Features
Power
On / Off
- N (No)
Cancel
selection
Left / Right
Navigate the
menu
Up / Down
Select laser or
thermal
modes

Getting Started

Your Thermal Laser is shipped with
a partial battery charge.
Fully charge the battery before use.
1. Connect the supplied USB cable to
the micro USB jack, and to the USB
power supply adapter.
2. Connect the USB power supply
adapter to a live power source.
Q UIC K-START GUID E
micro USB Jack
Charge the battery,
and connect to PC
- Y (Yes)
Accept
selection
Battery
Charge
Indicator
Charging
Charged

Thermal Mode

1.
Press
to select one of six
thermal views.
2. Point
at object.
3. Pull
trigger to capture screeenshot,
then press "Y" to save it.

Laser Spot Temperature Mode

1. Press
until "Press TRIG to start
measurement" displays.
2. Hold trigger in and point laser at
object.
3. Release trigger to capture
screenshot, then press "Y" to save it.
Laser
Thermal
Lens
Camera
Lens
LED
Spotlight
Trigger
Capture
screenshots
