Carefree ECLIPSE Owner's Manual

12v motorized awning with carefree's bt12 wireless awning control system using bluetooth wireless technology
Hide thumbs Also See for ECLIPSE:
Table of Contents

Advertisement

Quick Links

RV
with Carefree's BT12 Wireless Awning Control System
Using Bluetooth ® wireless technology
Before operating the awning, carefully review the Owner's Manual.
The manual contains important safety information, detailed operating
instructions, common maintenance procedures and other useful
information.
T
C
ABLE OF
Introduction ........................................................................................................... 2
Operation ............................................................................................................... 6
Standard Switch Operation ............................................................................ 6
Ignition Lockout ............................................................................................. 6
Options ................................................................................................................... 7
BT Remote .................................................................................................... 7
BT Motion Sensor .......................................................................................... 8
LED's ............................................................................................................. 8
Setting the System into Pairing Mode ......................................................... 10
Carefree Connects Mobile App ................................................................... 10
Adjusting the Pitch .............................................................................................. 12
Emergency Operation ......................................................................................... 13
Awning Care ........................................................................................................ 14
Fabric Care .................................................................................................. 14
Arm Care ..................................................................................................... 14
Carefree Major Product Limited Warranty ......................................................... 16
ONTENTS
O
'
WNER
S
12V M
OTORIZED
M
ANUAL
E
CLIPSE
A
WNING

















Advertisement

Table of Contents
loading

Related Manuals for Carefree ECLIPSE

Summary of Contents for Carefree ECLIPSE

  • Page 1: Table Of Contents

    CLIPSE 12V M OTORIZED WNING with Carefree’s BT12 Wireless Awning Control System Using Bluetooth ® wireless technology Before operating the awning, carefully review the Owner's Manual. The manual contains important safety information, detailed operating instructions, common maintenance procedures and other useful information.

  • Page 2: Introduction

    100% satisfaction. If you have any questions or concerns about this order, please do not hesitate to contact us. Check with your dealer to discover the products that can make your life more Carefree. RODUCT ESCRIPTION The Eclipse awning provides motorized awning comfort with Carefree's standards for looks, strength and dependability with a successful blend of style, quality and economy.
  • Page 3 RADEMARKS The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. Use of such marks by Carefree of Colorado is under license. Other trademarks and trade names are those of their respective owners. TATEMENTS OF OMPLIANCE ●...
  • Page 4 The information contained in this manual pertains to the current components and software listed on the title page. Carefree of Colorado reserves the right to cancel, change, alter or add any parts and procedures, described in this manual, without prior notice.
  • Page 5 BT12 CLIPSE WITH Warnings and Cautions This is the safety alert symbol. It is used to alert individuals to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible personal injury or death. WARNING This product can expose you to chemicals including Di- isodecyl phthalate (DIDP), Vinyl Chloride and Formaldehyde, which are known to the state of California to cause cancer or birth defects or other reproductive harm.

  • Page 6: Operation

    Carefree of Colorado PERATION The BT12 Wireless Awning Control System offers multiple methods of operating the awning: standard switch operation, the Carefree Connects Mobile App (see page 10) and the BT Remote (see page 7). TANDARD WITCH PERATION To Operate the Awning: ...

  • Page 7: Options

    The BT12 Wireless Control System offers several options to enhance your awning experience. OEM’s may install these options as a standard offering or can be added to your system at a later date. Contact your Carefree sales rep about these options.

  • Page 8: Bt Motion Sensor

    NOTICE The Carefree auto retract system is a premier electronic auto- retract system that provides protection against adverse elements; but no auto- retract system is a guarantee against severe or destructive weather; the effects of wind and rain on an awning are unpredictable and may cause severe damage to the awning and/or vehicle.

  • Page 9: Led's

    A feature of the Carefree Connects Mobile App can be enabled to shut the LED lights off when the awning is retracted (closed). This is a safety feature to prevent the lights from being accidentally left on when the awning is retracted.

  • Page 10: Setting The System Into Pairing Mode

    (the module remembers the devices that have been paired).  Refer to the Carefree Connects Mobile App manual for setting up and pairing a smart device (such as a smart phone or tablet). ...
  • Page 11 AREFREE ONNECTS OBILE The Carefree Connects Mobile App allows you to interact with your awning(s) from your mobile device. The app provides access to enhanced features and additional options. The mobile app may be used on any device that supports current iOS or Android operating systems and Bluetooth low energy technology.

  • Page 12: Adjusting The Pitch

    DJUSTING THE ITCH The Eclipse arms have 6 pitch adjustment settings from minimum pitch to maximum pitch. The awning can be extended and retracted in any of these positions without having to reset the pitch between uses. See the NOTICES at the bottom of the page.

  • Page 13: Emergency Operation

    CLIPSE WITH MERGENCY PERATION If the original power source fails or is unavailable, the Eclipse has emergency override terminals (12V). The terminals can be used with a 9V-18V power source, such as a cordless drill battery or car battery. NOTICE...

  • Page 14: Awning Care

    Carefree of Colorado WNING Maintaining a Carefree Awning is easy. Just follow these basic steps:  Always operate the awning according to the instructions.  Periodically check that the fasteners are tight. Tighten if necessary.  Keep the awning fabric and arms clean.
  • Page 15 The number of short blinks is based on the number of peripherals paired. o The module does not blink for being paired to a mobile device with the Carefree Connects Mobile App. BT023 YSTEM EEPS AND THE...

  • Page 16: Carefree Major Product Limited Warranty

    Carefree’s obligation under this warranty is limited to the repair or replacement, at Carefree’s option, of any defective component with new or factory refurbished components.
