Instrument Setting; Setting Of „F Key Assign - WIKA Pascal ET Operating Instructions Manual

6. Commissioning, operation

6.4.3 Instrument setting

This menu enables to see and change the settings of the instrument.
EN
6.4.3.1 Setting of „F Key assign"
The last function displayed in the picture previous can be set here.
Push the button at the right side close to the field [F Key assign].
Each option is active only from the main screen, if the calibration is not currently performing a report or an HART® adjustment.
The available options are:
Option
Hold All ON/OFF
Recall Report list
Recall Preset list
52
Fig. 62 - Instrument setting screen
Fig. 63 - [F Key assign] button assignment
Meaning
press the [F Key assign] button to enable/disable the HOLD function on all active measuring channels.
press the [F Key assign] button load the list of the saved reports.
press the [F Key assign] button load the list of the saved presets.
WIKA operating instructions, model Pascal ET
