Madeli B999-30-001 series Specification & Installation Manual

Functional Elegance
Vicenza - 30"
Features
• Free Standing 30" vanity: 32-1/16" (815mm)H x 22"(559mm)D x 29-5/8"
(753mm)W
• Furniture grade plywood layered with solid wood veneer and protected
with several coats of polyurethane (No particle board or MDF used).
• Matching nish inside out
• Two drawers of di erent depths with full-extension soft-close European
hardware.
• The bottom drawer includes adjustable tempered glass dividers.
• Handle and legs: Polished chrome nish
Colors/Finishes
• Ash Grey (AG)
• Glossy White (GW)
• Walnut (WA)
32-1/16"
(815mm)
SIDE VIEW
18-13/16"
20-3/4"
(478mm)
(527mm)
For clari cation, please contact Madeli Customer Care at (800)-819-6988 or (305)-718-8817 Ext. 1
All dimensions are approximate and subject to standard tolerance. Speci cations subject to change without prior notice.
29-5/8"
(559mm)
(753mm)
8-1/2" (140mm)
(216mm)
15-1/2"
(394mm)
Madeli, USA LLC | 9710 NW 110th Ave., Suite 1
Tel: 305-718-8817 | Fax: 305-718-8477
Speci cation & Installation Guide
Top/Basin options
• White or Soft Grey Quartzstone™ top & white under mount
ceramic basin
• Glossy White X-Stone top/basin
• Tempered glass top and ceramic basin
• Glossy or Matte White X-Stone at top with any other suitable
above-counter vessels
Package Dimensions
32" x 26" x 35"
Weight
121 lbs. / 55 kgs.
22"
21-5/16" (541mm)
5-1/2"
5-3/4"
(146mm)
22" (559mm)
| Miami , FL 33178
| Toll Free: 1-800-819-6988
Model Number
B999-30-001-XX
11/16"
(18mm)
| madeli.com
All Rights Reserved - 2017
01 | Page
Rev. 022217
