Print Mode; List Setup - LabelTac Pro X User Manual

Item
Use this item to setup printing darkness. The available setting is from 0
Darkness
to 30, and the step is 1. You may need to adjust your density based on
selected media.
Use this item to setup print speed. The each increase or decrease is 1
Print Speed
ips. Available setting is from 2 to 6.
This item is used to fine tune media stop location. Available setting
Tear Off
value is from "+" to "-" or "0" to "9".
This item is used to set the print mode. There are 3 modes as below,
Printer Mode
Tear Off

Print mode

Peeler Off
Print Width This item is used to set print width. The available value is from "0" to "9".
This feature is used to print current printer available fonts list to the label.
List Fonts
The fonts stored in the printer's DRAM, Flash or optional memory card.
This feature is used to print current printer available images list to
List Images
the label. The images stored in the printer's DRAM, Flash or optional
memory card.
This feature is used to print current printer available formats list to
List Formats
the label. The formats stored in the printer's DRAM, Flash or optional
memory card.

List Setup

This feature is used to print current printer configuration to the label.
Control Prefix
This feature is used to set control prefix character.
Format Prefix
This feature is used to set control prefix character.
Delimiter Char
This feature is used to set delimiter character. N/A
This option is used to set the action of the media when you turn on the printer.
Selections
Media Power Up
Calibration
No Motion
This option is used to set the action of the media when you close the
print head.
Selections
Head Close
Calibration
No Motion
This option is used to adjust print position vertically on the label. 0 The
Label Top
range is -120 to +120 dots.
This option is used to adjust print position horizontally on the label. The
Left Position
range is -9999 to +9999 dots.
When reprint mode is enabled, you can reprint the last label printer by
Reprint Mode
pressing "UP" button on printer's control panel.
Selects the bitmap scaling factor. The first number is the original dots
Format Convert
per inch (dpi) value; the second, the dpi to which you would like to scale.
Note: If printing from enclosed software/driver, the software/driver will send out the commands, which will overwrite
the settings set from the panel.
Description
Description
Next label top of form is aligned to the
print head burn line location.
Enable the label peel off mode.
Cutter Enable the label cutter mode
Description
Feed Printer will advance one label
Printer will calibration the sensor
levels, determine length and feed label
Length Printer determine length and feed label
Printer will not move media
Description
Feed Printer will advance one label
Printer will calibration the sensor
levels, determine length and feed label
Length Printer determine length and feed label
Printer will not move media
LabelTac Pro X | REFERENCE GUIDE
®
Default
16
6 (203dpi)
4 (300dpi)
3 (600dpi)
+000
Tear Off
N/A
N/A
N/A
N/A
N/A
N/A
N/A
No Motion
No Motion
0
+0000
Disabled
None
