- Page 1 CRYSTALLINE SILICON PV MODULE INSTALLATION GUIDE...
-
Page 2: Mechanical Installation
CRYSTALLINE SILICON PV MODULE INSTALLATION GUIDE Introduction Purpose Limitation of Liability Safety General Safety Installation Safety Mechanical Installation Installation Condition Installation Methods Electrical Installation Installation Condition Grounding Maintenance and Disposal... - Page 3 Because the use of this manual and the conditions or methods of installation, operation, use and maintenance of photovoltaic (PV) products are beyond Astronergy’s control, Astronergy does not accept responsibility and expressly disclaims liability for loss, damage, or expense arising out of or in any way connected with such installation, operation, use or maintenance.
- Page 4 All modules must be securely fastened with at least 4 bolts. For maximum security against strong winds or heavy snow falls, all 6 mounting holes (modules CHSM5409M, CHSM6609M/P, and CHSM6610M/P; see figure 1a) or 8 mounting holes (CHSM6611P and CHSM6612P; figure 1b) should be used.
- Page 5 Figure 1. Bolt positions for the at-minimum four-bolts for a) modules CHSM5409M, CHSM6609M/P, CHSM6610M/P; and b) modules CHSM6611P and CHSM6612P. Solid red arrows indicate primary bolt positions; dashed blue arrows indicate positions where bolts can be added for additional support.
- Page 6 Figure 3. Illustrations of the three different methods for clamping modules onto the frame with aluminum clamps. Each aluminum mounting clamp comes with an M8 bolt, a plain washer, a spring washer, and an M8 nut. To fasten the module: 1.
- Page 7 Figure 6. Permitted clamping locations with clamp. For exact dimensions for a given module series, see table 1 (below). Table 1. Use in conjunction with figure 6 to determine permitted clamping locations for a given module series for clamping with clamps. Module Series Dimension CHSM5409M 1200*554*35 1200 CHSM5611M 1453*808*35...
- Page 8 4. Electrical Installation and Grounding Installation 4.1.1 The electrical characteristics are within ±10 percent of the indicated values of Isc. Voc and Pmp under test conditions (irradiance of 100 mW/cm2,AM1.5 spectrum, and a cell temperature of 25°C). 4.1.2 The maximum system voltage for all module series is 600 V for North American Market and 1000V for European Market.
-
Page 9: Maintenance
Grounding Figure 7. Grounding the aluminum frame with copper wire. 4.2.1 Use the marked 5.5 mm grounding holes (5.5mm) to ground the anodized frame. Use an M5 nut, two M5 cut washers, an M5 plain washer, an M5 spring washer, and an M5 bolt and a copper wire. All nuts, bolts, and washers are type M5 and should be made of stainless steel (as in figure 8). -
Page 10: Corporate Headquarters
Tel: + 82 (0)2 2226 3911 Fax: + 49 (0)751 295096-39 Fax: + 82 (0)2 2226 3910 Thailand North America Astronergy Solar Korea (Thailand) Co., Astronergy Solar Inc Ltd. 377 Swift Avenue 184/88 Forum Tower 18FL South San Francisco, CA 94080 Ratchadapisek Rd., Huay-Kwang,...
