- Page 1 LAVA-OGGETTI LAVE-BATTERIE WARE WASHER ZUBEHÖRE-SPÜLERE P550-ek P700-ek MANUALE ISTRUZIONI INSTRUCTIONS D'EMPLOI INSTRUCTIONS MANUAL INSTALLATION-BEDIENUNG REV.01-09/09/06...
- Page 3 Verantwortung, dass folgende Produkte LAVAOGGETTI - LAVE-BATTERIE - WARES-WASHER – ZUBEHÖRE-SPÜLER P550-ek/P700-ek mod. al quale questa dichiarazione si riferisce è conforme alle seguenti norme: auquel se réfère cette déclaration, est conforme aux normes suivantes: for which this declaration refers to the conformity of the following standards: auf welche sich diese Erklärung bezieht, folgendem Standard entsprechen:...
- Page 5 - EMC - Noi - Nous soussignés - The following - Die Unterzeichnete Fa: LAMBER snc di Affaba F. e c. Via Italia 6 26855 Lodivecchio (LO) ITALY dichiariamo sotto la nostra esclusiva responsabilità che il prodotto attestons sous notre entière responsabilité que le produit suivant hereby declares under full responsability that the following product erklärt unter eigener Verantwortung, dass folgende Produkte...
- Page 6 INDICE ITALIANO Note generali pag 07 Introduzione e norme di sicurezza pag. 08 Parte prima - NORME PER L'UTILIZZATORE pag. 13 Pannello Comandi pag. 14 Funzionamento ed uso; detersivi; manutenzione; inconvenienti possibili pag. 15 Parte seconda - NORME PER L'INSTALLATORE pag.
- Page 7 NOTE GENERALI ITALIANO Vi ringraziamo per la scelta da Voi fatta nell'acquisto della Vostra LAVA-OGGETTI Il perfetto funzionamento della macchina e risultati di lavaggio ottimali sotto il profilo igienico sanitario potranno essere garantiti solo se tutte le avvertenze del presente Manuale verranno rispettate. Ci auguriamo che le informazioni contenute nel presente manuale Vi siano di aiuto.
- Page 8 INTRODUCTION ENGLISH AND SAFETY NOTES INTRODUCTION The machine is an Industrial Wares-washing machine . The machine is in conformity to the European Norms 89/336/CEE for the radio noises. According to EEC directive no.23 of 19/02/1973 and the law of actuation no.791 of 18/10/1987, our appliances are built-up according to the good technique notes in force in Italy and abroad.
- Page 9 Fate conoscenza con l'apparecchio Faites connaissance avec l'appareil Learn to use the appliance Wollen Sie den Apparat kennenlernen Lavaggio superiore rotante in acciaio inox Doppia parete coibentata 20mm Lavage supérieur rotatif en acier inoxydable Double paroi isolée 20mm Stainless steel Upper rotating washing Double skin with insulation 20mm Rotierend Oberer Wascharm aus CNS Doppelwandige Isolation 20 mm...
- Page 10 NORME PER L'UTENTE INSTRUCTIONS POUR L'UTILISATEUR INSTRUCTIONS FOR THE USER AUFSTELLUNGSANLEITUNG FÜR DEN BENUTZER...
- Page 11 PANNELLO COMANDI EMPLOI CONTROLES CONTROL PANEL STEUERTAFEL Interruttore generale Interrupteur général Main switch Hauptschalter Lampada ciclo Lampe indicatrice de cycle Cycle lamp Programmkontrollampe Pulsante selezione tempo lavaggio Bouton sélecteur temps de lavage Wash time selection pushbutton Programmwahlschalter Pulsante ciclo Bouton cycle Cycle pushbutton Programmdrucktaste Lampada temperatura...
- Page 12 ENGLISH First Section - FOR THE USER WORKING AND USE NOTE: - When the objects to be washed present burnt crusts, or a long time is elapsed from cooking up to the time of washing, it is necessary to make a previous softening in water at 50°C, by using an appropriate softeningproducts;...
- Page 13 In order to make washing keep on, load 2,5 g/lt. Mean concentration of liquid cleansing another basket and press pushbutton "C". The agents nust be 2-4 g/lt. cycle will automatically start again. In order to avoid scales and corrosions, put cleansing agent above water level on the Endless cycle (maximum 15 minutes) : the nearest area of the sucking pump filter, in this...
- Page 14 DAILY MAINTENANCE CLEANING PREVENTIVE MAINTENANCE Disconnect the machine with pushbutton "A"; PRECAUTION CLEANING Lift the overflow pipe and let the water INSTRUCTIONS drain out of the tank; Wash thoroughly the tank and the filters housing to remove all impurities; IMPORTANT : Before carrying out the Take the filters out and clean them under cleaning maintenance...
