Robot Battery Charger - Robotronics Toby Tire Robot Operating Manual

The charger supplied with the robot is designed to both recharge your battery, and extend your
battery's life. It produces 12 Volts DC at a full 6 Amps. It will charge the battery in about 8 hours
depending on how long you have used the robot. After the battery is charged, the green LED
will come on and the battery is ready to use. At this point the charger is charging at a FLOAT or
maintenance rate. At this rate you can leave the charger connected for extended periods of
time.
Charge Pro Model 2606A 6 Amp Battery Charger
Status Indicating Lights
Red on-The battery is discharged and is being recharged at the maximum 6 Amp rate of the
charger (stage 1).
Red and green both on-The battery is charging at the stage 2 rate of 1.5 to 5 Amps.
Green on-Your battery is charged and ready to use. It is now on float charge (stage 3).
Personal Safety Precautions
When charging, a lead acid battery gives off hydrogen gas. The Gel type battery is a lead acid
battery with pressure relief type vents. Although it only gives off a small percentage of the gas
that a wet lead acid battery does, the following precautions should be observed:
1. Charge the battery in a dry, well ventilated area. This is why it is important that you leave
the trunk or door open. You can also remove the battery from the robot.
2. Do not position your face over the battery, at any time while making connections.
3. Do not smoke, strike a match, or cause a spark in the vicinity of the battery during charging.
4. Always unplug the AC supply cord before connecting or disconnecting the charger leads
from the battery.
5. Do not drop a metal tool onto the battery.
6. Do not expose the charger to rain.
7. Replace defective cords and wires immediately.
8. Do not operate this charger with a two bladed adapter plug or extension cord. Doing so
can result in serious personal injury.
9. To reduce the risk of shock, connect only to a properly grounded outlet.

ROBOT BATTERY CHARGER

Warnings
HAZARD OF EXPLOSIVE GAS MIXTURE
Robot Battery Charger
27
