AMF-BRUNS Easy-Ramp Operating Instructions

Easy-Ramp and Easy-Flex-Ramp
Using the Vehicle without a Passenger
After disembarking a passenger / unloading a wheelchair:
1. Fold the access ramp up until it audibly engages in the
vertical position.
2. For the Easy-Flex-Ramp: Push the operating lever to the
right, to fold the access ramp away.
3. Fully fold the access ramp down inside the vehicle, until
its bearing surfaces rest on the vehicle's floor at the
sides of the floor section.
Attention! Max. permissible access ramp load
when deployed 300 kg.
Max. permissible access ramp load when fully
folded away 100 kg.
Removing the seat retainers
In the interests of safety and comfort for the wheelchair
passenger's feet, the seat retainers must be removed from
a vehicle with a long wheelbase.
1. Lift the securing clip on a seat retainer.
2. Pull the seat retainer towards the rear.
3. Remove the seat retainer.
4. Repeat the procedure for the second seat retainer.
Issue: February 2017 / Subject to technical changes without
These brief operating instructions do not in any way
replace the full Operating Instructions! Please read the full
Operating Instructions thoroughly
product for the first time!
AMF-Bruns GmbH & Co. KG
Hauptstraße 101 | 26689 Apen | Germany
Telephone +49 (0) 4489 / 72 72 30
Telefax +49 (0) 44 89 / 6245
service.hubmatik@amf-bruns.de
www.amf-bruns.de
notice.
Issue: February 2017
Article No. 10022592
AMF-Bruns
BRIEF OPERATING INSTRUCTIONS
Opel Vivaro / Renault Trafic / Fiat Talento with Easy- and Easy-Flex-Ramp
before using the
