Chapter 2: Technical Specifications - Snap-On ELITE User Manual

Chapter 2
Item
Display (LCD)
Digital Camera
Thermal Imager
LED Spotlight
Image Storage Memory Capacity
Image File Format
Video File Format
USB Interface
Battery
USB Power Supply Rating
Operating Voltage (USB input)
Operating Altitude
Width
Height
Depth
Weight
Operating Temperature Range (ambient)
Storage Temperature (ambient)
Environmental Conditions
Technical Specifications
Size (diagonal): 109mm (4.3 in.)
Resolution: 480 x 272 pixels
Focus: Fixed
Temperature Measurement Range: -20 to 450 °C (-4 to 840 °F)
Color Palettes: 4 options: Iron, Rainbow, Grey-Iron, Cool-Hot
Thermal Sensitivity (NETD): < 50mK (millidegrees Kelvin)
IR Image Refresh Rate: < 9 times per second
Radiometric Accuracy:
Typical (at 68°F (20°C)): ±5°C or ±5% (whichever is greater)
Maximum (over total temperature range): ±7°C or ±5% (whichever is
greater)
Spectral Range: Longwave infrared, 8 to 14 µm
IR Image Detector Type: Uncooled LWIR (Long Wave Infrared)
Effective Distance: Optimum results when used within 5 ft. (1.5 m)
Spot Size Ratio: 14:1
Low: 7 lumens
Med.: 12 lumens
High: 22 lumens
> 15000 images or 225 video recordings (total depends on the number
and size of the files)
.bmp
.avi
2.0 USB, micro USB
Rechargeable Lithium Ion Battery Pack (+3.7V, 2800mAh (nominal))
Approximate 4 hour continuous operation, with the brightness level
setting at 50%
Approximate 80% charge in 3-hours, 100% charge in less than 5-hours
5 VDC, 2A
4.75 to 5.25 VDC
Maximum 2000 m
4.80 in. (122.0 mm)
9.09 in. (231.0 mm)
2.24 in. (57.0 mm)
0.83 lb (376.5 g)
At 0 to 90% relative humidity (non-condensing)
32 to 113°F (0 to 45°C)
At 0 to 70% relative humidity (non-condensing)
–4 to 140°F (–20 to 60°C)
This product is intended for indoor use only. It is not rated for damp or
wet locations.
This product is rated for Pollution Degree 2 (normal conditions)
3
Description / Specification
