Madeli Milano-48 Specification & Installation Manual

Functional Elegance
Milano - 48" Double Bowl
Features
• Free Standing 48" vanity : 24-3/8"(620mm)H x 18"(458mm)D x 47-5/8"
(1210mm)W
• Furniture grade plywood layered with solid wood veneer and protected
with several coats of polyurethane (No particle board or MDF used).
• Two fully adjustable drawers with full-extension soft-close European
hardware.
• Bottom drawer includes adjustable tempered glass dividers
• Feet option: 4 L-Feet or 2 S-Feet in Polished Chrome or Brushed Nickel finish.
Colors/Finishes
• Ash Grey (AG)
• Glossy White (GW)
• Walnut (WA)
47-5/8"
(1210mm)
24-3/8"
(620mm)
L-FEET
SIDE VIEW
7-7/8"
(200mm)
3-3/8" (86mm)
4-1/2"
(116mm)
9-1/8"
(232mm)
Madeli, USA LLC | 9710 NW 110th Ave., Suite 1
Tel: 305-718-8817 | Fax: 305-718-8477
Top/Basin options
• White, Soft Grey or White Carrara Quartzstone™ top
& White ceramic basin
• Glossy White X-Stone top/basin
Package Dimensions
52" x 22"x 27"
Weight
180 lbs. / 86.4 kgs
18" (458mm)
S-FEET
13/16" (20mm)
17-1/4" (438mm)
(203mm)
16-1/8"
(409mm)
L-FEET
12-3/16" (310mm)
15-11/16" (398mm)
18" (458mm)
| Miami , FL 33178
| Toll Free: 1-800-819-6988
B200-48D-021-XX
8"
1/8"
(3mm)
24-3/8"
(620mm)
33-1/2"
(852mm)
SIG-B20048D021
| madeli.com
All Rights Reserved - 2016
Model Number
01 | Page
Rev. 040118
