- Page 1 No.EX##-OMJ0001 SI unit for ControlNet PRODUCT NAME EX250-SCN1 Model / Series...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions Model No. of product and how to order Contents of package Description and Function of Each Part Mounting/Installation method How to install Wiring and connection Setting/Adjustment Setting of address and HOLD/CLEAR of output ControlNet CONFIGURATION WITH RSLogix 5000 Specification Specification Outline with Dimensions... -
Page 3: Safety Instructions
Safety Instructions This SI unit and this manual contains essential information to prevent possible injury and damage to (users and other people, and property) and to ensure correct handling. Please confirm understanding the meaning of the following messages (signs) before reading the remaining the text, and always follow the instructions. - Page 4 1.The compatibility of pneumatic equipment is the responsibility of the person who designs the pneumatic system or decides its specifications. Since the products specified here are used in various operating conditions, their compatibility with the specific pneumatic system must be based on specifications or after analysis and / or tests to meet your specific requirements.
- Page 5 NOTE ♦Follow the instructions given below when handling reduced-wiring system: Or it will have a risk of being damaged and operating failure. ♦The instructions on selection (installation, wiring, environment of use, adjustment, operation and maintenance) described below must also be followed. ∗Product specifications •The direct-current power supply to combine should be UL authorization power supply.
- Page 6 •Verify the insulation of wiring. Insulation failure (interference with other circuit, poor insulation between terminals and etc.) could introduce excessive voltage or current to the reduced-wiring system or each I/O device and damage them. •Separate power line for solenoid valves from power line for input and control unit. Otherwise wires can be interrupted with noise or induced surge voltage causing malfunction.
-
Page 7: Model No. Of Product And How To Order
Model No. of product and how to order Contents of package Make sure that all the components pictured below are included. If some components are missing, or different from the ordered ones, please contact SMC sales representative. Description and Function of Each Part Body •... - Page 8 LED indication No. EX##-OMJ0001...
-
Page 9: Mounting/Installation Method
Mounting/Installation method How to install The SI unit is not designed to be a standalone device. Always use with solenoid valves or Output blocks. In addition, if an Input block is not needed, directly connect an endplate to the SI unit (Part number:EX250-EA1, EX250-EA2). -
Page 10: Wiring And Connection
Wiring and connection 1. Connection ControlNet network consists of nodes, taps, trunk cables, drop cables and repeaters. Wiring should be arranged in accordance with ControlNet specifications. Term Definition Network A collection of connected nodes the connection paths between any pair of devices may include repeaters and bridges. - Page 11 Total cable length for segment A segment is comprised of several sections of trunk cable separated by taps. The total cable length of a segment is equal to the sum of all of the trunk-cable sections. The total allowable length of a segment depends upon the number of taps in your segment. There is no minimum trunk-cable section length requirement.
- Page 12 2.Connection example * SMC only provides the SI unit and the power cable. Please refer to other manufactures for additional parts needed. 3. Power supply wiring The power supply connector features two independent electrical circuits, one for the output devices and one for the SI unit / Input blocks.
- Page 13 SW power supply is applied to the sensor connected to the Input block. Since a maximum of approx. 1V voltage may drop in the unit, select a sensor considering the voltage drop. If 24V needs to be supplied by any means, SW power supply voltage should slightly be increased in order to maintain the sensor voltage at 24V with the actual load applied (allowable voltage of SW power supply ranges from 19.2 to 28.8V).
-
Page 14: Setting/Adjustment
Setting/Adjustment Setting of address and HOLD/CLEAR of output The setting for the address and HOLD/CLEAR of output can be performed with 2 rotary switches and 1 DIP switch located under the cover. Address setting Each address is assigned to the unit with an address setting switch. -
Page 15: Controlnet Configuration With Rslogix 5000 Tm
ControlNet CONFIGURATION WITH RSLogix5000 When setting up the node with RSLogix5000, specific values must be entered for the assembly instance with regards to Input, Output and Configuration. Please see the diagram below for a Rockwell Automation’s RSLogix5000 programming software example. Connection Parameter Assembly Instance values: Description... -
Page 16: Specification
Specification Specification General specification Item Specification Operating ambient temp. +5 to +45°C Storage ambient humidity 35 to 85%RH (No condensation) Storage ambient temp. -20 to 60°C 10 to 57Hz 0.35mm (Constant amplitude) Vibration proof 57 to 150Hz 50m/s (Constant acceleration) Impact proof 150m/s (peak), 11ms x three times in each direction +/- X, Y and Z. -
Page 17: Outline With Dimensions
Input/Output block Part No. Remark Input component EX250-IE1 M12 connector, 2-input Input component EX250-IE2 M12 connector, 4-input Input component EX250-IE3 M8 connector, 4-input Output component EX9-OET1 M12 connector, PNP output (-COM), For low watt Output component EX9-OEP1 M12 connector, PNP output (-COM), For high watt Output component EX9-PE1 M12 connector, Power block Applicable solenoid valve series... -
Page 18: Maintenance Procedure
Maintenance procedure How to replace SI unit • Remove screws mounted on the endplate, and separate it from the valve unit. • Replace the SI unit (Tie rods should not be removed). Mount the removed endplate, and tighten it with the same screws with a specified tightening torque. (0.6N⋅m) Precautions on maintenance (1) Be sure to check that all the power supply is turned off. -
Page 19: Trouble
Trouble Trouble No.1 Trouble Possible cause Investigation method of cause Remedy Wrong wiring of Check that wiring of power supply for Connect power supply for communication and connector are not them properly. communication loosened. RWR lights off Failure of power Apply DC26.5 to 31.6V of Check the status of power supply for supply for... - Page 20 UNITED KINGDOM / (44) 1908-56 3888 Note: Please acknowledge that this content might change without a previous notice beforehand. Each company might be using the name of the commodity of this manual publishing respectively as a trademark. 2004 SMC Corporation All Rights Reserved No. EX##-OMJ0001...
