JETI model Max BEC 2D Manual page 10

for the handling of magnets. The magnet is contained within a special holder made of aluminium.
1. Keep the magnet a safe distance from all devices that could be damaged by magnetic
interference: Televisions, Credit Cards, PC's and Pacemakers.
2. Keep magnets away from children, due to the risk of ingestion or injury.
9. Technical Specification of the MAXBEC2D
Technical Data
Recommended Input Voltage
Maximum Input Voltage
Number of possible power-supply batteries 1 or 2
Adjustable Output Voltage
Maximum current (pulse)
Continuous current
Quiescent current
Maximum Power Dissipation
Operating Temperature
Weight
Dimensions
Table showing the dependency between input voltage, output voltage and continuous
current capability
Number of power-supply cells (Input V.)
2 LiXX / 6 NiXX
3 LiXX / 10 NiXX
12 NiXX
MAX BEC 2D
5.5 - 8.4 V
16 V
5.0 - 6.0V (0.1V Steps)
20A
12A
240µA
20 W
-10°C to 130°C
85g
100 x 29 x 16 mm
Output Voltage (V) / Continuous Current (A)
5 V 5.4 V
8.33 A 10.00 A
3.28 A 3.51 A
2.44 A 2.56 A
5.7 V 6 V
11.76 A 12.00 A
3.70 A 3.92 A
3.70 A 3.92 A
