Robotronics Toby Tire Robot Operating Manual page 48

Appendix A: Quick Reference Troubleshooting Chart
44
Problem
One of the eyelids is at a different level
No operation of any eye functions.
Water Squirter
Cannot fill reservoir
Cannot squirt: no pump sound.
Cannot squirt: pump sound yes
Voice Modifier
Voice not being modified
More detailed troubleshooting by system is included with each subsystem. For additional help or parts
call our service dept. at 801-489-4466.
Cause
1. Eyelid rod bent or eyelid out of adjustment
1. Connection at eye servo board has come off.
2. Wire(s) bringing 5 Volts and signal to servo
board are not making a connection. Broken
out of 37 pin connector.
3. No 5 Volts going to eye servo board.
1. In-line fuse blown.
2. Broken wire at water squirter switch or
coming from main box
1. Water squirter switch is not in on position.
2. Broken wire at pump or W.S. switch.
1. Reservoir empty
2. Water line is not connected to water
connector
3. Overflow tube and squirt tube are switched
at the reservoir.
1. Modifier not turned on.
2. Audio wires not plugged in correctly
Solution
1. Straighten bent rod or change eyelid position by
removing the servo arm.
lengthen the rod by twisting the servo arm. You
can also change the position of the servo arm on
the servo shaft.
1. Vehicle- located on underside of upper robot.
Robots with Character- located in character.
2. Vehicles- locate
(red/black/gray/yellow/black) going from the 37 pin
up to the eye servo board. Repair broken wiring.
Robots with Character- Check gray/yellow/black
and red black to eye servo board.
3. Find broken wire on red/black or check fuse for
eye servos on fuse block.
1. Replace the 5 Amp fuse which is in-line on the
wire. Follow wire from water squirter switch.
2. Repair break.
1. On position is not the center position.
2. Repair/re-solder broken wire.
1. Fill Reservoir with filler bottle.
2. Connect it.
3. Swap them back. Overflow tube is the one that
is in the top of the bottle and the tube runs to an
outlet on the bottom of the frame.
1. Push pedal on modifier. Light should come on.
2. Jumper wire goes from Nady Receiver to Input
of Modifier. Wire in Output A of modifier goes to
the main board.
Then shorten or
the wires
