- Page 1 No.EX※※-OMT1010-B PRODUCT NAME SI unit for IO-Link device MODEL / Series / Product Number EX260-SIL1-X207 EX260-SIL1-X210 EX260-SIL3-X207...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions Model Indication and How to Order Summary of Product elements Summary of product function Installation and Wiring Installation Wiring LED Indication, Settings and Status Monitoring LED indication Switch setting (Data transmission rate setting) Parameter settings and status monitoring IODD file Data Storage Parameter data... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of "Caution", "Warning" or "Danger". They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
- Page 5 Operator This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
- Page 6 ■NOTE Follow the instructions given below when designing, selecting and handling the product. The instructions on design and selection (installation, wiring, environment, adjustment, operation, described below must also be followed. maintenance, etc.) Product specifications •When conformity to UL is required, the SI unit should be used with a UL1310 Class 2 power supply. •The SI unit is a UL approved product only if they have a mark on the body.
- Page 7 Product handling Installation •Do not drop, hit or apply excessive shock to the fieldbus system. Otherwise damage to the product can result, causing malfunction. •Tighten to the specified tightening torque. If the tightening torque is exceeded the mounting screws may be broken. IP67 protection cannot be guaranteed if the screws are not tightened to the specified torque.
- Page 8 •Mount the product in a place that is not exposed to vibration or impact. Otherwise failure or malfunction can result. •Do not use the product in an environment that is exposed to temperature cycle. Heat cycles other than ordinary changes in temperature can adversely affect the inside of the product. •Do not expose the product to direct sunlight.
-
Page 9: Model Indication And How To Order
Model Indication and How to Order EX260-SIL 1 -X207 IO-Link port type X207 IO-Link port Class A type X210 IO-Link port Class B type Connector type, output specification M12 connector, 32 outputs, PNP (negative common) / source M12 connector, 16 outputs, PNP (negative common) / source : EX260-SIL3-X207 only Fieldbus ... -
Page 10: Summary Of Product Elements
Summary of Product elements <EX260-SIL1/-SIL3-X207> Element Description IO-Link communication IO-Link communication interface for the 3-wire connection (Port Class A) connector (M12 4-pin plug, A-coded) Power supply for valves Power supply connector (M12 5-pin plug, A-coded) Ground terminal Functional earth (M3 screw) Output connector Output signal interface for valve manifold ... - Page 11 <EX260-SIL1-X210> Element Description IO-Link communication interface for the 5-wire connection (Port Class B) IO-Link communication and including power supply for valves power supply connector (M12 5-pin plug, A-coded) Ground terminal Functional earth (M3 screw) Output connector Output signal interface for valve manifold ...
-
Page 12: Summary Of Product Function
■Summary of product function I/O function This device can control 16 outputs or 32 outputs for solenoid valve control over the IO-Link system cyclic data exchange. Failsafe output setting Several output states for the IO-Link communication error can be set by parameter, either Clear Output, Force Output or Hold Last State. -
Page 13: Installation And Wiring
Installation and Wiring ■Installation Connect valve manifold to the SI unit. Dimensions for installation n: number of valve stations 120.7 136.7 152.7 168.7 184.7 200.7 216.7 232.7 248.7 264.7 280.7 296.7 312.7 328.7 344.7 (mm) The above table shows dimensions as an example for the SY5000 series valve manifold. -12- No.EX※※-OMT1010-B... -
Page 14: Wiring
■Wiring Select the appropriate cables to mate with the connectors mounted on the SI unit. <EX260-SIL1/SIL3-X207> IO-Link communication connector layout (Port Class A) BUS IN: M12 4-pin plug, A-coded Designation Description Power supply (+): +24 V for SI unit Power supply (-): 0 V for SI unit IO-Link communication line Power supply connector layout PWR: M12 5-pin plug, A-coded... - Page 15 Ground terminal Connect the ground terminal to ground. Resistance to ground should be 100 ohms or less. <EX260-SIL1/3-X207> <EX260-SIL1-X210> -14- No.EX※※-OMT1010-B...
