- Page 1 Operating Instructions ELECTRIC STEP www.amf-bruns.de...
-
Page 3: Foreword
After reading these Operating Instructions for the first time, keep them in a safe place for future reference over the en- tire lifetime of the Electric Step. If you sell the Electric Step, hand these Operating Instructions over to the new owner. - Page 4 ...contains general notes and useful information..gives a reference to important information in other sec- tions and documents. Some texts serve a particular purpose. These are identified as follows: Lists Instructional text, e.g. a sequence of activities. Page 4 of 28 Electric Step...
-
Page 5: Table Of Contents
6.1 Safety Regulations for Maintenance and Repair ............20 6.2 Routine Maintenance Work ........21 6.2.1 Maintenance schedule ....... 21 6.2.2 Maintenance records ......... 21 6.3 Cleaning ............... 21 6.4 Maintenance and Inspection Record ....22 Electric Step Page 5 of 28... - Page 6 Contents De-Commissioning and Conservation ..... 23 8 Faults and Troubleshooting ......23 9 Electrical Circuit Diagram ........ 24 10 Customer Service ..........25 11 Declaration of Conformity ........ 26 Page 6 of 28 Electric Step...
-
Page 7: Safety
Prerequisite to the safe handling and trouble-free opera- tion of the Electric Step is a thorough knowledge of the applicable safety information and the safety regulations. It is therefore imperative that this Chapter is read thor- oughly before operating the Electric Step and that the in- structions and warnings herein are strictly observed. -
Page 8: Proper Use
Proper use also includes strictly adhering to the infor- mation given in these Operating Instructions. WARNING! If the Electric Step is used for any other purpose than that described above, this can create dangerous situations for persons or cause material damage. -
Page 9: Requirements Of The User
Other persons, who have read these Operating Instruc- tions. Other persons who have been have been made aware of the Electric Step and its function by the driver of the vehicle. Transportation, installation, commissioning, maintenance, repair, fault finding and disposal of the Electric Step must only be carried out by persons with the corresponding technical training and experience. -
Page 10: Danger Zone
Safety Devices 1.6.1 Electric motor current limiting With an Electric Step in the automatic mode the control unit is equipped with a current limiter. This limits the cur- rent supplied to the motor. This reduces the force at which the step will hit an obstacle when being extended. -
Page 11: Safety And Accident Prevention Regulations
If they are not replaced correctly, there is a high risk of injury. The Electric Step must only be used for the purpose for which it is intended, otherwise dangerous situations, with resultant injuries, may occur (Proper Use: see Sec- tion 1.1, page 8). -
Page 12: Disposal
Safety Disposal When the Electric Step's useful life has expired, it must on- ly be disposed of by qualified specialists. The manufacturer will accept no liability for damage caused by incorrect dis- posal. Page 12 of 28 Electric Step... -
Page 13: Description
The aim of this chapter is to illustrate the construction and function of the Electric Step. To this end, the individual as- semblies and components are described in the following sections. Step Tread The step tread automatically extends when the side door is opened or by operating a rocker switch. -
Page 14: Frame
2.3 Motor The Electric Step’s drive motor is a 12 V DC motor that ex- tends and retracts the tread step by means of a linear drive (see Figure 2). -
Page 15: Operating Controls
Description 2.5 Operating Controls Rocker switch The Electric Step is extended or retracted by operating the rocker switch. It is only available with a manually operated Electric Step. The rocker switch is installed on the B-column. When the side door is closed, the rocker switch is concealed. This is to prevent it from being operated inadvertently. -
Page 16: Transportation
Transportation 3 Transportation CAUTION! Dangers involved in the transportation of the Electric Step. The Electric Step can fall over or fall down during transpor- tation. There is a risk of personal injury or material dam- age. Therefore: Proceed with caution when transporting the Electric Step. -
Page 17: Installation / Commissioning
DANGER! Risk of danger through incorrect installation. A number of risks of personal injury and material damage can be caused if the Electric Step is incorrectly installed in the vehicle. Such risks of danger can not only occur during installation but also as a result of installation not being carried out cor- rectly. -
Page 18: Operation
DANGER! Risk of injury and material damage the vehicle is in motion. If the Electric Step extends when the vehicle is in motion, there is the risk of other road users suffering seriously inju- ries. Material damage can be caused. -
Page 19: Manual Operation
When the side door is opened, the Electric Step automatically extends. When the side door is closed, the Electric Step automatically retracts. There is no rocker switch or other controls available. -
Page 20: Maintenance And Repair
Therefore: use only original spare parts or spare parts that have been approved of by the manufacturer. Page 20 of 28 Electric Step... -
Page 21: Routine Maintenance Work
For records of maintenance work over and above this, it is recommended that you keep your own lists. 6.3 Cleaning Depending upon the degree of dirt, clean the Electric Step at intervals of three months: Remove the bolt on the piston rod of the motor using an SW 17 spanner. -
Page 22: Maintenance And Inspection Record
Maintenance and Repair 6.4 Maintenance and Inspection Record Maintenance work carried out Date Signature Remarks / work carried out Page 22 of 28 Electric Step... -
Page 23: De-Commissioning And Conservation
Therefore: Only allow specialist personnel to carry out repair work. If faults occur when operating the Electric Step, proceed as described in the following troubleshooting table. Con- tact the customer service department if faults are encoun- tered which cannot be remedied using the information and measures given. -
Page 24: Electrical Circuit Diagram
+ to the batterie Automatic Operation black green brown yellow grey white fuse 40 A motor buzzer limit switch door contact switch rocker switch control unit to battery control unit Figure 4: Electrical Circuit Diagram Page 24 of 28 Electric Step... -
Page 25: Customer Service
NOTE Guarantee work on the Electric Step must only be carried with prior agreement AMF-Bruns GmbH & Co. KG. The costs of such work will not be accepted by AMF-Bruns without prior agreement. Electric Step Page 25 of 28... -
Page 26: Declaration Of Conformity
Designation: Electric Step Type: see rating plate Serial number: see rating plate Manufacturer: Company: AMF-Bruns GmbH & Co. KG Address: Hauptstraße 101 26689 Apen Harmonised standards applied: DIN EN ISO 12100 Other technical standards and specifications applied: DIN 75078-1 Authorised agent for the technical documentation: Thomas Lakewand (address: see manufacturer’s address) - Page 28 AMF-Bruns GmbH & Co. KG | Hauptstraße 101 | 26689 Apen Telephone +49 (0) 4489 / 72 72 30 | Fax +49 (0) 4489 / 62 45 service.hubmatik@amf-bruns.de www.amf-bruns.de Reg.-No. Q1 0105027...