- Page 15 SANIFICATION At last each 30 days it would be useful to do this operation which guarantees the complete hygienic conditions of the machine. We suggest to contact your cleansing agent supplier who will give you quantity and name of the most suitable product you can use and that, generally, is an active chloride powder (100- 200 ppm).
- Page 16 NORME PER L’INSTALLATORE Le istruzioni che seguono sono rivolte a personale qualificato, il solo autorizzato ad attuare le verifiche e le eventuali riparazioni. La Ditta declina ogni responsabilità nel caso di interventi effettuati da personale non qualificato e/o utilizzo di ricambi non originali. INSTRUCTIONS POUR L'INSTALLATEUR Les instructions suivantes sont adressées à...
- Page 17 INSTALLATION SCHEMA ALLACCIAMENTI INSTALLATIONSBLATT INSTALLATION P550-ek/P700-ek P550-ek=685 P550-ek=1160 P700-ek=805 P700-ek=1250 ø100 ø100 P550-ek=755 P700-ek=402 P700-ek=845 127.5 P550-ek=165 P700-ek=227 P550-ek=265 P700-ek=322 Altezza massima per scarico a muro - Hauteur maximale pour vidange à mur Maximum height for drain to wall - Maximale Bodenhöhe für Wandwasserablauf Elettrovalvola carico - Electrovanne chargement 3/4"...
- Page 18 ENGLISH Second Section - FOR THE INSTALLER During installation, carry-out a good machine levelling, which is a prerequisite for a correct operation thereof. The Manufacturer cannot assume any responsability for any damage to persons or property deriving from the non-observance of the above-specified norms. For correct installation see draw page 32.
-
Page 19: Water Connections
The machine is provided with a flexible pipe WATER CONNECTIONS for the connection with the water-work. Make sure there are no throttlings along the Carefully comply with any national or pipe. regional regulations in force. Carefully comply with any national or Water installation must have the following regional regulations in force. - Page 21 SCHEMA BRANCHEMENTS SCHEMA COLLEGAMENTI DIAGRAM OF CONNECTIONS ANSCHLUßSCHEMA Resistenza BOILER - Résistance SURCHAUFFEUR BOILER Elements - BOILERHEIZUNG Marrone - Marron Brown - Braun Nero - Noir Black - Schwarz Nero - Noir Black - Schwarz Ponticelli - Ponts Staples - Brücken Resistenza VASCA Résistance CUVE TANK Elements...
-
Page 22: Wiring Diagram
SCHEMA ELETTRICO SCHEMA ELECTRIQUE WIRING DIAGRAM SCHALTTAFEL 400 V3 N 50Hz Fa10 Fa11 Fa15 MT1 no Interruttore differenziale Interrupteur différentiel Differential switch Differentialschalter Interruttore generale Interrupteur général Main switch Hauptschalter Finecorsa Microinterrupteur Limit switch Endschalter Resistenza boiler Résistance Surchauffeur Boiler elements Boilerheizung Resistenza vasca Résistance Cuve... - Page 23 SCHEDA ELETTRONICA FICHE ELECTRONIQUE P .C.BOARD ELEKTRONISCHE STEURUNG filo/fil/wire/draht ITA SCARICO VIDANGE DRAIN PUMP ABLAUFPUMPE RIGENERA REGENERATION REGENERATIN ENTKALKUNG LAVAGGIO LAVAGE WASHING WASCHUNG RISCIACQUO RINÇAGE RINSING SPÜLUNG FASE PHASE' PHASE PHASE NEUTRO NEUTRE NEUTRAL UNGELADEN LIVELLO PRESSOSTATO NIVEAU PRESSOSTAT PRESSOSTAT LEVEL DRUCKWÄCHTER TEMPERATURA (TERMOSTATO) TEMPERATURE /THERMOSTAT)
- Page 24 COMPONENTEN COMPOSANTS KOMPONENTEN COMPONENTS Morsetti SCHEDA ELETTRONICA FICHE ELECTRONIQUE P.C.BOARD Ad2 Ad1 ELECTRONISCHE STEURUNG CASSETTA QUADRO COMANDO - CONTROL BOARD - BOITE DE CONTROLE - SCHALTTAFEL PANNELLO QUADRO COMANDO CONTROL PANEL PANNEAU DE CONTROLE STEUERTAFEL BASAMENTO SOCLE BASE UNTERBAU Cnp-ho-015-2005...
