusting The Height Of The Head- And Back-Supports

    NOTE Have the following adjustments made for you by a second person. Remember that the adjustment of the eFutureSafe de- scribed here represents the ideal case. Always try to find a balance between maximum protection and maximum comfort when making adjustments.
  • Page 26  Adjust the height of the head-support, such that the up- per edge is at the same height as the top of the driver's head.  Release the latch button. Head-support latch button Back-support latch button Figure 9: Adjusting the Height Page 26 of 40 eFutureSafe...

  • Page 27: Emergency Release For The Efuturesafe

    5.5 Emergency Release for the eFutureSafe NOTE The emergency release facility allows the eFutureSafe to be swivelled to the park position if the electric drive fails. This allows you to leave your vehicle in such a case. This also allows you to be evacuated more easily if the vehicle is involved in an accident.
  • Page 28 Figure 11: Emergency Release Facility (2) Figure 12: Label for Emergency Release NOTE Once the emergency release facility has been used, visit a technician to restore the eFutureSafe to its original state and to guarantee trouble-free function. Page 28 of 40 eFutureSafe...

  • Page 29: Maintenance And Repair

    Read the safety information before carrying out mainte- nance and repair work (see Chapter 1, page 8). WARNING! There is a risk of injury if the eFutureSafe is used after it has been involved in an accident. If involved in an accident, the eFutureSafe can suffer dam- age that is not immediately evident This can impair your safety.

  • Page 30: Routine Maintenance Work

    For records of maintenance work over and above this, it is recommended that you keep your own lists. 6.3 Maintenance and Repair Record Maintenance work carried out Date Signature Remarks / work carried out Page 30 of 40 eFutureSafe...

  • Page 31: De-Commissioning And Conservation

    De-Commissioning and Conservation 7 De-Commissioning and Conserva- tion For queries regarding de-commissioning and conservation, contact our customer services department (see Chap- ter 10, page 35). eFutureSafe Page 31 of 40...

  • Page 32: Faults And Troubleshooting

     Only allow experienced technicians to carry out repair work. If faults occur when operating the eFutureSafe, proceed as described in the following troubleshooting table. Contact the customer service department if faults are encountered which cannot be remedied using the information and measures given in the table.

  • Page 33: Spare Parts

    Spare Parts 9 Spare Parts Figure Designation Article No. Head-support 200412614 Back-support 200412631 Guide bushing 200249429 Latch bushing 200249725 Hex. protective 10008439 cap SW17 eFutureSafe Page 33 of 40...
  • Page 34 Spare Parts Figure Designation Article No. Pillar cladding 10022896 Swivel joint 10022897 cladding Locking pin 200406018 Control unit 10022804 Indicator Lamp 10022803 Toggle switch 10022925 Page 34 of 40 eFutureSafe...

  • Page 35: Electrical Circuit Diagram

    Fuse 1 A – Signal 15 (ignition) 12 V starter battery Toggle switch (ON/OFF) in the dash- board Indicator lamp in the dashboard Electric motor in the eFutureSafe Control unit Contact switch in the eFutureSafe Plug-in connection to the control unit (7- pole)

  • Page 36: Customer Service

    AMF- Bruns GmbH & Co. KG. The costs of such work will not be accepted by AMF-Bruns without prior agreement. NOTE The information contained in this document is not all inclu- sive and may not cover or represent every installation.

  • Page 37: Declaration Of Conformity

    Designation: Electrically operated swivelling head- and back-support eFutureSafe Type: Manufacturer: Company: AMF-Bruns GmbH & Co. KG Address: Hauptstraße 101 26689 Apen Harmonised standards applied: DIN EN ISO 12100 Other technical standards and specifications applied:...
  • Page 40 AMF-Bruns GmbH & Co. KG | Hauptstraße 101 | 26689 Apen Telephone +49 (0) 4489 / 72 72 30 | Fax +49 (0) 4489 / 62 45 service.hubmatik@amf-bruns.de www.amf-bruns.de Reg.-No. Q1 0105027...
