Madeli Apogee B450 Series Installation Manual

Functional Elegance
B450-Apogee
Wall Hung Vanity Collection
Models
• B450-24-002-XX
• B450-30-002-XX
• B450-36-002-XX
• B450-42-002-XX
• B450-48C-002-XX
Specifications / Spécifications
Table of Contents
Specifications 24/30/36/42/48C.........................................................................................................2
Specifications 48D.............................................................................................................................3
Specifications 60C.............................................................................................................................4
Specifications 60D/72D.....................................................................................................................5
Typical Installation: Wall Hung/B450-Apogee................................................................................6-7
Installation Steps: Wall Hung/B450-Apogee..................................................................................8-9
Feet/Base Installation: Free Standing/B460-Pinnacle....................................................................10
Typical Installation: Free Standing/B460-Pinnacle.....................................................................11-12
For clarification, please contact Madeli Customer Care at (800) 819-6988 Ext.1 or service@madeli.com
Pour plus de précisions, veuillez contacter le service client Madeli au (800) 819-6988 Ext.1 ou service@madeli.com
Madeli, USA LLC
Specifications and Installation Guide
• B450-48D-002-XX
• B450-60C-002-XX
• B450-60D-002-XX
• B450-72D-002-XX
| madeli.com | 9710 NW 110th Ave., Suite 1, Miami, FL 33178
APOGEE / PINNACLE
B460-Pinnacle
Free Standing Vanity Collection
• B460-24-001-XX
• B460-30-001-XX
• B460-36-001-XX
• B460-42-001-XX
• B460-48C-001-XX
| Toll Free: 1-800-819-6988
• B460-48D-001-XX
• B460-60C-001-XX
• B460-60D-001-XX
• B460-72D-001-XX
Page / Page
All Rights Reserved - 2024 Rev. 05/28/24
