- Page 1 ASC580 Stick Vacuum Cleaner USER MANUAL PLEASE KEEP THIS USER MANUAL FOR FUTURE USE.
-
Page 3: Table Of Contents
USER MANUAL CONTENTS SAFETY INSTRUCTIONS...............3 PACKAGE CONTENTS...............6 APPLIANCE OVERVIEW..............6 ASSEMBLING THE APPLIANCE............7 USING THE APPLIANCE..............8 CLEANING & MAINTENANCE............9 TECHNICAL SPECIFICATIONS............14 SAFETY INSTRUCTIONS IT IS STRONGLY ADVISED THAT YOU READ ALL OF THE PROVIDED SAFETY GUIDES AND OPERATING INSTRUCTIONS IN THIS USER MANUAL FIRST BEFORE USING THE APPLIANCE. - Page 4 Electrical Safety: • Only use batteries and chargers supplied by the manufacturer. • Never modify the charger in any way. • The charger has been designed for a specific voltage. Always check that the main voltage is the same as stated on the rating plate. •...
- Page 5 Service: • Before using the appliance and after any impact, check for signs of wear or damage and repair as necessary. • Do not use the appliance if any part is damaged or defective. • Repairs should be carried out by a service agent or a qualified person in accordance with relevant safety regulations.
-
Page 6: Package Contents
PACKAGE CONTENTS • Easy Start Guide • Main Body • Flat Suction Nozzle • User Manual • Handle Tube • Round Brush • Warranty Policy • Floor Brush • Power Adapter APPLIANCE OVERVIEW COMPONENTS MAIN BODY FLAT SUCTION NOZZLE WALL MOUNT BASE DUST CUP HANDLE TUBE ROUND BRUSH... -
Page 7: Assembling The Appliance
ASSEMBLING THE APPLIANCE NOTE: The components are packed separately for convenient transportation and storage. Assemble the appliance as shown in the following procedure. STEP 1 Remove the body from the wall mount base. STEP 2 Attach the handle tube to the floor brush. -
Page 8: Using The Appliance
USING THE APPLIANCE POWER BUTTON STEP 1 Press the Power button to switch on the vacuum cleaner at the highest speed (default). SPEED CONTROL BUTTON STEP 2 Press the Speed Control button to adjust the speed. POWER BUTTON STEP 3 Press the Power button again to switch off the vacuum cleaner. -
Page 9: Cleaning & Maintenance
CLEANING & MAINTENANCE CHARGING THE BATTERY BATTERY STEP 1 INDICATOR LIGHT KEEPS BLINKING WHITE When the battery power indicator is blinking in white, battery is low. STEP 2 Fasten the screw (M4*20) into the wall and hang the wall mount base. STEP 3 Place the body on the wall mount base. - Page 10 STEP 4 Charge the appliance by plugging in the charging connector through the hole of the wall mount base. STEP 5 Plug the power adapter into the power socket. BATTERY STEP 6 INDICATOR TURNS When the battery is full, the light turns off.
- Page 11 CLEANING THE DUST CUP & HEPA FILTER STEP 1 Press the Release button to detach the dust cup from the body. STEP 2 Lift the filter handle and remove the HEPA filter. Clean the HEPA filter thoroughly. STEP 3 Press the Release button on the bottom cover of the dust cup, then open the cover to dispose of the dirt.
- Page 12 STEP 4 Align the dust cup to the snap joint of dust cup cover. STEP 5 Rotate the dust cup cover. STEP 6 Remove the dust cup cover, filter cover and dust cup in sequence. Rinse the filter cover with water. NOTE: HEPA filter and other spare parts can be purchased from the vacuum cleaner retailers.
- Page 13 STEP 7 Install the filter cover, dust cup cover and HEPA filter into the dust cup in sequence. STEP 8 Attach the dust cup assembly to the body. STEP 9 To remove tangled hair in the floor brush, press the Release button to eject and remove the rolling brush.
-
Page 14: Technical Specifications
STEP 10 Scrape along the rolling brush with blade to cut and remove the hair, then reinstall the floor brush. NOTE: It is recommended to clean the dust cup after every use. If the HEPA filter is blocked by the accumulation of dust, clean or replace in time. - Page 16 Copyright © 2018 Aztech Technologies Pte Ltd (CRN:199800635M). All rights reserved.
