INSTALLATION
INSTRUCTIONS
PARTS LIST
Front grille
TOOL AND SUPPLIES REQUIRED
Phillips screwdriver
Masking tape
Blanket
The following tool is available through the Honda Tool and
Equipment Program. On the iN, click on: Service >
Service Bay > Tool and Equipment Program, then enter
the number under "Search". Or, call 888-424-6857.
• Trim Tool Set (T/N SOJATP2014)
Illustration of the Front Grille on the Vehicle
FRONT GRILLE
© 2012 American Honda Motor Co., Inc. – All Rights Reserved.
Accessory
FRONT GRILLE
P/N 08F21-T2A-100
INSTALLATION
Customer Information: The information in this
installation instruction is intended for use only by skilled
technicians who have the proper tools, equipment, and
training to correctly and safely add equipment to your
vehicle. These procedures should not be attempted by
"do-it-yourselfers."
NOTE: Be careful not to damage the paint finish.
1.
QB13101AE
AII 47334 (1208)
Application
2013 ACCORD
4-DOOR
Attach masking tape to the front bumper, headlights
and front fenders as shown.
RIGHT
HEADLIGHT
MASKING
TAPE
Publications No.
AII 13032
Issue Date
AUG 2012
LEFT
HEADLIGHT
LEFT FRONT
FENDER
FRONT
BUMPER
QB13102AE
1 of 3
08F21-T2A-1000-90
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Honda 08F21-T2A-100
Summary of Contents for Honda 08F21-T2A-100
-
Page 1: Installation Instructions
• Trim Tool Set (T/N SOJATP2014) Illustration of the Front Grille on the Vehicle LEFT FRONT FENDER FRONT BUMPER MASKING TAPE QB13102AE FRONT GRILLE QB13101AE 1 of 3 © 2012 American Honda Motor Co., Inc. – All Rights Reserved. AII 47334 (1208) 08F21-T2A-1000-90... - Page 2 4 RETAINING TABS 2 SELF- TAPPING 2 SHORT SCREWS CLIPS 10 CLIPS BOTTOM VIEW FRONT BUMPER QB13106AE SHORT SHORT CLIP CLIP 10 CLIPS QB13104BE 2 of 3 AII 47334 (1208) © 2012 American Honda Motor Co., Inc. – All Rights Reserved.
- Page 3 With the help of an assistant, reinstall the front retaining tabs). bumper. Reinstall the front grille cover. 2 RETAINING TABS VEHICLE FRONT GRILLE (Discard.) FRONT 4 CLIPS BUMPER QB13108AE 3 of 3 © 2012 American Honda Motor Co., Inc. – All Rights Reserved. AII 47334 (1208)
