Operating Manual
Masterdrainer 80 Kombi
Art.no. 013854880
44 1683 001M1-D
MasterDrainer 80 Kombi
17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Masterdrainer 80 Kombi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TECALEMIT Masterdrainer 80 Kombi

  • Page 1 Operating Manual Masterdrainer 80 Kombi Art.no. 013854880 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 2: Table Of Contents

    4.2.Cleaning ........................27  5.  Repair and service ....................28  6.  Dispoal ........................28  7.  Outline drawing ....................29  7.1.Overview drawing ....................30  8.  Spare parts list ....................31  9.  Declaration ......................32  10.  Notes ........................33  44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 3 Technical changes reserved. Service Hotline +49 1805 900 301 (0,14 €/Min: on the German landline network, Mobile telephone max. 0,42 €/Min.) service@tecalemit.de Document-No.: 44 1683 001M1-D Stand: / As of: 21.01.2015 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 4: Safety Instructions

    The device has been designed to handle water hazardous substances. The regulations on the operating place (e.g. Water Resources Act WHG, = ordinance on installations for handling of substances hazardous to water VAwS) must be adhered to. 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 5 Machine or system components, on which inspection, maintenance or repair work is to be carried out must be de- energised.Product description 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 6: Technical Description

    2.2. Requirements for use The MasterDrainer 80 Kombi is intended for use in workshops, petrol stations and similar facilities. Only used lubricating oils of known origin with a flash point above 55°C - Hazard Class AIII (VbF) - may be filled.
  • Page 7: Accessories

    027 027 411 Suction probe Ø 5.4 mm 027 027 431 950 mm long, flexible, for MCC Smart 2.4. Technical data The following table shows the data of the MasterDrainer 80 Kombi Item Data Comments Tank volume approx. 80 litres Effective capacity approx.
  • Page 8: Installation Instructions

    MasterDrainer 80 Kombi against accidental operation and, when shut down, turn it off securely against unauthorised operation. When shut down the MasterDrainer 80 Kombi is to be disconnected from the compressed air supply! The equipment may be operated only under supervision!
  • Page 9: Suction Output

    The suction probe (adapter) is to be selected with the largest possible cross section.  Keep the suction hose as far as possible straight and without tight bends or buckled. The diagram presents target values for the suction output. 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 10: Collecting Using The Collecting Pan

    Following completion of drainage close the ball valve on the drainage hose, disconnect the equipment from the compressed air supply and plug on the suction probe again. The ball valve on the compact valve is to remain open for the ventilation of the tank. 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 11: Scheduled Maintenance

    Pressurising components and safety devices 4.1.1. Pressure tank The pressure tank of the MasterDrainer 80 Kombi is subject to the Pressure Equipment Directive 97/23/EC. It is classified in Category I according to the conformity assessment procedure and designed, manufactured and tested in accordance with Module A.
  • Page 12: Repair And Service

    The equipment is to be disposed of properly when taken permanently out of service:  Return old metal for recycling.  Return plastic parts for recycling.  Return electronic waste for recycling. The water legal regulations are to be followed. 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 13: Outline Drawing

    Outline drawing 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 14: Overview Drawing

    Ball valve, suction hose Tubular pipe with suction probe Level indicator Tank Compressed air connection Ball valve drainer tube Ejector Silence Vacuum gauge Safety valve Compressed air connection Ball valve ejector discharging Ball valve Compact valve Detail 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 15: Spare Parts List

    8. Spare parts list 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 16: Declaration

    Declaration 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 17: Notes

    10. Notes 44 1683 001M1-D MasterDrainer 80 Kombi...
  • Page 18 HORN GmbH & Co. KG Munketoft 42 24937 Flensburg Germany T +49 461-8696-0 F +49 461-8696-66 www.tecalemit.de info@tecalemit.de 44 1683 001M1-D MasterDrainer 80 Kombi...
