Solenoid valve
Operating manual
Version
BA-2017.09.08 EN
Print-No.
301 215
TR MA DE Rev001
Series
model 150
model 160
ASV Stübbe GmbH & Co. KG
Hollwieser Straße 5
32602 Vlotho
Germany
Phone: +49 (0) 5733-799-0
Fax: +49 (0) 5733-799-5000
E-mail:
contact@asv-stuebbe.de
Internet:
www.asv-stuebbe.com
We reserve the right to make
technical changes.
Read carefully before use.
Save for future use.
Advertisement
Table of Contents
Related Manuals for Stübbe 150
Summary of Contents for Stübbe 150
- Page 1 Solenoid valve Operating manual Series model 150 model 160 Version BA-2017.09.08 EN ASV Stübbe GmbH & Co. KG Print-No. 301 215 Hollwieser Straße 5 TR MA DE Rev001 32602 Vlotho Germany Phone: +49 (0) 5733-799-0 Fax: +49 (0) 5733-799-5000 E-mail: contact@asv-stuebbe.de...
-
Page 2: Table Of Contents
150 ........ -
Page 3: About This Document
– Keep this manual available at the place of operation, To download: also for future use. Type 150 data sheet Technical specifications, conditions of – Ensure that employees read and observe this manual and other applicable documents, especially the safety operation instructions and warnings. -
Page 4: Warnings And Symbols
Instruction 1., 2., ... Multiple-step instructions Precondition → Cross reference Information, notes Tab. 2 Warnings and symbols Type 150, Type 160 BA-2017.09.08 EN 301 215... -
Page 5: General Safety Instructions
The following work should be carried out by specialist tech- nicians only: – Installation, repair and maintenance work – Work on the electrical system • Make sure that trainee personnel only work on the fitting under supervision of specialist technicians. 301 215 BA-2017.09.08 EN Type 150, Type 160... -
Page 6: Layout And Function
(NC) Serial number – open when de-energized (NO) 10 Pressure range (dependent on nominal width in Type 150) • Direction of flow as per direction of arrow on valve body (→ 3.4 Direction of flow, Page 8 ). -
Page 7: Layout
12 plunger guide tube 13 flat sealing ring 13 O-ring 14 O-ring 14 oil screw 15 threaded bush 15 cap nut 16 O-ring 16 gasket 17 seal bonnet 17 magnet coil 18 connector plug 301 215 BA-2017.09.08 EN Type 150, Type 160... -
Page 8: Direction Of Flow
Store the fitting properly. Make sure the storage room meets the following condi- tions: – – Frost-free – Vibration-free – Not in direct sunlight – Storage temperature +10 °C to +60 °C Type 150, Type 160 BA-2017.09.08 EN 301 215... -
Page 9: Disposal
– Neutralize residues of medium in the fitting. Remove plastic parts and dispose of them in accordance with local regulations. Dispose of fitting in accordance with local regulations. 301 215 BA-2017.09.08 EN Type 150, Type 160... -
Page 10: Installation And Connection
3. Adhesively apply or weld fitting with solvent welding/fusion socket ends. 5.3.2 Connection with internal thread fixed 1. Prepare pipe ends according to connection type. 2. Align fitting with the magnetic coil preferably upwards. 3. Screw pipe ends with fitting. Type 150, Type 160 BA-2017.09.08 EN 301 215... -
Page 11: Insulate Fitting
NOTE Danger of overheating from wrong plug! Mount only rectifier connectors on Type 150. 1. Ensure correct current type and voltage before electrical connection (→ data sheet). 2. Ensure that the plug connection is protected against per- manent dampness. -
Page 12: Maintenance
– No leaks – No unusual operating noises or vibrations 7.2.2 Changing magnetic coil of type 150 2. Clean fitting with a moist cloth if necessary. System is switched off and secured against being switched back on again Maintenance Follow the section drawing for disassembly (→... -
Page 13: Replacement Parts And Return
ID number – Nominal pressure and diameter – Body and seal material 2. Please complete and enclose the document of compliance for returns (→ www.asv-stuebbe.com/service/downloads). 3. Only use spare parts from ASV Stübbe. 301 215 BA-2017.09.08 EN Type 150, Type 160... -
Page 14: Troubleshooting
Check specifications of the fitting (→ data sheet). Magnetic coil defective Type 150: Install new magnetic coil (→ 7.2.2 Changing magnetic coil of type 150, Page 12). Type 160: Install new magnetic coil (→ 7.2.3 Changing magnetic coil of type 160, Page 12). -
Page 15: Appendix
160 Plug assignment DIN EN 175301-803 plug socket. The polarity of the con- nections (1,3) has no effect on operation. Fig. 5 Connection diagram (NO) (normally open), type 150 Fig. 6 Connection diagram (NC) (normally closed), type 150 Fig. 9... - Page 16 Appendix Type 150, Type 160 BA-2017.09.08 EN 301 215...