-
Page 16: Led Indication, Settings And Status Monitoring
LED Indication, Settings and Status Monitoring ■LED indication LED Status Description Green ON Power ON, IO-Link communication inactive Green OFF Power OFF Flashing Green IO-Link communication active Green ON Power for the solenoid valve is supplied PWR(V) Power for the solenoid valve is not supplied or outside the tolerance range (19 V or less) ■Switch setting (Data transmission rate setting) The switch should only be set with the power supply turned off. -
Page 17: Parameter Settings And Status Monitoring
Direct Parameter Page 1 DPP1 Access Parameter Name Value Address 0x07 Vendor ID 0x08 289: EX260-SIL1-X207 (for COM3) 0x09 EX260-SIL1-X210 (for COM3) 290: EX260-SIL1-X207 (for COM2) 0x0A Device ID EX260-SIL1-X210 (for COM2) 291: EX260-SIL3-X207 (for COM3) 0x0B 292: EX260-SIL3-X207 (for COM2) -16- No.EX※※-OMT1010-B... - Page 18 0x0010 Vendor Name SMC Corporation (16) 0x0011 Vendor Text www.smcworld.com (17) e.g. 0x0012 Product Name EX260-SIL1-X207_COM (18) 0x0013 Product ID e.g. EX260-SIL1-X207 (19) 0x0014 Product Text SI unit (20) 0x0015 3 Serial Number "xxxxxxxxxxxxxxxx" (21) 0x0016 4 Hardware Revision HW-Vx.y...
- Page 19 Coding of SystemCommand (index 2) For ParamDownloadStore, Device reset, Application reset, Restore factory settings or Output switching count value reset, the ISDU Index 0x002 (SystemCommand) should be used. The buttons, a command interface to the SI unit, labelled with the following command name (except ParamDownloadStore) are displayed in the IO-Link Tool.
- Page 20 Device Access Locks (index 12) For Device Access Locks, the following Device locking possibilities are specified. Value Definition unlocked parameter (write) access locked data storage locked parameter (write) access locked and data storage locked Parameter (write) access: If the "Parameter (write) access" bit is set in the SI unit, write access to all SI unit parameters over the IO-Link communication is inhibited for all read/write parameters of the SI unit except the parameter Device Access Locks.
- Page 21 Application Specific Parameters Data Index Sub- Access Parameter name Type Default Storage Description (dec) index The failsafe 0x40 behavior for every Failsafe Output U16[2] {0,0} (64) output signal OUT0 to OUT15. The failsafe 0x41 behavior for every Failsafe Output U16[2] {0,0} (65) output signal...
- Page 22 Application Specific Parameters (Continued) Data Index Sub- Access Storage Parameter name Type Default Description (dec) index The output wire status for every output signal OUT16 to OUT31, the sub-index1 indicates the open 0x4A Output Wire U16[2] {0,0} circuit status and (74) Status sub-index2...
- Page 23 Structure of Failsafe Output parameter (index 64) The Failsafe output parameter (index 64) consists of two sub-indices that represent bit fields with a size of 16 bits each for Output 0 to Output 15. Bit 0 in the bit field corresponds to output line 0, Bit 1 to output line 1 and so on.
- Page 24 Structure of Output Switching Counts (index68) The output switching count parameter consists of thirty-two sub-indices that represent bit fields with a size of 32 bits each. Sub-index 1 corresponds to output line 0 cycle count, Sub-index 2 to output line 1 cycle count and so on.
- Page 25 Structure of Output Wire Status parameter (index 73) The Output wire status parameter (index 73) consists of two sub-indices that represent bit fields with a size of 16 bits each for Output 0 to Output 15. Bit 0 in the bit field corresponds to Output 0, Bit 1 to Output 1 and so on.
