Owner's Handbook
Bonneville Bobber, Bonneville Bobber Black
and Bonneville Speedmaster
This handbook contains information on the Triumph Bonneville Bobber, Bonneville
Bobber Black and Bonneville Speedmaster motorcycles. Always store this Owner's
Handbook with the motorcycle and refer to it for information whenever necessary.
The information contained in this publication is based on the latest information
available at the time of printing. Triumph reserves the right to make changes at any
time without prior notice, or obligation.
Not to be reproduced wholly or in part without the written permission of
Triumph Motorcycles Limited.
© Copyright 08.2017 Triumph Motorcycles Limited, Hinckley, Leicestershire, England.
Publication part number 3855569-EN issue 1
1
