RIOTEC OM7222J Programming Quick Manual

Programming Quick Guide
- OM7222J/ OM7222JW/
OM7222K/OM7222L
/OM7222N
Installation
Make sure that the scanner has the correct cable to plug in the PC
as below described::
*Note : Please install PL-2303 driver for USB serial
Reset Configuration to Default :
(For USB HID, RS232, USB Serial)
If you are unsure of the scanner configuration or have scanned
the incorrect codes, please scan the following barcode. This will
reset the scanner to its factory defaults.
Default
Keyboard Language
(For USB HID Only)
Scan the barcode corresponding to the keyboard type
North American
Standard USB
Keyboard
French
Windows
French Canadian
Windows 2000/XP
Spanish
Windows
Swedish
Windows
Japanese
Windows (ASCII)
Redundancy Level
This scanner offers two levels of decode redundancy. Select higher
redundancy levels for decreasing levels of bar code quality. As
redundancy levels increase, the decoder's aggressiveness decreases.
Select the redundancy level appropriate for the bar code quality.
Redundancy Level 1
barcode must be successfully read twice
before being decoded
Redundancy Level 2
barcode must be successfully read three times
before being decoded:
1
1D Symbologies -1
German
Windows ENABLE
French Canadian
Windows 95/98 ENABLE
French Belgian
ENABLE
Windows
Italian
Windows ENABLE
UK English
Windows ENABLE
Portuguese-
Brazilian Windows ENABLE
ENABLE
ENABLE
ENABLE
UPC-A
DISABLE
UPC-E
DISABLE
EAN-8
DISABLE
EAN-13
DISABLE
Code 128
DISABLE
ISBT 128
DISABLE
Code 39
Code 39
DISABLE
Trioptic
Code 39
DISABLE
Code 39
FULL ASCII
DISABLE