- Page 26 Structure of Output Switching Counts Set Point (index75) The Output switching count set point parameter (index75) represents a bit field with a size of 32 bits. Any number of output switching count set points, which is a common number to all outputs, up to 4,294,967,295 (0x FFFFFFFF) can be set in a 32 bit field.
-
Page 27: Output Number Layout
The following illustration shows the byte order in each case. For the fieldbus / Industrial Ethernet with the big endian transmission format (e.g. Profibus-DP, ProfiNet) EX260-SIL1-X207 / EX260-SIL1-X210 32 outputs type EX260-SIL3-X207... - Page 28 For the fieldbus / Industrial Ethernet with the little endian transmission format (e.g. EtherNet/IP, EtherCAT, CC-Link IE) EX260-SIL1-X207 / EX260-SIL1-X210 32 outputs type EX260-SIL3-X207 16 outputs type -27- No.EX※※-OMT1010-B...
- Page 29 The output numbering refers to the solenoid position on the manifold and starts at zero. Standard wiring of the manifold is for a double-solenoid valve. The output number starts at the A side and then B side in that order as shown in figure a.
-
Page 30: Troubleshooting And Maintenance
Troubleshooting and Maintenance ○Troubleshooting chart When any malfunction is observed, it is recommended to perform the following troubleshooting. SI unit SI unit Refer to fault malfunction COM LED is OFF No.1 SI unit Refer to fault PWR (V) LED is OFF No.2 SI unit COM LED Refer to fault... - Page 31 ○Troubleshooting table Fault No.1 Fault Probable cause Recommended error handling Recommended action Re-tighten the IO-Link cable. Defective IO-Link (Replace the cable if it is broken) Check the condition of the IO-Link cable cable wiring for SI wiring to the SI unit. Correct the IO-Link cable wiring unit operation layout.
- Page 32 Fault No.4 Fault Probable cause Recommended error handling Recommended action If the inspection level of the Master port in Connect the SI unit with a which the SI unit is connected is Device ID that matches the ID TYPE_COMP, Check the Device ID of the Master port has configured in the Master port.
- Page 33 Fault No.7 Fault Probable cause Recommended error handling Recommended action Tighten the screws with the Poor connection Check if there are any loose screws making specified tightening torque between SI unit and the connection between the SI unit and the (i.e.
- Page 34 ■Maintenance Replacement of the SI unit •Remove the M3 hexagon screws from the SI unit and release the SI unit from the valve manifold. •Replace the SI unit. •Tighten the screws with the specified tightening torque. (0.6 Nm) Precautions for maintenance (1) Be sure to switch off the power.
-
Page 35: Specification
SI unit power supply 0.1 A max. Current consumption in 22.8 to 26.4 VDC power supply voltage Solenoid valve power 2.0 A or less (EX260-SIL1-X207 and X210)/1.0 A or less range supply (EX260-SIL3-X207), according to the solenoid valve station specification Output type... - Page 36 IO-Link communication specifications Item Specifications Protocol IO-Link version 1.1 Data transmission rate 230.4 Kbps (COM3) or 38.4 kbps (COM2) selectable EX260-SIL1-X207 (COM3) 0.8 ms EX260-SIL1-X210 (COM3) Process data minimum EX260-SIL1-X207 (COM2) 3.4 ms cycle time EX260-SIL1-X210 (COM2) EX260-SIL3-X207 (COM3) 0.5 ms EX260-SIL3-X207 (COM2) 2.5 ms...
-
Page 37: Dimensions
■Dimensions <EX260-SIL1-X207/ EX260-SIL3-X207> •If a fieldwireable connector is used for the power supply connection, and the SI unit is installed directly to a valve manifold, the connector should be 16 mm or less. If the connector is a larger diameter it will interfere with the clamping face. - Page 38 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2016-2017 SMC Corporation All Rights Reserved No.EX※※-OMT1010-B...
